SK-F SERIES PARTS LIST

Pump Model SK08CF SK15CF SK22CF SK37CF SK55CF SK75CF SK110CF SK150CF

Pos. No. Part Description

Item # Item # Item # Item # Item # Item # Item # Item #

01-2 Stand Only 202847 202858 202850 202855 201998 201998 202000 202000

Suction Cover, Cast Iron - - - - 202880 202880 202882 202882

02 Suction Cover, Hi-Chrome 202045 202046 202047 202048 - - - -

03 Impeller Nut 202894 202894 202894 202894 202897 202897 202897 202897

04 Impeller Washer 202907 202907 202907 202907 202917 202917 202917 202917

05 Impeller, Cast Iron 202956 202961 202964 202967 202136 202138 202945 202947

05 Impeller, Hi-Chrome 202126 202960 202963 202966 - - - -

06 Impeller Key 202140 202140 202140 202140 202146 202146 202146 202987

07 Pump Housing 202173 203008 203011 203014 203024 203024 203027 203027

08 Oil Chamber Cover 202213 202213 202218 202218 202221 202221 202223 202223

08-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit

09 Lip Seal FKM 202232 202232 202235 202235 202243 202243 202243 202243

13 Mechanical Seal FKM** 200500 200500 200301 200301 200307 200307 200307 200307

13-2 Mechanical Seal Retainer - - - - 202273 202273 202273 202273

14 Lower Ball Bearing ( * =Qty 2 Needed) 200958 200958 200959 200959 200962 200962 200962* 200962*

14-2 Lower Bearing Retainer 202279 202279 202279 202279 203075 203075 203076 203076

14-3 Lock Nut & Lock Washer 200424 200424

17 Rotor w/ Shaft, 3PH 204031 204032 204033 204034 204035 204036 204037 204038

18 Stator w/ Casing 208V, 3PH 200525 200529 200533 200537 200670 - - -

18 Stator w/ Casing 230/460V, 3PH 200547 200551 200555 200559 200573 200577 200581 -

18 Stator w/ Casing 460V, 3PH - - - - - - - 200585

18 Stator w/ Casing 575V, 3PH 200589 200593 200597 200601 200617 200623 200630 200637

19 Wire Connection Kit* 204202 204202 204203 204203 204203 204203 CTF CTF

20 Upper Ball Bearing 200967 200967 200958 200958 200968 200968 200968 200968

20-1 O-Ring (Kit Only) - - - - Kit Kit Kit Kit

21A Oil Chamber/Motor Housing 202196 202196 203030 203030 202199 202199 203032 203032

21A-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit

26 Pump Top Cover (w/ Sensor Opening) 202435 202435 202437 202437 203129 203129 203131 203132

26-1 O-Ring Kit Only Kit Kit Kit Kit Kit Kit Kit Kit

27 Power Cable w/ Gland- 3PH(high temp) 201733 201733 203776 203776 203776 203776 203778 203778

27-1 O-Ring Kit Only Kit Kit Kit Kit Kit Kit Kit Kit

27-2 Seal Minder/Temp. Sensor Cord (High Temp) 2736BF 2736BF 2736BF 2736BF 2736BF 2736BF 2736BF 2736BF

27-2-1 O-Ring Kit Only Kit Kit Kit Kit Kit Kit Kit Kit
