1. Introduction 1-1. Overview of LGB1005A-R2 LGB1005A-R2, a 24-port Gigabit L2 Plus Managed Switch, is a standard switch that meets all IEEE 802.3/u/x/z Gigabit, Fast Ethernet specifications. 16-Port 1000Mbps SFP and 8-Port Combo Gigabit TP/SFP Fiber dual media management Ethernet switch. The switch can be managed through RS-232 serial port via directly connection, or through Ethernet port using CLI or Web-based management unit, associated with SNMP agent.
• Key Features in the Device QoS: Support Quality of Service by the IEEE 802.1P standard. There are two priority queue and packet transmission schedule. Spanning Tree: Support IEEE 802.1D, IEEE 802.1w (RSTP: Rapid Spanning Tree standards. Protocol) VLAN: Support Port-based VLAN and IEEE802.1Q Tag VLAN. Support 256 active VLANs and VLAN ID 1~4094. Port Trunking: Support static port trunking and port trunking with IEEE 802.3ad LACP. Bandwidth Control: Support ingress and egress per port bandwidth control.
• none of its other hosts belong, sends unsolicited group membership reports to that group. When the last of its hosts in a particular multicast group leaves the group, sends an unsolicited leave group membership report to the all-routers group (244.0.0.2).
1-2. Checklist Before you start installing the switch, verify that the package contains the following: ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ LGB1005A-R2 24-port Layer 2 plus Gigabit Managed Switch SFP Modules (optional) Mounting Accessory (for 19” Rack Shelf) This User's Manual in CD-ROM AC Power Cord RS-232 Cable Please notify your sales representative immediately if any of the aforementioned items is missing or damaged. 1-3.
• Supports 802.
1-4. View of LGB1005A-R2 Fig. 1-1 Full View of LGB1005A-R2 1-4-1. User Interfaces on the Front Panel (Button, LEDs and Plugs) There are 8 TP Gigabit Ethernet ports and 24 SFP fiber ports for optional removable modules on the front panel of the switch. LED display area, locating on the left side of the panel, contains a Power LED, which indicates the power status and 24 ports working status of the switch. One RS-232 DB-9 interface is offered for configuration or management.
• LED Indicators LED POWER Color System LED Green Function Lit when +5V DC power is on and good 10/100/1000Ethernet TP Port 1 to 8 LED Lit when connection with remote device is good Green Blinks when any traffic is present LINK/ACT Off when cable connection is not good Lit green when 1000Mbps speed is active Green/ Lit ember when 100Mbps speed is active 10/100/1000Mbps Amber Off when 10Mbps speed is active 1000SX/LX Gigabit Fiber Port 1, 24 LED Lit when connection with the remote device is good SFP(LIN
1-5. View of the Optional Modules In the switch, Port 1~ 8 includes two types of media --- TP and SFP Fiber (LC, BiDi LC…); this port supports 10/100/1000Mbps TP or 1000Mbps SFP Fiber with autodetected function.
2. Installation 2-1. Starting LGB1005A-R2 Up This section will give users a quick start for: - Hardware and Cable Installation - Management Station Installation - Software booting and configuration 2-1-1.
• TP Port and Cable Installation ⇒ In the switch, TP port supports MDI/MDI-X auto-crossover, so both types of cable, straight-through and crossed-over can be used. It means you do not have to tell from them, just plug it. ⇒ Use Cat. 5 grade RJ-45 TP cable to connect to a TP port of the switch and the other end is connected to a network-aware device such as a workstation or a server. ⇒ Repeat the above steps, as needed, for each RJ-45 port to be connected to a Gigabit 10/100/1000 TP device.
2-1-2. Installing Chassis to a 19-Inch Wiring Closet Rail Fig. 2-2 Caution: Allow a proper spacing and proper air ventilation for the cooling fan at both sides of the chassis. ⇒ Wear a grounding device for electrostatic discharge. ⇒ Screw the mounting accessory to the front side of the switch (See Fig. 2-2). ⇒ Place the Chassis into the 19-inch wiring closet rail and locate it at the proper position. Then, fix the Chassis by screwing it. 2-1-3.
2-1-3-1. Cabling Requirements for TP Ports ⇒ For Fast Ethernet TP network connection ⎯ The grade of the cable must be Cat. 5 or Cat. 5e with a maximum length of 100 meters. ⇒ Gigabit Ethernet TP network connection ⎯ The grade of the cable must be Cat. 5 or Cat. 5e with a maximum length of 100 meters. Cat. 5e is recommended. 2-1-3-2. Cabling Requirements for 1000SX/LX SFP Module It is more complex and comprehensive contrast to TP cabling in the fiber media.
2-1-3-3. Switch Cascading in Topology • Takes the Delay Time into Account Theoretically, the switch partitions the collision domain for each port in switch cascading that you may up-link the switches unlimitedly. In practice, the network extension (cascading levels & overall diameter) must follow the constraint of the IEEE 802.3/802.3u/802.3z and other 802.1 series protocol specifications, in which the limitations are the timing requirement from physical signals defined by 802.
Case1: All switch ports are in the same local area network. Every port can access each other (See Fig. 2-3). Fig. 2-3 No VLAN Configuration Diagram If VLAN is enabled and configured, each node in the network that can communicate each other directly is bounded in the same VLAN area. Here VLAN area is defined by what VLAN you are using. The switch supports both port-based VLAN and tag-based VLAN. They are different in practical deployment, especially in physical location.
Case 2b: Port-based VLAN (See Fig.2-5). Fig. 2-5 Port-based VLAN Diagram 1. VLAN1 members could not access VLAN2, VLAN3 and VLAN4 members. 2. VLAN2 members could not access VLAN1 and VLAN3 members, but they could access VLAN4 members. 3. VLAN3 members could not access VLAN1, VLAN2 and VLAN4. 4. VLAN4 members could not access VLAN1 and VLAN3 members, but they could access VLAN2 members. Case3a: The same VLAN members can be at different switches with the same VID (See Fig. 2-6). Fig.
2-1-4. Configuring the Management Agent of LGB1005A-R2 We offer you three ways to startup the switch management function. They are RS232 console, CLI, and Web. Users can use any one of them to monitor and configure the switch. You can touch them through the following procedures.
2-1-4-1. Configuring the Management Agent of LGB1005A-R2 through the Serial RS232 Port To perform the configuration through RS-232 console port, the switch’s serial port must be directly connected to a DCE device, for example, a PC, through RS-232 cable with DB-9 connector. Next, run a terminal emulator with the default setting of the switch’s serial port. With this, you can communicate with the switch.
• Set IP Address, Subnet Mask and Default Gateway IP Address Please refer to Fig. 2-7 CLI Management for details about ex-factory IP setting. They are default setting of IP address. You can first either configure your PC IP address or change IP address of the switch, next to change the IP address of default gateway and subnet mask. For example, your network address is 10.1.1.0, and subnet mask is 255.255.255.0. You can change the switch’s default IP address 192.168.1.1 to 10.1.1.
2-1-4-2. Configuring the Management Agent of LGB1005A-R2 through the Ethernet Port There are three ways to configure and monitor the switch through the switch’s Ethernet port. They are CLI, Web browser and SNMP manager. The user interface for the last one is NMS dependent and does not cover here. We just introduce the first two types of management interface. LGB1005A-R2 L2 Managed Switch Default IP Setting: IP = 192.168.1.1 Subnet Mask = 255.255.255.0 Default Gateway = 192.168.1.
Fig. 2-10 the Login Screen for Web 2-1-5. IP Address Assignment For IP address configuration, there are three parameters needed to be filled in. They are IP address, Subnet Mask, Default Gateway and DNS. IP address: The address of the network device in the network is used for internetworking communication. Its address structure looks is shown in the Fig. 2-11. It is “classful” because it is split into predefined address classes or categories.
With the classful addressing, it divides IP address into three classes, class A, class B and class C. The rest of IP addresses are for multicast and broadcast. The bit length of the network prefix is the same as that of the subnet mask and is denoted as IP address/X, for example, 192.168.1.0/24. Each class has its address range described below. Class A: Address is less than 126.255.255.255. There are a total of 126 networks can be defined because the address 0.0.0.0 is reserved for default route and 127.0.
Class D and E: Class D is a class with first 4 MSB (Most significance bit) set to 1-1-1-0 and is used for IP Multicast. See also RFC 1112. Class E is a class with first 4 MSB set to 1-1-1-1 and is used for IP broadcast. According to IANA (Internet Assigned Numbers Authority), there are three specific IP address blocks reserved and able to be used for extending internal network. We call it Private IP address and list below: Class A Class B Class C 10.0.0.0 --- 10.255.255.255 172.16.0.0 --- 172.31.255.
In this diagram, you can see the subnet mask with 25-bit long, 255.255.255.128, contains 126 members in the sub-netted network. Another is that the length of network prefix equals the number of the bit with 1s in that subnet mask. With this, you can easily count the number of IP addresses matched. The following table shows the result. Prefix Length No. of IP matched No.
For different network applications, the subnet mask may look like 255.255.255.240. This means it is a small network accommodating a maximum of 15 nodes in the network. Default gateway: For the routed packet, if the destination is not in the routing table, all the traffic is put into the device with the designated IP address, known as default router. Basically, it is a routing policy. The gateway setting is used for Trap Events Host only in the switch.
2-2. Typical Applications The LGB1005A-R2 implements 8 Gigabit Ethernet TP ports with auto MDIX and two slots for the removable module supporting comprehensive fiber types of connection, including LC and BiDi-LC SFP modules. For more details on the specification of the switch, please refer to Appendix A. ⎯ ⎯ ⎯ The switch is suitable for the following applications. Central Site/Remote site application is used in carrier or ISP (See Fig. 2-13) Peer-to-peer application is used in two remote offices (See Fig.
Fig. 2-14 Peer-to-peer Network Connection Fig.
3. Operation of Web-based Management This chapter instructs you how to configure and manage the LGB1005A-R2 through the web user interface it supports, to access and manage the 16-Port Gigabit SFP and 8-Port Gigabit TP/SFP Fiber management Ethernet switch.
To optimize the display effect, we recommend you use Microsoft IE 6.0 above, Netscape V7.1 above or FireFox V1.00 above and have the resolution 1024x768. The switch supported neutral web browser interface. In Fig. 3-2, for example, left section is the whole function tree with web user interface and we will travel it through this chapter. Fig.
3-1. Web Management Home Overview After you login, the switch shows you the system information as Fig. 3-2. This page is default and tells you the basic information of the system, including “Model Name”, “System Description”, “Location”, “Contact”, “Device Name”, “System Up Time”, “Current Time”, “BIOS Version”, “Firmware Version”, “Hardware-Mechanical Version”, “Serial Number”, “Host IP Address”, “Host Mac Address”, “Device Port”, “RAM Size” and “Flash Size”.
• The Information of Page Layout ⎯ On the top side, it shows the front panel of the switch. In the front panel, the linked ports will display green; as to the ports, which are link off, they will be dark. For the optional modules, the slot will show only a cover plate if no module exists and will show a module if a module is present. The image of module depends on the one you inserted. The same, if disconnected, the port will show just dark, if linked, green. (See Fig. 3-3) Fig.
Root System Port VLAN MAC GVRP QoS SNMP ACL IP MAC Binding 802.
3-1-1. System Information Function name: System Information Function description: Show the basic system information. Parameter description: Model name: The model name of this device. System description: As it is, this tells what this device is. Here, it is “L2 Plus Managed Switch”. Location: Basically, it is the location where this switch is put. User-defined. Contact: For easily managing and maintaining device, you may write down the contact person and phone here for getting help soon.
Host IP address: The IP address of the switch. Host MAC address: It is the Ethernet MAC address of the management agent in this switch. Device Port: Show all types and numbers of the port in the switch. RAM size: The size of the DRAM in this switch. Flash size: The size of the flash memory in this switch. Fig.
3-1-2. Account Configuration In this function, only administrator can create, modify or delete the username and password. Administrator can modify other guest identities’ password without confirming the password but it is necessary to modify the administrator-equivalent identity. Guestequivalent identity can modify his password only. Please note that you must confirm administrator/guest identity in the field of Authorization in advance before configuring the username and password.
3-1-3. Time Configuration The switch provides manual and automatic ways to set the system time via NTP. Manual setting is simple and you just input “Year”, “Month”, “Day”, “Hour”, “Minute” and “Second” within the valid value range indicated in each item. If you input an invalid value, for example, 61 in minute, the switch will clamp the figure to 59. NTP is a well-known protocol used to synchronize the clock of the switch system time over a network.
