Screen element Image Image size in pixels

BlackBerry 6

BlackBerry® Device Software 5.0

Phone phone receiver (active

phone call)

composite image 264 x 17

component image 24 x 17

composite image 676 x 52

component image 52 x 52

volume control (active

phone call)

composite image 660 x 4

component image 60 x 4

composite image 495 x 50

component image 45 x 50

button (active phone call)

button focus (active

phone call)

80 x 50 —

button (incoming call)

button focus (incoming

call)

320 x 50 —

phone icons (phone

hotlist)

composite image 522 x 29

component image 29 x 29

composite image 380 x 20

component image 20 x 20

background (incoming,

active call)

320 x 240 320 x 240

Lock screen background 320 x 240 320 x 240

lock icon 44 x 44 52 x 52

Global images transmission arrows 10 x 10 22 x 22

Alt mode, NUM lock, CAP

lock

20 x 20 to 30 x 29 21 x 20 to 30 x 29

navigation arrows 19 x 9 to 28 x 18 10 x 7 to 28 x 18

hourglass 17 x 17 to 50 x 50 19 x 19 to 50 x 50

Image sizes for the BlackBerry Pearl 9100 Series

smartphones

You can use the image sizes in the BlackBerry® 6 column to create themes for Custom 6 and BlackBerry 6 theme

layouts. You can use the image sizes in the BlackBerry® Device Software 5.0 column to create themes for Custom,

Zen, and Today theme layouts.

Screen element Image Image size in pixels

BlackBerry 6

Image size in pixels

BlackBerry® Device

Software 5.0

Banner Home screen 360 x 60 360 x 96

Application list 360 x 21 360 x 48

alarm indicator 13 x 13 11 x 13

User Guide

Image sizes for the BlackBerry Pearl 9100 Series smartphones
