Appendices
724-746-5500 | blackbox.com
Page 41
Serial remote control and flash upgrade cable (8p8c)
8p8c
connector
D-Type female
9 way
62
TXD RXD
3
2
3
5
RXD
GND
TXD
GND
Serial remote control and flash upgrade cable (10p10c)
10p10c
connector
D-Type female
9 way
72
TXD RXD
4
3
3
5
RXD
GND
TXD
GND
Appendix C. Cable pin-outs
The OPTIONS port uses a 10p10c socket which can accommodate both 10p10c connectors as well as the much more common
8p8c connectors, which are used on Ethernet leads and patch cables. The pin-outs are listed in this section for both types of
connectors.