NTP: NTP is Network Time Protocol and is used to sync the network time based Greenwich Mean Time (GMT). If use the NTP mode and select a built-in NTP time server or manually specify an user-defined NTP server as well as Time Zone, the switch will sync the time in a short after pressing button. Though it synchronizes the time automatically, NTP does not update the time periodically without user’s processing. Time Zone is an offset time off GMT.
Day Light Saving End : This is used to set when to stop performing the daylight saving time. Mth: Range is 1 ~ 12. Default: 1 Day: Range is 1 ~ 31. Default: 1 Hour: Range is 0 ~ 23. Default: 0 Fig.
3-1-4. IP Configuration IP configuration is one of the most important configurations in the switch. Without the proper setting, network manager will not be able to manage or view the device. The switch supports both manual IP address setting and automatic IP address setting via DHCP server. When IP address is changed, you must reboot the switch to have the setting taken effect and use the new IP to browse for web management and CLI management. Fig.
IP address: Users can configure the IP settings and fill in new values if users set the DHCP function “Disable”. Then, click button to update. When DHCP is disabled, Default: 192.168.1.1 If DHCP is enabled, this field is filled by DHCP server and will not allow user manually set it any more.
DNS: It is Domain Name Server used to serve the translation between IP address and name address. The switch supports DNS client function to re-route the mnemonic name address to DNS server to get its associated IP address for accessing Internet. User can specify a DNS IP address for the switch. With this, the switch can translate a mnemonic name address into an IP address. There are two ways to specify the IP address of DNS.
3-1-5. Loop Detection The loop detection is used to detect the presence of traffic. When switch receives packet’s(looping detection frame) MAC address the same as oneself from port, show Loop detection happens. The port will be locked when it received the looping detection frames. If you want to resume the locked port, please find out the looping path and take off the looping path, then select the resume the locked port and click on “Resume” to turn on the locked ports. Fig.
3-1-6. Management Policy Through the management security configuration, the manager can do the strict setup to control the switch and limit the user to access this switch. The following rules are offered for the manager to manage the switch: Rule 1) : When no lists exists, then it will accept all connections.
Function name: Management Security Configuration Function description: The switch offers Management Security Configuration function. With this function, the manager can easily control the mode that the user connects to the switch. According to the mode, users can be classified into two types: Those who are able to connect to the switch (Accept) and those who are unable to connect to the switch (Deny).
The switch supports two kinds of options for managed valid VLAN VID, including “Any” and “Custom”. Default is “Any”. When you choose “Custom”, you can fill in VID number. The valid VID range is 1~4094. IP Range: The switch supports two kinds of options for managed valid IP Range, including “Any” and “Custom”. Default is “Any”. In case that” Custom” had been chosen, you can assigned effective IP range. The valid range is 0.0.0.0~255.255.255.255.
3-1-7. Virtual Stack Function name: Virtual Stack Function description: Virtual Stack Management(VSM) is the group management function. Through the proper configuration of this function, switches in the same LAN will be grouped automatically. And among these switch, one switch will be a master machine, and the others in this group will become the slave devices. VSM offers a simple centralized management function.
Parameter description: State: It is used for the activation or de-activation of VSM. Default is Enable. Role: The role that the switch would like to play in virtual stack. Two types of roles, including master and slave are offered for option. Default is Master. Group ID: It is the group identifier (GID) which signs for VSM. Valid letters are A-Z, a-z, 0-9, “ - “ and “_” characters. The maximal length is 15 characters.
3-1-8. System Log The System Log provides information about system logs, including information when the device was booted, how the ports are operating, when users logged in, when sessions timed out, as well as other system information. Fig. 3-11 Function name: System Log Function description: The Trap Log Data is displaying the log items including all SNMP Private Trap events, SNMP Public traps and user logs occurred in the system. In the report table, No.
3-2. Port Configuration Four functions, including Port Status, Port Configuration, Simple Counter and Detail Counter are contained in this function folder for port monitor and management. Each of them will be described in detail orderly in the following sections.
3-2-1. Port Configuration Port Configuration is applied to change the setting of each port. In this configuration function, you can set/reset the following functions. All of them are described in detail below. Fig. 3-12 Function name: Port Configuration Function description: It is used to set each port’s operation mode. The switch supports 3 parameters for each port. They are state, mode and flow control. Parameter description: Speed: Set the speed and duplex of the port.
Flow Control: There are two modes to choose in flow control, including Enable and Disable. If flow control is set Enable, both parties can send PAUSE frame to the transmitting device(s) if the receiving port is too busy to handle. When it is set Disable, there will be no flow control in the port. It drops the packet if too much to handle. Maximum Frame: This module offer 1518~9600 (Bytes) length to make the long packet.
3-2-2.Port Status The function Port Status gathers the information of all ports’ current status and reports it by the order of port number, media, link status, port state, AutoNegotiation status, speed/duplex, Rx Pause and Tx Pause. An extra media type information for the module ports 1 and 8 is also offered (See Fig. 3-14). Fig. 3-13 Function name: Port Status Function Description: Report the latest updated status of all ports in this switch.
Link: Show that if the link on the port is active or not. If the link is connected to a working-well device, the Link will show the link “Up”; otherwise, it will show “Down”. This is determined by the hardware on both devices of the connection. No default value. Speed / Duplex Mode: Display the speed and duplex of all port. There are three speeds 10Mbps, 100Mbps and 1000Mbps supported for TP media, and the duplex supported is half duplex and full duplex.
Parameter description of Port 1 ~ Port 24: Connector Type: Display the connector type, for instance, UTP, SC, ST, LC and so on. Fiber Type: Display the fiber mode, for instance, Multi-Mode, Single-Mode. Tx Central Wavelength: Display the fiber optical transmitting central wavelength, for instance, 850nm, 1310nm, 1550nm and so on. Baud Rate: Display the maximum baud rate of the fiber module supported, for instance, 10M, 100M, 1G and so on.
3-2-3. Simple Counter The function of Simple Counter collects any information and provides the counting about the traffic of the port, no matter the packet is good or bad. In the Fig. 3-15, the window can show all ports’ counter information at the same time. Each data field has 20-digit long. If the counting is overflow, the counter will be reset and restart counting. The data is updated every time interval defined by the user. The Refresh Interval is used to set the update frequency. Fig.
Receive: Total received bytes. Error: Transmit: Number of bad packets transmitted. Receive: Number of bad packets received. Drops: Transmit: Number of packets transmitted drop. Receive: Number of packets received drop. Auto-refresh: The simple counts will be refreshed automatically on the UI screen. Refresh: The simple counts will be refreshed manually when user use mouse to click on “Refresh” button. Clear: The simple counts will be reset to zero when user use mouse to click on “Clear” button.
3-2-4. Detail Counter The function of Detail Counter collects any information and provides the counting about the traffic of the port, no matter the packet is good or bad. In the Fig. 3-16, the window can show only one port counter information at the same time. To see another port’s counter, you have to pull down the list of Select, then you will see the figures displayed about the port you had chosen. Each data field has 20-digit long.
Rx Low Priority Packets: Number of Rx packets classified as low priority. Rx Broadcast: Show the counting number of the received broadcast packet. Rx Multicast: Show the counting number of the received multicast packet. Tx Packets: The counting number of the packet transmitted. TX Octets: Total transmitted bytes. Tx High Priority Packets: Number of Tx packets classified as high priority. Tx Low Priority Packets: Number of Tx packets classified as low priority.
Tx 65-127 Bytes: Number of 65 ~ 126-byte frames in good and bad packets transmitted. Tx 128-255 Bytes: Number of 127 ~ 255-byte frames in good and bad packets transmitted. Tx 256-511 Bytes: Number of 256 ~ 511-byte frames in good and bad packets transmitted. Tx 512-1023 Bytes: Number of 512 ~ 1023-byte frames in good and bad packets transmitted. Tx 1024-Bytes: Number of 1024-max_length-byte frames in good and bad packets transmitted.
click on “Refresh” button. Clear: The detail counts will be reset to zero when user use mouse to click on “Clear” button.
3-3. VLAN The switch supports Tag-based VLAN (802.1Q) and Port-based VLAN. Support 4094 active VLANs and VLAN ID 1~4094. VLAN configuration is used to partition your LAN into small ones as your demand. Properly configuring it, you can gain not only improving security and increasing performance but greatly reducing VLAN management. 3-3-1.
3-3-2. Tag-based Group Function name: Tag-based Group Configuration Function description: It shows the information of existed Tag-based VLAN Groups, You can also easily create, edit and delete a Tag-based VLAN group by pressing , and function buttons. User can add a new VLAN group by inputting a new VLAN name and VLAN ID. Parameter description: VLAN Name: The name defined by administrator is associated with a VLAN group. Valid letters are A-Z, a-z, 0-9, “ - “ and “_” characters.
Fig. 3-18 Add new VLAN: Please click on to create a new Tag-based VLAN. Input the VLAN name as well as VID, configure the SYM-VLAN function and choose the member by ticking the check box beside the port No., then, press the button to have the setting taken effect. Fig. 3-19 Delete Group: Just press the button to remove the selected group entry from the Tag-based group table. Fig.
Note: If you need use PVLAN( Private VLAN) function on Switch then you need follow up the process as below: a. Create a VLAN as primary VLAN and the VLAN ID is 2 and evoke the Private VLAN to enable Private VLAN service. b. Assign port member to the VLAN2 c. Fig. 3-20-1 You need to assign these ports for member of port isolation. d. Press the “Save” to complete the PVLAN configuration process.
3-3-3. Port-based Group Function name: Port-based Group Configuration Function description: It shows the information of the existed Port-based VLAN Groups. You can easily create, edit and delete a Port-based VLAN group by pressing , and function buttons. User can add a new VLAN group by inputting a new VLAN name. Parameter description: VLAN Name: The name defined by administrator is associated with a VLAN group. Valid letters are A-Z, a-z, 0-9, “ - “ and “_” characters.
Delete Group: Just press the button to remove the selected group entry from the Port-based group table. Fig.
3-3-4. Ports Function name: VLAN Port Configuration Function description: In VLAN Tag Rule Setting, user can input VID number to each port. The range of VID number is from 1 to 4094. User also can choose ingress filtering rules to each port. There are two ingress filtering rules which can be applied to the switch. The Ingress Filtering Rule 1 is “forward only packets with VID matching this port’s configured VID”. The Ingress Filtering Rule 2 is “drop untagged frame”.
Fig.
3-3-5. Management Function name: Management Function description: To assign a specific VLAN for management purpose. Parameter description: VID: Specific Management VLAN ID. Fig.
3-4. MAC MAC Table Configuration gathers many functions, including MAC Table Information, MAC Table Maintenance, Static Forward, Static Filter and MAC Alias, which cannot be categorized to some function type. They are described below. 3-4-1. Mac Address Table Function name: MAC Address Table Information Function Description: This function can allow the user to set up the processing mechanism of MAC Table. An idle MAC address exceeding MAC Address Age-out Time will be removed from the MAC Table.
Fig.
3-4-2. Static Filter Function name: Static Filter Function Description: Static Filter is a function that denies the packet forwarding if the packet’s MAC Address is listed in the filtering Static Filter table. User can very easily maintain the table by filling in MAC Address, VID (VLAN ID) and Alias fields individually. User also can delete the existed entry by clicking button.
3-4-3. Static Forward Function Name: Static Forward Function Description: Static Forward is a function that allows the user in the static forward table to access a specified port of the switch. Static Forward table associated with a specified port of a switch is set up by manually inputting MAC address and its alias name. When a MAC address is assigned to a specific port, all of the switch’s traffics sent to this MAC address will be forwarded to this port.
3-4-4. MAC Alias Function name: MAC Alias Function description: MAC Alias function is used to let you assign MAC address a plain English name. This will help you tell which MAC address belongs to which user in the illegal access report. At the initial time, it shows all pairs of the existed alias name and MAC address. There are three MAC alias functions in this function folder, including MAC Alias Add, MAC Alias Edit and MAC Alias Delete.
3-4-5. MAC Table Function name: Dynamic MAC Table Function Description: Display the static or dynamic learning MAC entry and the state for the selected port. Parameter description: Type: Dynamic or Static. VLAN: VLAN identifier. This will be filled only when tagged VLAN is applied. Valid range is 1 ~ 4094. MAC address: Display the MAC address of one entry you selected from the searched MAC entries table. Port: The port that exists in the searched MAC Entry.
