Blackrock CerePlex M Instruction for Use Blackrock Microsystems, Inc. 391 Chipeta Way, Suite G Salt Lake City, UT 84108 Tel: (866) 806-3692 www.blackrockmicro.
Blackrock CerePlex M - Instruction for Use Table of Contents 1 Symbols of Contraindications, Warnings, Cautions, and Specifications ....... 3 1.1 1.2 1.3 1.4 Contraindications ................................................................................................................................. 3 Warnings ...............................................................................................................................................
Blackrock CerePlex M - Instruction for Use 1 Symbols of Contraindications, Warnings, Cautions, and Specifications IEC60101-0102 Danger of Electrostatic Discharge (ESD) EN-980 Caution IEC60417-5036 Dangerous voltage IEC60417-5019 Protective earth (ground) IEC60417-5021 Equipotentiality Connector IEC606417-5335 Type of CF Applied Part 1.1 Contraindications • • The CerePlex M is part of a recording system and should not be used in applications involving stimulation.
Blackrock CerePlex M - Instruction for Use • This product is for animal research only. 1.4 Specifications Model Name Blackrock CerePlex M Power Requirements ±3 VDC, 150 mAmps maximum load Resolution 16-bit Sampling Frequency 30ksps Mode of Operation Continuous Input Frequency Range 0.3 Hz – 7.
Blackrock CerePlex M - Instruction for Use 2 Introduction The Blackrock CerePlex M provides an interface between the Cerebus Bio-potential recording system and up to three 32-channel microelectrode arrays for high fidelity transmission and recording of extracellular spikes and local field potentials from the brain. The Blackrock CerePlex M converts analog signals to digital format right at the recording site which dramatically reduces the noise introduced to the signal during transmission.
Blackrock CerePlex M - Instruction for Use 3 Hardware 3.1 Blackrock CerePlex M Pin-out The CerePlex M has three different configurations which are 32-channel, 64-channel and 96channel. The differences can be distinguished easily be recognizing the quantity of banks on the board. For 32-channel CerePlex M, there is only one bank, bank A. For 64-channel CerePlex M, there are two banks, bank A and bank B, but bank B could be on either left or right side of bank A.
Blackrock CerePlex M - Instruction for Use on. LED2 will blink on a one second interval as receiving correct clock cycle. LED3 only lights up when the conversion of analog to digital is saturated. 4 Instruction for Assembly 1. The following instructions are for 96-channel CerePlex M. However, the 32 and 64-channel CerePlex M are still applicable. 2. Turn off the power on the Digital Hub 128 before connecting. 3. Plug the input connector on the CerePlex M main board to the electrode termination. 4.
Blackrock CerePlex M - Instruction for Use This constitutes the sole warranty made by Blackrock, Inc. There are no other warranties, expressed or implied, which extend beyond those described herein or to anyone other than the original purchaser, including the implied warranties of merchantability and fitness for a particular purpose. In no event shall Blackrock Microsystems, Inc.