3-5. GVRP GVRP is an application based on Generic Attribute Registration Protocol (GARP), mainly used to automatically and dynamically maintain the group membership information of the VLANs. The GVRP offers the function providing the VLAN registration service through a GARP application. It makes use of GARP Information Declaration (GID) to maintain the ports associated with their attribute database and GARP Information Propagation (GIP) to communicate among switches and end stations.
Default Applicant Mode: The mode here means the type of participant. There are two modes, normal participant and non-participant, provided for the user’s choice. Normal: It is Normal Participant. In this mode, the switch participates normally in GARP protocol exchanges. The default setting is Normal. Non-Participant: It is Non-Participant. In this mode, the switch does not send or reply any GARP messages. It just listens messages and reacts for the received GVRP BPDU.
Fig.
3-5-2. Counter Function name: GVRP Counter Function description: All GVRP counters are mainly divided into Received and Transmitted two categories to let you monitor the GVRP actions. Actually, they are GARP packets. Fig. 3-32 Parameter description: Received: Total GVRP Packets: Total GVRP BPDU is received by the GVRP application. Invalid GVRP Packets: Number of invalid GARP BPDU is received by the GARP application.
Empty Message Packets: Number of GARP BPDU with Empty message is received by the GARP application. Transmitted: Total GVRP Packets: Total GARP BPDU is transmitted by the GVRP application. Invalid GVRP Packets: Number of invalid GARP BPDU is transmitted by the GVRP application. LeaveAll Message Packets: Number of GARP BPDU with Leave All message is transmitted by the GARP application. JoinEmpty Message Packets: Number of GARP BPDU with Join Empty message is transmitted by the GARP application.
3-5-3. Group Function name: GVRP Group VLAN Information Function description: To show the dynamic group member and their information. Parameter description: VID: VLAN identifier. When GVRP group creates, each dynamic VLAN group owns its VID. Valid range is 1 ~ 4094. Member Port: Those are the members belonging to the same dynamic VLAN group. Edit Administrative Control: When you create GVRP group, you can use Administrative Control function to change Applicant Mode and Registrar Mode of GVRP group member.
3-6. QoS(Quality of Service) Configuration The switch support four QoS queues per port with strict or weighted fair queuing scheduling. There are 24 QoS Control Lists (QCL) for advance programmable QoS classification, based on IEEE 802.1p, Ethertype, VID, IPv4/IPv6 DSCP and UDP/TCP ports and ranges. High flexibility in the classification of incoming frames to a QoS class.
class values for VLAN tagged or priority tagged frames. Queuing Mode: There are two Scheduling Method, Strict Priority and Weighted Fair. Default is Strict Priority. After you choose any of Scheduling Method, please click Apply button to be in operation. Queue Weighted: There are four queues per port and four classes weighted number (1 / 2 / 4 / 8) for each queues, you can select the weighted number when the scheduling method be set to “Weighted Fair” mode. Fig.
3-6-2. Qos Control List Function name: Qos Control List Configuration Function description: The switch support four QoS queues per port with strict or weighted fair queuing scheduling. There are 24 QoS Control Lists (QCL) for advance programmable QoS classification, based on IEEE 802.1p, Ether Type, VID, IPv4/IPv6 DSCP and UDP/TCP ports and ranges. Fig.
QCE Configuration: The QCL consists of 12 QoS Control Entries (QCEs) that are searched from the top of the list to the bottom of the list for a match. The first matching QCE determines the QoS classification of the frame. The QCE ordering is therefore important for the resulting QoS classification algorithm. If no matching QCE is found, the default QoS class is used in the port QoS configuration. Fig. 3-36 Fig. 3-37 Fig.
Fig. 3-39 Fig. 3-40 Fig.
Fig. 3-42 Parameter description: QCL#: QCL number : 1~24 QCE Type: Ethernet Type / VLAN ID / UDP/TCP Port / DSCP / ToS / Tag Priority Ethernet Type Value: The configurable range is 0x600~0xFFFF. Well known protocols already assigned EtherType values. The commonly used values in the EtherType field and corresponding protocols are listed below: Ethertype (Hexadecimal) Protocol 0x0800 IP, Internet Protocol 0x0801 X.75 Internet 0x0802 NBS Internet 0x0803 ECMA Internet 0x0804 Chaosnet 0x0805 X.
0x6559 Raw Frame Relay [RFC1701] 0x8035 DRARP, Dynamic RARP. RARP, Reverse Address Resolution Protocol. 0x8037 Novell Netware IPX 0x809B EtherTalk (AppleTalk over Ethernet) 0x80D5 IBM SNA Services over Ethernet 0x 80F3 AARP, AppleTalk Address Resolution Protocol. 0x8100 IEEE Std 802.1Q - Customer VLAN Tag Type. 0x8137 IPX, Internet Packet Exchange. 0x 814C SNMP, Simple Network Management Protocol. 0x86DD IPv6, Internet Protocol version 6. 0x880B PPP, Point-to-Point Protocol.
UDP/TCP Port Range: The configurable ports range: 0~65535 You can refer to following UDP/TCP port-numbers information. http://www.iana.org/assignments/port-numbers UDP/TCP Port No.
3-6-3.Rate Limiters Function name: Rate Limit Configuration Function description: Each port includes an ingress policer, and an egress shaper, which can limit the bandwidth of received and transmitted frames. Ingress policer or egress shaper operation is controlled per port in the Rate Limit Configuration. Fig. 3-43 Parameter description: Port #: Port number. Policer Enabled: Policer enabled to limit ingress bandwidth by policer rate.
Policer Rate: The configurable policer rate range: 500 Kbps ~ 1000000 Kbps 1 Mbps ~ 1000 Mbps Policer Unit: There are two units for ingress policer rate limit: kbps / Mbps Shaper Enabled: Shaper enabled to limit egress bandwidth by shaper rate.
3-6-4.Storm Control Function name: Storm Control Configuration Function description: The switch support storm ingress policer control function to limit the Flooded, Multicast and Broadcast to prevent storm event happen.
3-6-5.Wizard Function name: Wizard Function description: The QCL configuration Wizard is targeted on user can easy to configure the QCL rules for QoS configuration. The wizard provide the typical network application rules, user can apply these application easily. Fig.
Fig. 3-46 Set up Port Policies Parameter description: QCL ID: QoS Control List (QCL): 1~24 Port Member: Port Member: 1~24 Fig. 3-47 Set up Port Policies Parameter description: Wizard Again: Click on the , back to QCL Configuration Wizard. Finish: When you click on , the parameters will be set according to the wizard configuration and shown on the screen, then ask you to click on for changed parameters confirmation.
Fig. 3-48 Set up Port Policies Finish Fig. 3-49 Set up Typical Network Application Rules Fig.
Fig.
Fig. 3-52 Set up Typical Network Application Rules Parameter description: QCL ID: QCL ID Range: 1~24 Traffic Class: There are four classes: Low / Normal / Medium / High Fig.
Fig. 3-54 Set up Typical Network Application Rules Finish Fig.
Fig. 3-56 Set up Typical Network Application Rules Finish Parameter description: QCL #: QoS Control List (QCL): 1~24 Fig.
Parameter description: QCL ID: QoS Control List (QCL): 1~24 TOS Precedence 0~7 Class: Low / Normal / Medium / High Fig. 3-58 Set up TOS Precedence Mapping Fig.
Fig. 3-60 Set up VLAN Tag Priority Mapping Parameter description: QCL ID: QoS Control List (QCL): 1~24 Tag Priority 0~7 Class: Low / Normal / Medium / High Fig.
Fig.
3-7. SNMP Configuration Any Network Management System (NMS) running the Simple Network Management Protocol (SNMP) can manage the Managed devices equipped with SNMP agent, provided that the Management Information Base (MIB) is installed correctly on the managed devices. The SNMP is a protocol that is used to govern the transfer of information between SNMP manager and agent and traverses the Object Identity (OID) of the management Information Base (MIB), described in the form of SMI syntax.
Default SNMP function : Enable Default community name for GET: public Default community name for SET: private Default community name for Trap: public Default Set function : Enable Default trap host IP address: 0.0.0.0 Default port number :162 Trap: In the switch, there are 6 trap hosts supported. Each of them has its own community name and IP address; is user-definable. To set up a trap host means to create a trap manager by assigning an IP address to host the trap message.
3-8. ACL The LGB1005A-R2 switch access control list (ACL) is probably the most commonly used object in the IOS. It is used for packet filtering but also for selecting types of traffic to be analyzed, forwarded, or influenced in some way. The ACLs are divided into EtherTypes. IPv4, ARP protocol, MAC and VLAN parameters etc. Here we will just go over the standard and extended access lists for TCP/IP.
Counter: The counter will increase from initial value 0, when this port received one of the met ACL packet the counter value will increase +1 Fig.
3-8-2.Rate Limiters Function name: ACL Rate Limiter Configuration Function description: There are 16 rate limiter ID. You can assign one of the limiter ID for each port. The rate limit configuration unit is Packet Per Second (pps). Parameter description: Rate Limiter ID: ID Range: 1~16 Rate(pps): 1 / 2 / 4 / 8 / 16 / 32 / 64 / 128 / 256 / 512 / 1K / 2K / 4K / 8K / 16K / 32K / 64K / 128K / 256K / 512K / 1024K Fig.
3-8-3.Access Control List Function name: ACL Rate Limiter Configuration Function description: The switch ACL function support up to 128 Access Control Entries (ACEs), using the shared 128 ACEs for ingress classification. You can create an ACE and assign this ACE for each port with or assign this ACE for a policy or assign this ACE for a port.
Fig. 3-67 Ingress Port Fig.
Parameter description: Frame Type: Range: Any / Ethernet Type / ARP / IPv4 Any: It is including all frame type Ethernet Type: It is including all Ethernet frame type ARP: It is including all ARP protocol frame type IPv4: It is including all IPv4 protocol frame type Fig.
Fig.
Fig. 3-71 Fig. 3-72 Fig.
Fig. 3-74 ARP Fig. 3-75 ARP Fig. 3-76 ARP Fig.
Fig. 3-78 ARP Fig. 3-79 ARP Fig. 3-80 ARP Fig.
Fig. 3-82 ARP Fig. 3-83 ARP Fig. 3-84 ARP Fig. 3-85 ARP Fig.
Fig. 3-87 IPv4 Fig. 3-88 IPv4 Fig.
Fig. 3-90 IPv4 Fig. 3-91 IPv4 Fig. 3-92 IPv4 Fig. 3-93 IPv4 Fig.
Fig. 3-95 IPv4 Fig. 3-96 IPv4 Fig. 3-97 IPv4 Fig. 3-98 IPv4 Fig.
Fig. 3-100 IPv4 Fig. 3-101 IPv4 Fig.
Fig. 3-103 IPv4 Fig. 3-104 IPv4 Fig.
Fig. 3-106 IPv4 Fig. 3-107 IPv4 Fig.
Fig. 3-109 IPv4 Fig. 3-110 IPv4 Fig.
Fig. 3-112 IPv4 Fig. 3-113 IPv4 Fig.
Fig. 3-115 IPv4 Fig. 3-116 IPv4 Fig.
Fig. 3-118 Rate Limiter Fig.
Fig. 3-120 DMAC Filter Fig. 3-121 VLAN ID Filter Fig.
Fig. 3-123 Tag Priority Function name: ACE Configuration Function description: The switch ACL function support up to 128 Access Control Entries (ACEs), using the shared 128 ACEs for ingress classification. You can create an ACE and assign this ACE for each port with or assign this ACE for a policy or assign this ACE for a port.
DMAC Filter: Range: Any / MC / BC / UC Any: It is including all destination MAC address MC: It is including all Multicast MAC address BC: It is including all Broadcast MAC address UC: It is including all Unicast MAC address MAC Parameters: (When Frame Type = Ethernet Type) SMAC Filter: Range: Any / Specific Any: It is including all source MAC address Specific: It is according to SMAC Value specific the source MAC address DMAC Filter: Range: Any / MC / BC / UC / Specific Any: It is including all destination
Ether Type Parameters: (When Frame Type = Ethernet Type) EtherType Filter: Range: Any / Specific Any: It is including all Ethernet frame type Specific: It is according to specific Ethernet Type Value.
0: The ingress ARP frames where the source MAC address is not equal SMAC under MAC parameter setting 1: The ingress ARP frames where the source MAC address is equal SMAC address under MAC parameter setting RARP DMAC Match: Range: Any / 0 / 1 Any: Both 0 and 1 0: The ingress RARP frames where the Destination MAC address is not equal DMAC address under MAC parameter setting 1: The ingress RARP frames where the Destination MAC address is equal DMAC address under MAC parameter setting IP/Ethernet Length: Range:
IPTTL: (Time To Live) How many routers a datagram can pass through. Each router decrements this value by 1 until it reaches 0 when the datagram is discarded. This keeps misrouted datagrams from remaining on the Internet forever Range: Any / Non-zero / Zero Any: Including all conditions for IPTTL Non-Zero: Including IPTTL is Non-Zero Zero: Including IPTTL is zero IP Fragment: (IP Fragmentation Flag) Controls datagram fragmentation together with the identification field.
Default: 192.168.1.254 DIP Mask: Default: 255.255.255.
Dest. Port No.: (Destination Port Number) Range: 0-65535 Dest. Port Range.: (Destination Port Range) Range: 0-65535 IP Parameters: (Frame Type = IPv4 and IP Protocol Filter = TCP) Source Port Filter: Range: Any / Specific / Range Any: Including all TCP source ports Specific: According to following Source Port No. setting for ingress classification Range: According to following Source Port Range setting for ingress classification Source Port No.: Range: 0-65535 Source Port Range.: Range: 0-65535 Dest.
0: The TCP control bit SYN is 0 1: The TCP control bit SYN is 1 TCP RST: TCP Control Bit RST: Means Reset the connection Range: Any / 0 / 1 Any: Including all TCP RST case 0: The TCP control bit RST is 0 1: The TCP control bit RST is 1 TCP PSH: TCP Control Bit PSH: Means Push Function Range: Any / 0 / 1 Any: Including all TCP PSH case 0: The TCP control bit PSH is 0 1: The TCP control bit PSH is 1 TCP ACK: TCP Control Bit ACK: Means Acknowledgment field significant Range: Any / 0 / 1 Any: Including all TCP
IP Protocol Value Default: 255 IPTTL: (Time To Live) How many routers a datagram can pass through. Each router decrements this value by 1 until it reaches 0 when the datagram is discarded. This keeps misrouted datagrams from remaining on the Internet forever Range: Any / Non-zero / Zero Any: Including all conditions for IPTTL Non-Zero: Including IPTTL is Non-Zero Zero: Including IPTTL is zero IP Fragment: (IP Fragmentation Flag) Controls datagram fragmentation together with the identification field.
Network: A specific IP subnet segment under the destination IP mask DIP Address: Default: 192.168.1.254 DIP Mask: Default: 255.255.255.
3-8-4.Wizard Function name: Wizard Function description: The wizard function is provide 4 type of typical application for user easy to configure their application with ACL function. Parameter description: Please select an Action: Set up Policy Rules / Set up Port Policies / Set up Typical Network Application Rules / Set up Source MAC and Source IP Binding Next: Click on to confirm current setting and go to next step automatically.
Fig. 3-125 Set up Policy Rules Fig. 3-126 Set up Policy Rules Fig.
Fig. 3-128 Set up Policy Rules Finish Fig. 3-129 Set up Port Policies Fig.
Fig. 3-131 Set up Port Policies Fig.
Fig. 3-133 Set up Typical Network Application Rules Fig.
Fig. 3-135 Set up Typical Network Application Rules Fig. 3-136 Set up Typical Network Application Rules Fig.
Instant Messaging: Google Talk / MSN Messenger / Yahoo Messenger User Definition: Ethernet Type / UDP Port / TCP Port Others: TCP Port / ICMP / Multicast IP Stream / NetBIOS / Ping Request / Ping Reply / SNMP / SNMP Traps Ingress Port: Any / Policy1-8 / Port1-24 Action: Permit / Deny Rate Limiter ID: Disabled / 1-16 Fig.
Fig. 3-139 Set up Source MAC and Source IP Binding Fig. 3-140 Set up Source MAC and Source IP Binding Fig.
Parameter description: Port #: 1-24 Binding Enabled: Use the switch ACL function to support IP/MAC Binding function, the maximum is up to 128 entries. Source MAC Address: xx-xx-xx-xx-xx-xx For example: 00-40-c7-00-00-01 Source IP Address: xxx.xxx.xxx.xxx For example: 192.168.1.
3-9. IP MAC Binding The IP network layer uses a four-byte address. The Ethernet link layer uses a six-byte MAC address. Binding these two address types together allows the transmission of data between the layers. The primary purpose of IP-MAC binding is to restrict the access to a switch to a number of authorized users. Only the authorized client can access the Switch’s port by checking the pair of IP-MAC Addresses and port number with the pre-configured database.
Delete: Select one of entry from the table, then click on to delete this entry. Fig.
3-10. 802.1X Configuration 802.1X port-based network access control provides a method to restrict users to access network resources via authenticating user’s information. This restricts users from gaining access to the network resources through a 802.1Xenabled port without authentication. If a user wishes to touch the network through a port under 802.
The overview of operation flow for the Fig. 3-53 is quite simple. When Supplicant PAE issues a request to Authenticator PAE, Authenticator and Supplicant exchanges authentication message. Then, Authenticator passes the request to RADIUS server to verify. Finally, RADIUS server replies if the request is granted or denied.
Authentication server C Authenticator B Fig. 3-54 Supplicant A The Fig. 3-55 shows the procedure of 802.1X authentication. There are steps for the login based on 802.1X port access control management. The protocol used in the right side is EAPOL and the left side is EAP. 1. At the initial stage, the supplicant A is unauthenticated and a port on switch acting as an authenticator is in unauthorized state. So the access is blocked in this stage. 2. Initiating a session.
8. If user ID and password is correct, the authentication server will send a Radius-Access-Accept to the authenticator. If not correct, the authentication server will send a Radius-Access-Reject. 9. When the authenticator PAE receives a Radius-Access-Accept, it will send an EAP-Success to the supplicant. At this time, the supplicant is authorized and the port connected to the supplicant and under 802.1X control is in the authorized state.
Only MultiHost 802.1X is the type of authentication supported in the switch. In this mode, for the devices connected to this port, once a supplicant is authorized, the devices connected to this port can access the network resource through this port. 802.1X Port-based Network Access Control function supported by the switch is little bit complex, for it just support basic Multihost mode, which can distinguish the device’s MAC address and its VID.
3-10-1.Server Function name: 802.1X Server Configuration Function description: This function is used to configure the global parameters for RADIUS authentication in 802.1X port security application. Parameter description: Authentication Server Server IP Server: Server IP address for authentication. Default: 192.168.1.1 UDP Port: Default port number is 1812. Secret Key: The secret key between authentication server and authenticator. It is a string with the length 1 – 31 characters.
Fig. 3-143 802.
3-10-2.Port Configuration Function name: 802.1X Port Configuration Function description: This function is used to configure the parameters for each port in 802.1X port security application. Refer to the following parameters description for details. Parameter description: Port: It is the port number to be selected for configuring its associated 802.1X parameters which are Port control, reAuthMax, txPeriod, Quiet Period, reAuthEnabled, reAuthPeriod, max.
the authentication server and the supplicant. Default: Auto reAuthMax(1-10): The number of authentication attempt that is permitted before the port becomes unauthorized. Default: 2 txPeriod(1-65535 s): A time period to transmitted EAPOL PDU between the authenticator and the supplicant. Default: 30 Quiet Period(0-65535 s): A period of time during which we will not attempt to access the supplicant. Deafult: 60 seconds reAuthEnabled: Choose whether regular authentication will take place in this port.
Fig. 3-144 802.1X Port Configuration 3-10-3.Status Function name: 802.1X Status Function description: Show the each port IEEE 802.1X authentication current operating mode and status. Parameter description: Port: Port number: 1-24 Mode: Show this port IEEE 802.1X operating mode: There are four modes Disable, Normal, Advance and Clientless Status: Show this port IEEE 802.
Fig. 3-145 802.
3-10-4. Statistics Function name: 802.1X Port Statistics Port1 Function description: Show the IEEE 802.1X authentication related counters for manager monitoring authenticator status. Parameter description: Port: Port Number: 1-24 Auto - refresh: Refresh the authenticator counters in the web UI automatically Refresh: Click on the to update the authenticator counters in the web UI Clear: Click on the to clear all authenticator counters in the web UI Fig. 3-146 802.
3-11. Trunking Configuration The Port Trunking Configuration is used to configure the settings of Link Aggregation. You can bundle more than one port with the same speed, full duplex and the same MAC to be a single logical port, thus the logical port aggregates the bandwidth of these ports. This means you can apply your current Ethernet equipments to build the bandwidth aggregation.
Per Trunking Group supports a maximum of 12 ready member-ports. Please note that some decisions will automatically be made by the system while you are configuring your trunking ports. Some configuration examples are listed below: a) 12 ports have already used Static Trunk Group ID 1, the 13th port willing to use the same Static Trunk Group ID will be automatically set to use the “None” trunking method and its Group ID will turn to 0. This means the port won’t aggregate with other ports.
3-11-1.Port Function name: Trunk Port Setting/Status Function description: Port setting/status is used to configure the trunk property of each and every port in the switch system. Parameter description: Port: Port Number: 1-24 Method: This determines the method a port uses to aggregate with other ports. None: A port does not want to aggregate with any other port should choose this default setting. LACP: A port use LACP as its trunk method to get aggregated with other ports also using LACP.
Aggtr: Aggtr is an abbreviation of “aggregator”. Every port is also an aggregator, and its own aggregator ID is the same as its own Port No. We can regard an aggregator as a representative of a trunking group. Ports with same Group ID and using same trunking method will have the opportunity to aggregate to a particular aggregator port. This aggregator port is usually the port with the smallest Port No. within the trunking group.
3-11-2 Aggregator View Function name: Aggregator View Function description: To display the current port trunking information from the aggregator point of view. Parameter description: Aggregator: It shows the aggregator ID (from 1 to 24) of every port. In fact, every port is also an aggregator, and its own aggregator ID is the same as its own Port No.. Method: Show the method a port uses to aggregate with other ports. Member Ports: Show all member ports of an aggregator (port).
3-11-3 ACP System Priority Function name: LACP System Priority Function description: It is used to set the priority part of the LACP system ID. LACP will only aggregate together the ports whose peer link partners are all on a single system. Each system supports LACP will be assigned a globally unique System Identifier for this purpose. A system ID is a 64-bit field comprising a 48-bit MAC Address and 16-bit priority value. The System Priority can be set by the user. Its range is from 1 to 65535.
3-12 STP Configuration The Spanning Tree Protocol (STP) is a standardized method (IEEE 802.1D) for avoiding loops in switched networks. When STP is enabled, ensure that only one path is active between any two nodes on the network at a time. User can enable Spanning Tree Protocol on switch’s web management and then set up other advanced items. We recommend that you enable STP on all switches to ensure a single active path on the network. 3-12-1.
All bridges in the LAN will re-learn and determine which the root bridge is. Maximum Age time is assigned by root bridge in unit of seconds. Default is 20 seconds. Current Forward Delay: Show the current root bridge forward delay time. The value of Forward Delay time is set by root. The Forward Delay time is defined as the time spent from Listening state moved to Learning state or from Learning state moved to Forwarding state of a port in bridge. Hello Time: Show the current hello time of the root bridge.
3-12-2. Configuration The STP, Spanning Tree Protocol, actually includes RSTP. In the Spanning Tree Configuration, there are six parameters open for the user to configure as user’s idea. Each parameter description is listed below. Function name: STP Configuration Function description: User can set the following Spanning Tree parameters to control STP function enable/disable, select mode RSTP/STP and affect STP state machine behavior to send BPDU in this switch.
Forward Delay: You can set the root bridge forward delay time. This figure is set by root bridge only. The forward delay time is defined as the time spent from Listening state moved to Learning state and also from Learning state moved to Forwarding state of a port in bridge. The forward delay time contains two states, Listening state to Learning state and Learning state to Forwarding state. It assumes that forward delay time is 15 seconds, then total forward delay time will be 30 seconds.
3-12-3. STP Port Configuration Function name: STP Port Setting Function description: In the STP Port Setting, one item selection and five parameters settings are offered for user’s setup. User can disable and enable each port by selecting each Port Status item. User also can set “Path Cost” and “Priority” of each port by filling in the desired value and set “Admin Edge Port” and “Admin Point To Point” by selecting the desired item. Parameter description: Port Status: It displays the current state of a port.
802.1w RSTP recommended value: (Valid range: 1 – 200,000,000) 10 Mbps : 2,000,000 100 Mbps : 200,000 1 Gbps : 20,000 Default: 0 Priority: Priority here means Port Priority. Port Priority and Port Number are mixed to form the Port ID. Port IDs are often compared in order to determine which port of a bridge would become the Root Port. The range is 0 – 240. Default is 128. Admin Edge Port: If user selects “Yes”, this port will be an edge port.
M Check: Migration Check. It forces the port sending out an RSTP BPDU instead of a legacy STP BPDU at the next transmission. The only benefit of this operation is to make the port quickly get back to act as an RSTP port. Click button to send a RSTP BPDU from the port you specified. Fig.
3-13 MSTP The implementation of MSTP is according to IEEE 802.1Q 2005 Clause 13 – Multiple Spanning Tree Protocol. MSTP allows frames assigned to different VLANs to follow separate paths, each based on an independent Multiple Spanning Tree Instance (MSTI), within Multiple Spanning Tree (MST) Regions composed of LANs and or MST Bridges. Proper configuration of MSTP in an 802.1Q VLAN environment can ensure a loop-free data path for a group of vlans within an MSTI.
3-13-2 Region Config Function name: MSTP Region Config Function description: To configure the basic identification of a MSTP bridge. Bridges participating in a common MST region must have the same Region Name and Revision Level. Parameter description: Region Name: 0-32 characters.(A variable length text string encoded within a fixed field of 32 octets , conforming to RFC 2271’s definition of SnmpAdminString.) Revision Level: 0-65535 Fig.
3-13-3 Instance View (Fig. 3-155) Function name: MSTP Instance Config Function description: Providing an MST instance table which include information(vlan membership of a MSTI ) of all spanning instances provisioned in the particular MST region which the bridge belongs to. Through this table, additional MSTP configuration data can be applied and MSTP status can be retrieved. Parameter description: Instance ID: Every spanning tree instance need to have a unique instance ID within 0~4095.
Fig. 3-155 MSTP Instance Config Fig. 3-156 Edit MSTI / Vlan Parameter description: Vlan Mapping: VID STRING VID STRING Example: 2.5-7.100-200.301.303.
Fig. 3-157 Instance Config Parameter description: Priority: The priority parameter used in the CIST(Common and Internal Spanning Tree) connection. 0 / 4096 / 8192 / 12288 / 16384 / 20480 / 24576 / 28672 / 32768 / 36864 / 40960 / 45056 / 49152 / 53248 / 57344 / 61440 MAX. Age: 6-40sec. The same definition as in the RSTP protocol. Forward Delay: 4-30sec. The same definition as in the RSTP protocol. MAX. Hops: 6-40sec. It’s a new parameter for the multiple spanning tree protocol.
Fig. 3-158 Port Config Parameter description: Port: 1-24 Path Cost: 1 – 200,000,000 The same definition as in the RSTP specification. But in MSTP, this parameter can be respectively applied to ports of CIST and ports of any MSTI. Priority: 0 / 16 / 32 / 48 / 64 / 80 / 96 / 112 / 128 / 144 / 160 / 176 / 192 / 208 / 224 / 240 The same definition as in the RSTP specification. But in MSTP, this parameter can be respectively applied to ports of CIST and ports of any MSTI.
Admin P2P: (Auto/ True/ False) The same definition as in the RSTP specification for the CIST ports. Restricted Role: (Yes/ No) If “Yes” causes the Port not to be selected as Root Port for the CIST or any MSTI, even it has the best spanning tree priority vector. Such a Port will be selected as an Alternate Port after the Root Port has been selected. This parameter is “No” by default. If set, it can cause lack of spanning tree connectivity.
Parameter description: MSTP State: MSTP protocol is Enable or Disable. Force Version: It shows the current spanning tree protocol version configured. Bridge Max Age: It shows the Max Age setting of the bridge itself. Bridge Forward Delay: It shows the Forward Delay setting of the bridge itself. Bridge Max Hops: It shows the Max Hops setting of the bridge itself.
CIST INTERNAL ROOT PATH COST: Root path cost value from the point of view of the bridges inside the IST. CIST CURRENT MAX AGE: Max Age of the CIST Root bridge. CIST CURRENT FORWARD DELAY: Forward Delay of the CIST Root bridge. TIME SINCE LAST TOPOLOGY CHANGE(SECs): Time Since Last Topology Change is the elapsed time in unit of seconds for a bunch of “Topology Change and(or) Topology Change Notification receiving” to occur. When new series of Topology Changes occur again, this counter will be reset to 0.
Path Cost: Display currently resolved port path cost value for each port in a particular spanning tree instance. Priority: Display port priority value for each port in a particular spanning tree instance. Hello: per port Hello Time display. It takes the following form: Current Hello Time/Hello Time Setting Oper. Edge: Whether or not a port is an Edge Port in reality. Oper. P2P: Whether or not a port is a Point-to-Point Port in reality.
3-14. Mirror Function name: Mirror Configuration Function description: Mirror Configuration is to monitor the traffic of the network. For example, we assume that Port A and Port B are Monitoring Port and Monitored Port respectively, thus, the traffic received by Port B will be copied to Port A for monitoring. Note: When configure the mirror function, you should avoid setting a port to be a sniffer port and aggregated port at the same time. It will cause something wrong.
Fig.
3-15. IGMP Snooping The function, IGMP Snooping, is used to establish the multicast groups to forward the multicast packet to the member ports, and, in nature, avoids wasting the bandwidth while IP multicast packets are running over the network. This is because a switch that does not support IGMP or IGMP Snooping can not tell the multicast packet from the broadcast packet, so it can only treat them all as the broadcast packet.
Parameter description: IGMP snooping mode selection: The switch supports three kinds of IGMP Snooping status, including “Passive”, “Active” and “Disable”. Disable: Set “Disable” mode to disable IGMP Snooping function. Default: Disable Active: In Active mode, IGMP snooping switch will periodically issue the Membership Query message to all hosts attached to it and gather the Membership report message to update the database of the Multicast table.
3-15-2 Group Membership Function name: Group Membership Function description: To show the IGMP group members information, the you can edit the parameters for IGMP groups and members in the web user interface. Fig. 3-163 IGMP Group Membership Parameter description: IP Range: The switch supports two kinds of options for managed valid IP range, including “Any” and “Custom”. Default is “Any”. In case that” Custom” had been chosen, you can assigned effective IP range. The valid range is 224.0.0.0~239.255.255.
3-16. Alarm Configuration Alarm Configuration Events Configuration Email/SMS Configuration Fig.3-61 Function name: Events Configuration Function description: The Trap Events Configuration function is used to enable the switch to send out the trap information while pre-defined trap events occurred. The switch offers 24 different trap events to users for switch management. The trap information can be sent out in three ways, including email, mobile phone SMS (short message system) and trap.
3-16-1 Events Function name: Email/SMS Configuration Function description: Alarm configuration is used to configure the persons who should receive the alarm message via either email or SMS, or both. It depends on your settings. An email address or a mobile phone number has to be set in the web page of alarm configuration (See Fig. 3-61). Then, user can read the trap information from the email or the mobile phone. This function provides 6 email addresses and 6 mobile phone numbers at most.
3-16-2 Email Parameter description: Email: Mail Server: the IP address of the server transferring your email. Username: your username on the mail server. Password: your password on the mail server. Email Address 1 – 6: email address that would like to receive the alarm message. SMS: SMS Server: the IP address of the server transferring your SMS. Username: your username in ISP. Password: your username in ISP. Mobile Phone 1-6: the mobile phone number that would like to receive the alarm message. Fig.
3-17. DHCP Snooping DHCP Snooping DHCP Snooping State DHCP Snooping Entry DHCP Snooping Client Fig.3-62 3-17-1. DHCP Snooping State Function name: DHCP Snooping State Function description: The addresses assigned to DHCP clients on unsecure ports can be carefully controlled using the dynamic bindings registered with DHCP Snooping. DHCP snooping allows a switch to protect a network from rogue DHCP servers or other devices which send port-related information to a DHCP server.
3-17-2. DHCP Snooping Entry Function name: DHCP Snooping Entry Function description: DHCP snooping Entry allows a switch to add the an trust DHCP server and 2 trust port to build the DHCP snooping available entry. This information can be useful in tracking an IP address back to a physical port and enable or disable the DHCP Option 82. Fig.
processed as follows: * If the DHCP packet is a reply packet from a DHCP server, the packet is dropped. * If the DHCP packet is from a client, such as a DISCOVER, REQUEST INFORM, DECLINE or RELEASE message, the packet is forwarded if MAC address verification is disabled. However, if MAC address verification is enabled, then the packet will only be forwarded if the client’s hardware address stored in the DHCP packet is the same as the source MAC address in the Ethernet header.
3-18. Configuration The switch supports three copies of configuration, including the default configuration, working configuration and user configuration for your configuration management. All of them are listed and described below respectively. Default Configuration: This is ex-factory setting and cannot be altered. In Web UI, two restore default functions are offered for the user to restore to the default setting of the switch.
3-18-1. Factory Defaults Function name: Restore Default Configuration (includes default IP address) Function description: Restore Default Configuration function can retrieve ex-factory setting to replace the start configuration. And the IP address of the switch will also be restored to 192.168.1.1. Fig. 3-166 Factory Defaults 3-18-2 . Save Start Function name: Save As Start Configuration Function description: Save the current configuration as a start configuration file in flash memory. Fig.
Fig. 3-168 Save as User Configuration 3-18-4 . Restore User Function name: Restore User Configuration Function description: Restore User Configuration function can retrieve the previous confirmed working configuration stored in the flash memory to update start configuration. When completing to restore the configuration, the system’s start configuration is updated and will be changed its system settings after rebooting the system. Fig.
3-19. Config File Function name: Config File Function description: With this function, user can back up or reload the configuration files of Save As Start or Save As User via TFTP. Parameter description: Export File Path: Export Start: Export Save As Start’s config file stored in the flash. Export User-Conf: Export Save As User’s config file stored in the flash. Import File Path: Import Start: Import Save As Start’s config file stored in the flash.
3-20. Diagnostics Three functions, including Diagnostics, Loopback Test and Ping Test are contained in this function folder for device self-diagnostics. Each of them will be described in detail orderly in the following sections. Diagnostics Diagnostics Ping Test VeriPHY 3-20-1 . Diag Function name: Diagnostics Function description: Diagnostics function provides a set of basic system diagnosis. It let users know that whether the system is health or needs to be fixed.
3-20-2 .Ping Function name: Ping Test Function description: Ping Test function is a tool for detecting if the target device is alive or not through ICMP protocol which abounds with report messages. The switch provides Ping Test function to let you know that if the target device is available or not. You can simply fill in a known IP address and then click button. After a few seconds later, the switch will report you the pinged device is alive or dead in the field of Ping Result.
3-20-2 .VeriPHY Function name: VeriPHY Function description: The switch device includes a comprehensive suite of cable diagnostic function that are available using SMI reads and writes. These functions enable a variety of cable operating conditions and status to be accessed and checked. The VeriPHY suite has the ability to identify the cable and operating conditions and to isolate a variety of common faults that can occur the Cat5 twisted pair cabling.
3-21 Maintenance This chapter will introduce the reset and firmware upgrade function for the firmware upgrade and key parameters change system maintenance requirements. 3-21-1 .Reset Device Function name: Reset Device Function description: We offer you many ways to reset the switch, including power up, hardware reset and software reset. You can press the RESET button in the front panel to reset the switch.
3-22 Logout You can manually logout by performing Logout function. In the switch, it provides another way to logout. You can configure it to logout automatically. Function name: Logout Function description: The switch allows you to logout the system to prevent other users from the system without the permission. If you do not logout and exit the browser, the switch will automatically have you logout in five minutes. Besides this manually logout.
4. Operation of CLI Management 4-1. CLI Management Refer to Chapter 2 for basic installation. The following description is the brief of the network connection. -- Locate the correct DB-9 null modem cable with female DB-9 connector. Null modem cable comes with the management switch. Refer to the Appendix B for null modem cable configuration. -- Attach the DB-9 female connector to the male DB-9 serial port connector on the Management board.
LGB1005A-R2 LGB1005A-R2 Fig. 4-1 LGB1005A-R2 LGB1005A-R2 Fig.
4-2. Commands of CLI To see the commands of the mode, please input “?” after the prompt, then all commands will be listed in the screen. All commands can be divided into two categories, including global commands and local commands. Global commands can be used wherever the mode you are. They are “exit”, “end”, “help”, “history”, “logout”, “save start”, “save user”, “restore default” and “restore user”. For more details, please refer to Section 4-2-1.
4-2-1. Global Commands of CLI end Syntax: end Description: Back to the top mode. When you enter this command, your current position would move to the top mode. If you use this command in the top mode, you are still in the position of the top mode. Argument: None. Possible value: None. Example: LGB1005A-R2# alarm LGB1005A-R2(alarm)# events LGB1005A-R2(alarm-events)# end LGB1005A-R2# exit Syntax: exit Description: Back to the previous mode.
help Syntax: help Description: To show available commands. Some commands are the combination of more than two words. When you enter this command, the CLI would show the complete commands. Besides, the command would help you classify the commands between the local commands and the global ones. Argument: None. Possible value: None.
history Syntax: history [#] Description: To show a list of previous commands that you had ever run. When you enter this command, the CLI would show a list of commands which you had typed before. The CLI supports up to 256 records. If no argument is typed, the CLI would list total records up to 256. If optional argument is given, the CLI would only show the last numbers of records, given by the argument. Argument: [#]: show last number of history records. (optional) Possible value: [#]: 1, 2, 3, ….
logout Syntax: logout Description: When you enter this command via Telnet connection, you would logout the system and disconnect. If you connect the system through direct serial port with RS-232 cable, you would logout the system and be back to the initial login prompt when you run this command. Argument: None. Possible value: None.
restore user Syntax: restore user Description: To restore the startup configuration as user defined configuration. If restoring default successfully, the CLI would prompt if reboot immediately or not. If you press Y or y, the system would reboot immediately; others would back to the CLI system. After restoring user-defined configuration, all the changes in the startup configuration would be lost. After rebooting, the entire startup configuration would replace as user defined one. Argument: None.
save user Syntax: save user Description: To save the current configuration as the user-defined configuration. When you enter this command, the CLI would save your current configuration into the non-volatile FLASH as user-defined configuration. Argument: None. Possible value: None. Example: LGB1005A-R2# save user Saving user...
4-2-2. Local Commands of CLI 802.1X set maxReq Syntax: set maxReq Description: The maximum number of times that the state machine will retransmit an EAP Request packet to the Supplicant before it times out the authentication session. Argument: : syntax 1,5-7, available from 1 to 24 : max-times , range 1-10 Possible value: : 1 to 24 : 1-10, default is 2 Example: LGB1005A-R2(802.
set port-control Syntax: set port-control Description: To set up 802.1X status of each port. Argument: : syntax 1,5-7, available from 1 to 24 : Set up the status of each port 0:ForceUnauthorized 1:ForceAuthorized 2:Auto Possible value: : 1 to 24 : 0, 1 or 2 Example: LGB1005A-R2(802.
set reAuthMax Syntax: set reAuthMax Description: The number of reauthentication attempts that are permitted before the port becomes Unauthorized. Argument: : syntax 1,5-7, available from 1 to 24 : max. value , range 1-10 Possible value: : 1 to 24 : 1-10, default is 2 Example: LGB1005A-R2(802.
set auth-server Syntax: set auth-server Description: To configure the settings related with 802.1X Radius Server. Argument: : the IP address of Radius Server : the service port of Radius Server(Authorization port) : set up the value of secret-key, and the length of secret-key is from 1 to 31 Possible value: : 1~65535, default is 1812 Example: LGB1005A-R2(802.1X)# set auth-server 192.168.1.
show status Syntax: show status Description: To display the mode of each port. Argument: None Possible value: None Example: LGB1005A-R2(802.1X)# show status Port Mode ====== ============ 1 Disable 2 Multi-host 3 Disable 4 Disable 5 Disable 6 Disable show port-config Syntax: show port-config Description: To display the parameter settings of each port. Argument: : syntax 1,5-7, available from 1 to 24 Possible value: : 1 to 24 Example: LGB1005A-R2(802.
reAuthPeriod max. Request suppTimeout serverTimeout : : : : 120 2 30 30 show statistics Syntax: show statistics <#> Description: To display the statistics of each port. Argument: <#> syntax 1,5-7, available from 1 to 24 Possible value: <#> 1 to 24 : show server Syntax: show server Description: Show the Radius server configuration Argument: None Possible value: None Example: LGB1005A-R2(802.1X)# show server Authentication Server ________________________________________ IP Address: 192.168.1.
Argument: : new account name Possible value: A string must be at least 5 character. Example: LGB1005A-R2(account)# add aaaaa Password: Confirm Password: LGB1005A-R2(account)# del Syntax: del Description: To delete an existing account. Argument: : existing user account Possible value: None. Example: LGB1005A-R2(account)# del aaaaa Account aaaaa deleted modify Syntax: modify Description: To change the username and password of an existing account.
Argument: None. Possible value: None. Example: LGB1005A-R2(account)# show Account Name Identity ----------------- --------------admin Administrator guest guest acl ace Syntax: ace Description: To display the ace configuration. Argument: : the access control rule index value Possible value: None.
action Syntax: action Description: To set the access control per port as packet filter action rule. Argument: : 1-24 : permit: 1, deny: 0 : 0-16 (0:disable) : 0-24 (0:disable) Possible value: : 1-24 : 0-1 : 0-16 : 0-24 Example: LGB1005A-R2L(acl)# action 5 0 2 2 LGB1005A-R2L(acl)# show port policy id action rate limiter port copy counter a class map .. .. ……. …. … ..
move Syntax: move Description: To move the ACE ( Access Control Entry) configuration between index1 and index2.. Argument: None. Possible value: None.
set Syntax: set [] [] [switch | (port ) | (policy )] [] [] [] [(any) | (etype [] []) | (arp [] [] (any | [] []) (any | [] []) [] [] [] [] [] []) | (ip [( ) | any] [( ) | any] [] [
rate limiter rate(pps) ------------ -----------1 1 2 1 3 1 4 1 5 1 …… LGB1005A-R2L(acl)# …… alarm <> del mail-address Syntax: del mail-address <#> Description: To remove the configuration of E-mail address. Argument: <#>: email address number, range: 1 to 6 Possible value: <#>: 1 to 6 Example: LGB1005A-R2(alarm-email)# del mail-address 2 del server-user Syntax: del server-user Description: To remove the configuration of server, user account and password. Argument: None. Possible value: None.
<#> :email address number, range: 1 to 6 :email address Possible value: <#>: 1 to 6 Example: LGB1005A-R2(alarm-email)# set mail-address 1 abc@mail.abc.com set server Syntax: set server Description: To set up the IP address of the email server. Argument: :email server ip address or domain name Possible value: None. Example: LGB1005A-R2(alarm-email)# set server 192.168.1.6 set user Syntax: set user Description: To set up the account and password of the email server.
Email Email Email Email Address Address Address Address 3: 4: 5: 6: <> del all Syntax: del all Description: To disable email, sms and trap of events. Argument: :del the range of events, syntax 1,5-7 Possible value: : 1~24 Example: LGB1005A-R2(alarm-events)# del all 1-3 del email Syntax: del email Description: To disable the email of the events.
set all Syntax: set all Description: To enable email, sms and trap of events. Argument: :set the range of events, syntax 1,5-7 Possible value: : 1~24 Example: LGB1005A-R2(alarm-events)# set all 1-3 set email Syntax: set email Description: To enable the email of the events.
Example: LGB1005A-R2(alarm-events)# show Events Email SMS Trap ----------------------------------------1 Cold Start v 2 Warm Start v 3 Link Down v 4 Link Up v 5 Authentication Failure v 6 Login 7 Logout 8 Module Inserted 9 Module Removed 10 Dual Media Swapped 11 Looping Detected 12 STP Disabled 13 STP Enabled 14 STP Topology Changed 15 LACP Disabled 16 LACP Enabled 17 LACP Member Added 18 LACP Aggregates Port Failure 19 GVRP Disabled 20 GVRP Enabled 21 VLAN Disabled 22 Port-based Vlan Enabled 23 Tag-based V
show (alarm) Syntax: show Description: The Show for alarm here is used to display the configuration of Events, or E-mail. Argument: None. Possible value: None. Example: LGB1005A-R2(alarm)# show events LGB1005A-R2(alarm)# show email autologout autologout Syntax: autologout
config-file export Syntax: export < ip address> Description: To run the export function. Argument: < Usage> set up current or user < ip address> the TFTP server ip address Possible value: none Example: LGB1005A-R2(config-file)# export current 192.168.1. 63 Export successful. import Syntax: import < ip address> Description: To run the import start function. Argument: None Possible value: None Example: LGB1005A-R2(config-file)# import current 192.168.1.
gvrp set state Syntax: set state < 0 | 1> Description: To disable/ enable the gvrp function. Argument: 0 : disable the gvrp function 1 : enable the gvrp function Possible value: 0 : disable the gvrp function 1 : enable the gvrp function Example: LGB1005A-R2(gvrp)# set state 1 group applicant Syntax: group applicant < 0 | 1> Description: To enter any of gvrp group for changing gvrp group setting. You can change the applicant or registrar mode of existing gvrp group per port.
set applicant Syntax: set applicant < 0 | 1 > Description: To set default applicant mode for each port. Argument: : port range, syntax 1,5-7, available from 1 to 24 <0>: set applicant as normal mode <1>: set applicant as non-participant mode Possible value: : 1 to 24 < 0 | 1 >: normal or non-participant Example: LGB1005A-R2(gvrp)# set applicant 1-10 non-participant set registrar Syntax: set registrar < 0 | 1 | 2> Description: To set default registrar mode for each port.
Port Join Time Leave Time LeaveAll Time ---- --------- ---------- ------------1 20 60 1000 2 20 60 1000 3 20 60 1000 4 20 60 1000 5 20 60 1000 6 20 60 1000 7 20 60 1000 8 20 60 1000 9 20 60 1000 10 20 60 1000 22 23 24 20 20 20 60 60 60 1000 1000 1000 Applicant --------------Normal Normal Normal Normal Normal Normal Normal Normal Normal Normal : : : Normal Normal Normal Registrar Restricted --------- ---------Normal Enable Normal Enable Normal Enable Normal Enable Normal Enable Normal Enable Normal Ena
---- --------- ---------- ------------- --------------1 20 60 1000 Normal 2 25 80 2000 Normal 3 25 80 2000 Normal 4 25 80 2000 Normal 5 25 80 2000 Normal 6 25 80 2000 Normal 7 25 80 2000 Normal 8 25 80 2000 Normal : : 23 20 60 1000 Normal 24 20 60 1000 Normal counter Syntax: counter Description: To display the counter number of the port.
group grpinfo Syntax: group grpinfo Description: To show the gvrp group. Argument: : To set the vlan id from 1 to 4094 Possible value: : 1 to 4094 Example: LGB1005A-R2(gvrp)# group grpinfo 2 GVRP group information VID Member Port ---- ------------------------------------------------- hostname hostname Syntax: hostname Description: To set up the hostname of the switch. Argument: : hostname, max. 40 characters. Possible value: : hostname, max. 40 characters.
set erp Syntax: set erp Description: Set router ports to enable Argument: : syntax 1,5-7, available from 1 to 24 Possible value: : 1 to 24 Example: LGB1005A-R2(igmp)# set erp 1 set flood Syntax: set flood Description: To set up disable / enable unregister ipmc flooding. Argument: : 0:disable, 1:enable Possible value: : 0,or 1 Example: LGB1005A-R2(igmp)# set flood 1 show gm Syntax: show gm Description: To display group memebership. Argument: None.
Example: LGB1005A-R2(igmp)# show igmpp IP disable dhcp Syntax: disable dhcp Description: To disable the DHCP function of the system. Argument: None Possible value: None Example: LGB1005A-R2(ip)# disable dhcp enable dhcp Syntax: enable dhcp Description: To enable the system DHCP function and set DNS server via manual or auto mode. Argument: : set dhcp by using manual or auto mode.
set ip Syntax: set ip Description: To set the system IP address, subnet mask and gateway. Argument: : ip address : subnet mask : default gateway Possible value: : 192.168.1.2 or others : 255.255.255.0 or others : 192.168.1.253 or others Example: LGB1005A-R2(ip)# set ip 192.168.1.2 255.255.255.0 192.168.1.
ip_mac_binding set entry Syntax: set entry < 0 | 1> < mac> < ip> < port no> < vid> Description: To set ip mac binding entry Argument: < 0 | 1> : 0 : Client , 1: Server : mac address < ip > : ip address < port > : syntax 1,5-7, available from 1 to 24 < vid > : vlan id, 1 to 4094 Possible value: < 0 | 1> : 0 : Client , 1: Server : format: 00-02-03-04-05-06 < ip > : ip address < port > : 1 to 24 < vid > : 1 to 4094 Example: LGB1005A-R2(ip_mac_binding)# set entry 1 00-11-2f-de-7b-a9 192.168.2.
MAC Alias List MAC Address Alias ----- ----------------- ---------------1) 00-02-03-04-05-06 aaa 2) 00-33-03-04-05-06 ccc 3) 00-44-33-44-55-44 www loop-detection disable Syntax: disable <#> Description: To disable switch ports the loop detection function.
1 Enable 2 Enable 3 Enable 4 Enable 5 Enable 6 Enable 7 Enable 8 Enable …………. 1 2 3 4 5 6 7 8 Normal Normal Normal Normal Normal Normal Normal Normal Resume Syntax: resume <#> Description: To resume locked ports on switch.
Detection Port Locked Port Port Status Port Status --------------------------------1 Enable 1 Normal 2 Enable 2 Normal 3 Enable 3 Normal 4 Enable 4 Normal 5 Enable 5 Normal 6 Enable 6 Normal 7 Enable 7 Normal 8 Enable 8 Normal …………. show Syntax: show Description: To display loop detection configure.
Argument: : set up the MAC format: xx-xx-xx-xx-xx-xx Possible value: : set up the MAC format: xx-xx-xx-xx-xx-xx Example: LGB1005A-R2(mac-alias)# set 23-56-r5-55-3f-03 test3 LGB1005A-R2(mac-alias)# show MAC Alias No MAC Alias =========================================== 1 23-56-00-55-3F-03 test3 2 23-56-00-55-EF-03 test13 3 23-56-00-55-EF-33 test1 LGB1005A-R2(mac-alias)# del 23-56-00-55-3F-03 LGB1005A-R2(mac-alias)# show MAC Alias No MAC Alias =========================================== 1 23-56-00
Argument: None Possible value: none Example: LGB1005A-R2(mac-alias)# show MAC Alias No MAC Alias =========================================== 1 23-56-00-55-3F-03 test3 2 23-56-00-55-EF-03 test13 3 23-56-00-55-EF-33 test1 <> flush Syntax: flush Description: To del dynamic mac entry.
----1 Static 1 FF-FF-FF-FF-FF-FF 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16,17,1 8,19,20,21,22,23,24, <> set age-time Syntax: set age-time <#> Description: To set mac table age out time of dynamic learning mac. Argument: <#>: age-timer in seconds, 0, 10 1000000. The value zero disables aging Possible value: <#>: 0, 10 to 1000000.
set learning Syntax: set learning Description: To set mac table learning. Argument: : 1,5-7, available from 1 to 24 : auto learning : disable learning : learn frames are discarded Possible value: : 1,5-7, available from 1 to 24 : auto learning : disable learning : learn frames are discarded.
show Syntax: show Description: To display mac table maintenance Argument: Noneq Possible value: None Example: LGB1005A-R2(mac-maintenance)# show 1 Static Aging Configuration:FF 1,2,3,4,5,6,7,8,9 Age time: 3004,15,16,17,1 MAC Table Learning Port Learning Mode 2 Auto 3 Auto 4 Auto 5 Auto 6 Auto 7 Auto 8 Auto 9 Auto 10 Auto 11 Auto 12 Auto 13 Auto 14 Auto 15 Auto 16 Auto 17 Auto 18 Auto 19 Auto 20 Auto 21 Auto 22 Auto 23 Auto 24 Auto 200
<> add Syntax: add [alias] Description: To add the static mac entry. Argument: : mac address, format: 00-02-03-04-05-06 : 0-24. The value “0” means this entry is filtering entry : vlan id. 0, 1-4094. VID must be zero if vlan mode is not tag-based [alias] : mac alias name, max.
Example: LGB1005A-R2(mac-static-mac)# show filter Static Filtering Etnry: (Total 1 item(s)) 1) mac: 00-33-03-04-05-06, vid: -, alias: ccc LGB1005A-R2(mac-static-mac)# show forward Syntax: show forward Description: To display the static forwarding mac entry.
mirror set mirror Syntax: set mirror < #> Description: To set mirror port and enable/disable mirror function Argument: <#>: port, available from 1 to 24 and 0. 1 to 24: available port number 0: disable mirror function Possible value: <#>: 1 to 24 Example: LGB1005A-R2(mirror)# set mirror 2 set monitor-destination Syntax: set monitor-destination Description: To set monitor destination port. The packets sent by this port will be copied to the monitoring port.
set monitor-source Syntax: set monitor-source Description: To set up the monitoring port of the mirror function. User can observe the packets that the monitored port received via this port. Argument: : the monitoring port that is chosen for the mirror function.
show Syntax: show Description: To display the setting status of mirror configuration.
mstp disable Syntax: disable Description: To disable mstp function. Argument: None Possible value: None Example: LGB1005A-R2 (mstp)# disable enable Syntax: enable Description: To enable mstp function. Argument: None Possible value: None Example: LGB1005A-R2 (mstp)# enable migrate-check Syntax: migrate-check Description: To force the port to transmit RST BPDUs.
: available from 4 to 30. Recommended value is 15 : available from 6 to 40. Recommended value is 20 Possible value: : available from 6 to 40. Recommended value is 20 : available from 4 to 30. Recommended value is 15 : available from 6 to 40.
Possible value: syntax: 1,5-7, available from 1 to 24 : 0->non-edge port,1->edge ports Example: LGB1005A-R2(mstp)# set p-edge 10-12 0 LGB1005A-R2(mstp)# set p-hello Syntax: set p-hello Description: To set per port hello time Argument: : syntax: 1,5-7, available from 1 to 24 : only 1~2 are valid values Possible value: : syntax: 1,5-7, available from 1 to 24 : only 1~2 are valid values Example: LGB1005A-R2
LGB1005A-R2(mstp)# enable MSTP started LGB1005A-R2(mstp)# show instance 0 mstp status : enabled force version : 3 instance id: 0 bridge max age : 20 bridge forward delay : 15 bridge max hops : 20 instance priority : 4096 bridge mac : 00:40:c7:5e:00:09 CIST ROOT PRIORITY : 4096 CIST ROOT MAC : 00:40:c7:5e:00:09 CIST EXTERNAL ROOT PATH COST : 0 CIST ROOT PORT ID : 0 CIST REGIONAL ROOT PRIORITY : 4096 CIST REGIONAL ROOT MAC : 00:40:c7:5e:00:09 CIST INTERNAL ROOT PATH COST : 0 CIST CURRENT MAX AGE : 20 CIST CUR
8 DISCARDING dsbl 9 DISCARDING dsbl 10 DISCARDING dsbl 11 DISCARDING dsbl 12 DISCARDING dsbl 13 DISCARDING dsbl 14 DISCARDING dsbl 15 DISCARDING dsbl 16 DISCARDING dsbl 17 DISCARDING dsbl 18 DISCARDING dsbl 19 DISCARDING dsbl 20 DISCARDING dsbl 21 DISCARDING dsbl 22 DISCARDING dsbl 23 DISCARDING dsbl 24 DISCARDING dsbl LGB1005A-R2(mstp)# 2000000 2000000 2000000 2000000 2000000 2000000 2000000 2000000 2000000 2000000 2000000 2000000 2000000 2000000 2000000 2000000 2000000 128 128 128 128 128 128 128 128 12
14 0 128 15 0 128 16 0 128 17 0 128 18 0 128 19 0 128 20 0 128 21 0 128 22 0 128 23 0 128 24 0 128 LGB1005A-R2(mstp)# 2 2 2 2 2 2 2 2 2 2 2 true true true true true true true true true true true auto false true auto false true auto false true auto true true auto true true auto true true auto true true auto true false auto true false auto true false auto true false set region-name Syntax: set region-name Description: To set mstp region name(0~32 bytes) Argument: :a null region name Poss
set version Syntax: set version Description: To set force-version Argument: :0~65535 Possible value: :0~65535 Example: LGB1005A-R2(mstp)# set version mstp show instance Syntax: show instance Description: To show instance status Argument: :0->CIST;1-4095->MSTI Possible value: :0->CIST;1-4095->MSTI Example: LGB1005A-R2(mstp)# show instance 0 mstp status : enabled force version : 2 instance id: 0 bridge max age : 20 br
To show port configuration Argument: instance-id:0->CIST;1-4095->MSTI Possible value: :0->CIST;1-4095->MSTI Example: LGB1005A-R2(mstp)# show pconf 0 set r-role Se 2 0 128 2 true 3 0 128 2 true 4 0 128 2 true 5 0 128 2 true 6 0 128 2 true 7 0 128 2 true 8 0 128 2 true 9 0 128 2 true 10 0 128 2 true 11 0 128 2 true 12 0 128 2 true 13 0 128 2 true 14 0 128 2 true 15 0 128 2 true 16 0 128 2 true 17 0 128 2 true 18 0 128 2 true 19 0 128 2 true 20 0 128 2 true 21 0 128 2 true 22 0 128 2 true 23 0 12
To show region config Argument: none Possible value: none Example: LGB1005A-R2(mstp)# show region-info Name : test2 Revision : 30000 Instances : 0 LGB1005A-R2(mstp)# show vlan-map Syntax: show vlan-map Description: To show vlan mapping of an instance Argument: :0->CIST;1-4095->MSTI Possible value: :0->CIST;1-4095->MSTI Example: LGB1005A-R2(mstp)# show vlan-map 0 instance 0 has those vlans : 0-4095 LGB1005A-R2(mstp)# policy add Syntax: add [name ] [ip
Action : Deny Port : 11 12 13 14 15 3) Name : Mary Action : Deny Port : Any Access Type : HTTP TELENT SNMP IP Range : 192.168.3.1-192.168.3.4 Access Type : Any LGB1005A-R2(policy)# delete Syntax: delete Description: To add a new management policy entry. Argument: : a specific or range management policy entry(s) e.g. delete 2,3,8-12 Possible value: : a specific or range management policy entry(s) Example: LGB1005A-R2(policy)# add name rule2 ip 192.168.4.23-192.168.4.
Example: LGB1005A-R2(policy)# show 1) Name : rule1 Action : Deny Port : 2 3 4 5 2) Name : rule2 Action : Deny Port : 6 7 8 IP Range : 192.168.4.5-192.168.4.22 Access Type : HTTP TELENT SNMP IP Range : 192.168.4.23-192.168.4.33 Access Type : TELENT SNMP port clear counter Syntax: clear counter Description: To clear all ports’ counter (include simple and detail port counter) information.
6 7 8 9 Auto Auto Auto Auto Disabled Disabled Disabled Disabled 9600 9600 9600 9600 Discard salesdepartment Discard salesdepartment Discard salesdepartment Discard set excessive-collision Syntax: set excessive-collision Description: To set port description Argument: syntax : 1,5-7, available from 1 to 24 Possible value: : 1 to 24 Example: LGB1005A-R2(port)# set excessive-collision 6-10 restart LGB1005A-R2(port)# show config Speed/ Flow Maximum Ex
3 4 5 6 7 8 9 10 11 12 Auto Auto Auto Auto Auto Auto Auto Auto Auto Auto Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled Disabled Disabled 9600 9600 9600 9600 9600 9600 9600 9600 9600 9600 Discard Discard Discard Restart Restart Restart Restart Restart Discard Discard salesdepartment salesdepartment salesdepartment salesdepartment salesdepartment salesdepartment set max-frame Syntax: set max-frame Description: To set per-port maximum frame size Argument:
10half: set speed/duplex 10M Half 10full: set speed/duplex 10M Full 100half: set speed/duplex 100M Half 100full: set speed/duplex 100M Full 1Gfull: set speed/duplex 1G Full Possible value: : 1 to 24 : auto, 10half, 10full, 100half, 100full, 1Gfull Example: LGB1005A-R2(port)# set speed 3 auto LGB1005A-R2(port)# show status Speed/ Port Link Duplex Rx Pause Tx Pause Description ---- ---- --------- -------- -------- -------------------------------1 Up 100M/Full Disabled Disabled 2 Down D
12 Auto Disabled 9600 Discard show detail-counter Syntax: show detail-counter Description: To display the display detail port counter.
LGB1005A-R2(port)# show sfp 11 Port 11 SFP information --------------------------------------------------------------------Connector Type : SFP - Unknown or unspecified Fiber Type : Reserved Tx Central Wavelength : 0 Baud Rate : 1G Vendor OUI : 00:00:00 Vendor Name : FIBERXON INC.
Port 23 SFP information --------------------------------------------------------------------Connector Type : SFP - LC Fiber Type : Multi-mode (MM) Tx Central Wavelength : 850 Baud Rate : 1G Vendor OUI : 00:40:c7 Vendor Name : APAC Opto Vendor PN : KM28-C3S-TC-N Vendor Rev : 0000 Vendor SN : 5425010708 Date Code : 050530 Temperature : none Vcc : none Mon1 (Bias) mA : none Mon2 (TX PWR) : none Mon3 (RX PWR) : none show simple-counter Syntax: show simple-counter Description: To display the summary counting of
show status Syntax: show status Description: To display the port’s current status. Argument: None. Possible value: None.
qos <> set class Syntax: set class <#> Description: To set number of classes. Argument: #: Number of classes, available 1, 2, 4 Possible value: <#>: 1,2,4 Example: LGB1005A-R2(qos-ports)# set class 2 LGB1005A-R2(qos-ports)# set port Syntax: set port Description: To set port information.
2 Medium 1 3 Low 1 4 Low 1 5 Low 1 6 Low 1 7 Low 1 8 Low 1 9 Low 1 10 Low 1 11 Low 1 12 Low 1 13 Low 1 14 Low 1 ……… LGB1005A-R2(qos-ports)# 3 0 0 0 0 0 0 0 0 0 0 0 0 Weighted Fair Strict Priority Strict Priority Strict Priority Strict Priority Strict Priority Strict Priority Strict Priority Strict Priority Strict Priority Strict Priority Strict Priority Strict Priority 2 / 1 / 1 / 1 / 1 / 1 / 1 / 1 / 1 / 1 / 1 / 1 / 1 / 2 2 2 2 2 2 2 2 2 2 2 2 2 Weighted Fair Strict Priority Strict Priority Strict Prio
: ethernet : 0xfff0 : high Possible value: : dscp field, syntax 1,5-7, available from 0 to 63 < tos> : tos priority , available from 1 to 8 < tagpriority> : tag priority, available from 1 to 8 : ethernet : 0xfff0 : high Example: LGB1005A-R2(qos-qcl)# set 2 0 3 ethernet 0xfff0 high LGB1005A-R2(qos-qcl)# show 2 1 QCE Type: Ethernet Type Ethernet Type Value:0xfff0 Traffic Class: High LGB1005A-R2(qos-qcl)# move Syntax: move Descr
<> set Syntax: set Description: To set rate limit configuration Argument: : 1,5-7, available from 1 to 24 : 1 means enable and 0 means disable : allowed values are 500kbps-1Gkps : 'k' means kbps and 'm' means mbps : 1 means enable and 0 means disable : allowed values are 500kbps-1Gkps : 'k' means kbps and 'm' means mbps Possible value: range syntax: 1,5-7, ava
Possible value: : 1 means enable and 0 means disable : 1, 2, 4, 8, 16, 32, 64, 128, 256, 512, 1k, 2k, 4k, 8k, 16k, 32k, 64k, 128k , 256k, 512k Example: LGB1005A-R2(qos-storm)# set broadcast 1 512 LGB1005A-R2(qos-storm)# show Frame Type Status Rate(Packet Per Second) -----------------------------------------------Flooded unicast 1 Multicast 1 Broadcast V 512 set multicast Syntax: set multicast Description: To set multicast storm control configuration Argument: : 1 me
: 1, 2, 4, 8, 16, 32, 64, 128, 256, 512, 1k, 2k, 4k, 8k, 16k, 32k, 64k, 128k , 256k, 512k Example: LGB1005A-R2(qos-storm)# set unicast 1 128 LGB1005A-R2(qos-storm)# show Frame Type Status Rate(Packet Per Second) -----------------------------------------------Flooded unicast V 128 Multicast V 64 Broadcast V 512 show Syntax: show Description: To show storm control configuration Argument: none Possible value: none Example: LGB1005A-R2(qos-storm)# show Frame Type Status Rate(Packet Per Second) ---------
<> Syntax: disable set-ability disable snmp Description: The Disable here is used for the de-activation of snmp or set-community. Argument: None. Possible value: None. Example: LGB1005A-R2(snmp)# disable snmp LGB1005A-R2(snmp)# disable set-ability <> Syntax: enable set-ability enable snmp Description: The Enable here is used for the activation snmp or set-community. Argument: None. Possible value: None.
show Syntax: show Description: The Show here is to display the configuration of SNMP. Argument: None. Possible value: None. Example: LGB1005A-R2(snmp)# show SNMP : Enable Get Community: public Set Community: private [Enable] Trap Host 1 IP Address: 192.168.1.1 Port: 162 Community: public Trap Host 2 IP Address: 0.0.0.0 Port: 162 Community: public Trap Host 3 IP Address: 0.0.0.0 Port: 162 Community: public Trap Host 4 IP Address: 0.0.0.0 Port: 162 Community: public Trap Host 5 IP Address: 0.0.0.
stp MCheck Syntax: MCheck Description: To force the port to transmit RST BPDUs. Argument: : syntax 1,5-7, available from 1 to 24 Possible value: : 1 to 24 Example: LGB1005A-R2(stp)# Mcheck 1-8 disable Syntax: disable Description: To disable the STP function. Argument: None. Possible value: None. Example: LGB1005A-R2(stp)# disable enable Syntax: enable Description: To enable the STP function. Argument: None. Possible value: None.
set config Syntax: set config Description: To set up the parameters of STP. Argument: :priority must be a multiple of 4096, available from 0 to 61440. : available from 1 to 10. : available from 6 to 40. : available from 4 to 30. Note: 2*(Forward Delay -1) >= Max Age Max Age >= 2*(Hello Time +1) Possible value: : 0 to 61440 : 1 to 10
set version Syntax: set version Description: To set up the version of STP. Argument: :stp / rstp Possible value: :stp / rstp Example: LGB1005A-R2(stp)# set version rstp show config Syntax: show config Description: To display the configuration of STP. Argument: None. Possible value: None. Example: LGB1005A-R2(stp)# show config STP State Configuration : Spanning Tree Protocol : Enabled Bridge Priority (0-61440) : 61440 Hello Time (1-10 sec) : 2 Max.
show port Syntax: show port Description: To display the port information of STP. Argument: None. Possible value: None.
show status Syntax: show status Description: To display the status of STP. Argument: None. Possible value: None. Example: LGB1005A-R2(stp)# show status STP Status : STP State Bridge ID Bridge Priority Designated Root Designated Priority Root Port Root Path Cost Current Max.
system set contact Syntax: set contact Description: To set the contact description of the switch. Argument: :string length up to 40 characters. Possible value: : A, b, c, d, ... ,z and 1, 2, 3, …. etc. Example: LGB1005A-R2(system)# set contact Taipei set device-name Syntax: set device-name Description: To set the device name description of the switch. Argument: : string length up to 40 characters.
show Syntax: show Description: To display the basic information of the switch. Argument: None. Possible value: None. Example: LGB1005A-R2(system)# show Model Name : LGB1005A-R2 System Description : L2 Managed Switch Location : Contact : Device Name : LGB1005A-R2 System Up Time : 0 Days 0 Hours 4 Mins 14 Secs Current Time : Tue Jan 17 16:28:46 2006 BIOS Version : v1.05 Firmware Version : v2.08 Hardware-Mechanical Version : v1.01-v1.01 Serial Number : 030C02000003 Host IP Address : 192.168.1.
show Syntax: show Description: To display the trap log. Argument: None. Possible value: None. Example: LGB1005A-R2(tftp)# show 2 Mon Mar 17 15:18:38 2008gvrp mode> .
Save Successfully set manual Syntax: set manual Description: To set up the current time manually. Argument: YYYY : Year (2000-2036) MM : Month (01-12) DD : Day (01-31) hh : Hour (00-23) mm : Minute (00-59) ss : Second (00-59) Possible value: YYYY : (2000-2036) MM : (01-12) DD : (01-31) hh : (00-23) mm : (00-59) ss : (00-59) Example: LGB1005A-R2(time)# set manual 2004/12/23 16:18:00 set ntp Syntax: set ntp Description: To set up the current time via NTP server.
NTP Server Timezone Day light Saving Day light Saving Start Day light Saving End : Mth: LGB1005A-R2(time)# : : : : 1 209.81.9.7 GMT+8:00 0 Hours Mth: 1 Day: 1 Hour: 0 Day: 1 Hour: 0 trunk del trunk Syntax: del trunk Description: To delete the trunking port.
: 1 to 24 : static / lacp : 1-8. : active / passive Example: LGB1005A-R2(trunk)# set trunk 1-4 lacp 1 active show aggtr-view Syntax: show aggtr-view Description: To display the aggregator list. Argument: None. Possible value: None.
show lacp-priority Syntax: show lacp-priority Description: To display the value of LACP Priority. Argument: None. Possible value: None. Example: LGB1005A-R2(trunk)# show lacp-priority LACP System Priority : 32768 show status Syntax: show status Description: To display the aggregator status and the settings of each port. Argument: None. Possible value: None.
vlan del port-group Syntax: del port-group Description: To delete the port-based vlan group. Argument: : which vlan group you want to delete. Possible value: : port-vlan name Example: LGB1005A-R2(vlan)# del port-group VLAN-2 del tag-group Syntax: del tag-group Description: To delete the tag-based vlan group.
disable sym-vlan Syntax: disable sym-vlan Description: To drop frames from the non-member port. Argument: : which port(s) you want to set, syntax 1,5-7, available from 1 to 24 Possible value: : 1 to 24 Example: LGB1005A-R2(vlan)# disable sym-vlan 5-10 enable drop-untag Syntax: enable drop-untag Description: To drop the untagged frames.
set mode Syntax: set mode [up-link] Description: To switch VLAN mode, including disable, port-based, tag-based, metro and doubletag modes.
set port-role Syntax: set port-role [vid] Description: To set egress rule: configure the port roles.
set tag-group Syntax: set tag-group <#> Description: To add or edit the tag-based vlan group. Argument: : vlan ID, range from 1 to 4094 : tag-vlan name : vlan group members, syntax 1,5-7, available from 1 to 24 <#>: sym/asym vlan setting.
None.
5. Maintenance 5-1. Resolving No Link Condition The possible causes for a no link LED status are as follows: z The attached device is not powered on z The cable may not be the correct type or is faulty z The installed building premise cable is faulty z The port may be faulty 5-2. Q&A 1. Computer A can connect to Computer B, but cannot connect to Computer C through the Managed Switch. 9 The network device of Computer C may fail to work. Please check the link/act status of Computer C on the LED indicator.
Appendix A Technical Specifications Features • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 16 fiber (SFP) switching ports are compliant with SX/LX..etc-LC. 8 Gigabit TP/SFP fiber are dual media ports with auto detected function. Non-blocking store-and-forward shared-memory Web-Smart switched. Supports auto-negotiation for configuring speed, duplex mode. Supports 802.3x flow control for full-duplex ports. Supports collision-based and carrier-based backpressure for half-duplex ports.
Hardware Specifications Standard Compliance: IEEE802.3/802.3ab / 802.3z / 802.3u / 802.
Diagnostic LED: System LED : Per Port LED: 10/100/1000M TP Port 1 to 8 1000M SFP Fiber Port 1 to 24 Power Requirement : Power : LINK/ACT, 10/100/1000Mbps : SFP(LINK/ACT) AC Line Voltage : 100∼240 V Frequency : 50∼60 Hz Consumption : 30W Ambient Temperature : 0° to 40°C : 5% to 90% Humidity Dimensions : 44(H) × 442(W) × 209(D) mm Comply with FCC Part 15 Class A & CE Mark Approval 253
Management Software Specifications System Configuration Management Agent Spanning Tree Algorithm VLAN Function Trunk Function IGMP Bandwidth Control Quality of Service (QoS) Port Security Internetworking Protocol Network Management Auto-negotiation support on 10/100/1000 BaseTX ports, Web browser or console interface can set transmission speed (10/100/1000Mbps) and operation mode (Full/Half duplex) on each port, enable/disable any port, set VLAN group, set Trunk Connection.
Appendix B Null Modem Cable Specifications The DB-9 cable is used for connecting a terminal or terminal emulator to the Managed Switch’s RS-232 port to access the command-line interface. The table below shows the pin assignments for the DB-9 cable.
