Connect2Home Smartphone Application User Manual
Table of Contents 1. Introduction _________________________________________________________ 1 2. Connect2Home for iPhone _____________________________________________ 2 3. Connect2Home for Android ___________________________________________ 11 Information and illustrations are subject to change within this document. Blaupunkt reserves the right to alter the specification and product design at anytime without notice.
1. Introduction Features The Blaupunkt Connect2Home app is a free smartphone application designed to assist our SA and SH-series GSM alarm system users by providing remote system control and programming functions. The application operates by sending SMS command message to your Control Panel. The features of Connect2Home application include: Remote System Control You can remotely Away Arm / Home Arm / Disarm your SA-series or SH-series alarm system by sending SMS command to the Control Panel.
2. Connect2Home For iPhone Search for “Connect2Home” in Apple App Store. Download and run the app Panel Selection Menu Upon starting the application, you will first enter Panel Selection menu. - Panel Name: The name the Control Panel is recognized in the app. - Panel SIM: The mobile number of the SIM Card inserted in the Control Panel. - PIN Code: Enter a User PIN Code programmed in the Control Panel. Refer to your Control Panel setting for detail.
Delete Panel Panel Main Menu If you want to remove the panel, press Press the panel name under Panel Selection Menu to enter Panel Main Menu “Remove.” Press the icon, then “Delete” to remove the panel from the application. Edit Panel Setting You can edit your control panel information by pressing “Edit.” Enter the new panel name, panel SIM card number, PIN Code and the SMS keyword you desired. Press “Done” to confirm when finished.
Away Arm / Home Arm / Disarm PIN Setting To change system mode, select the icon for Arm / Home / Disarm respectively. A SMS message edit screen will appear for you to confirm. Press “Send” to send the SMS command to panel. The PIN Setting Menu allows you to edit User PIN Codes and SMS Keyword. Select the code you want to edit, enter the information and press “Save”. A SMS message edit screen will appear for you to confirm. Press “Send” to send the SMS command to panel.
Select the option you want to edit, you will NOTE: Connect2Home app supports editing for User PIN Code 1 ~ 4. For SH3000 Control Panel which supports 10 User PIN Codes, only the first 4 can be edited via the app When you change User PIN Code 1 in the app and send to Control Panel. The PIN Code stored in Edit Panel information will be updated automatically with the new User PIN Code 1.
Enter the telephone number for reporting, Report Setting and select report type and events. If you want to delete the telephone number, enter keep the telephone number blank The Report Setting Menu allows you to edit your telephone numbers for reporting. Press “Save”. A SMS message edit screen will appear for you to confirm. Press “Send” to send the SMS command. NOTE: Select the telephone number you want to edit. 6 Connect2Home app supports editing for telephone number 1 ~ 6.
Device Setting Edit Device The Device Setting Menu allows you to edit device, control Siren and Power Switches, or request PIR camera to take a picture (SH3000 only). The Edit Device option allows you to edit a device name, and set attribute for Door Contact, PIR Sensor and PIR Camera (SH3000 only). Select the Zone number of the device you want to edit and enter a new name, For Door Contact, PIR Sensor and PIR Camera, please select an attribute.
Siren Control (Optional Bellbox Required) confirm the mode change. Outdoor When set to Disabled, the Bellbox will not make any sound when system mode is changed. The Siren Control option allows you to edit Siren settings if you have included BX-S1 Outdoor Bellbox in your alarm system. This function is only available via Connect2Home app for SA2700 and not available from panel LCD menu.
PSS Control (Optional Power Switch required) Capture Image (SH3000 only) SH3000 panel can be controlled remotely via SMS command to take a picture with its PIR Camera. The picture will be uploaded according to the Control Panel setting. You can control Power Switches in your alarm system remotely with PSS Control function. On – The Power Switch at selected Enter the.zone number of your PIR Camera, channel will be turned on. then presses “Capture Image” to send the SMS command.
For High/Low Temperature condition, set Home Automation Setting (Optional the temperature threshold for the Power Switch to be activated/deactivated. Power Switch required) The Home Automation Setting enables you to program Power Switches to turn on/off for set duration according to different conditions For Time condition, set the time when the Power Switch deactivated.
3. Connect2Home For Android Search for “Connect2Home” in Google Play. Download and run the app Panel Selection Menu Upon starting the application, you will first enter Panel Selection menu. - Panel Name: The name the Control Panel is recognized in the app. - Panel SIM: The mobile number of the SIM Card inserted in the Control Panel. - PIN Code: Enter a User PIN Code programmed in the Control Panel. Refer to your Control Panel setting for detail.
Panel Main Menu Away Arm / Home Arm / Disarm Press the panel name under Panel Selection Menu to enter Panel Main Menu To change system mode, select the icon for Arm / Home / Disarm respectively to send the SMS command to panel. Sync with Panel Press the Menu button on you Android phone to bring up the “Sync” option. Press “Sync” to send an SMS command to Control Panel requesting it to report back its current mode.
Press the Menu button on you Android PIN Setting phone to bring up the “Sync” option. Press “Sync” to send an SMS command to Control Panel requesting it to update User PIN Code setting. Once your phone receives the SMS response message from the Control Panel, the app will update the User PIN setting accordingly The PIN Setting Menu allows you to edit User PIN Codes and SMS Keyword.
When you are satisfied with all of your Alarm Setting alarm settings, press “Save” to send the SMS command to panel. The Alarm Setting Menu allows you to edit alarm related configuration. You can press the “Menu” button on your Android phone to bring up the “Sync” options and choose to sync either the configurations or high/low temperature setting.
Enter the telephone number for reporting, Report Setting and select report type and events. If you want to delete the telephone number, enter keep the telephone number blank. Press “Save” to send the SMS command. The Report Setting Menu allows you to edit your telephone numbers for reporting. You can press the “Menu” button on your Android phone to bring up the “Sync” options and choose to sync either Telephone Number 1~3 or 4~6.
Device Setting Edit Device The Device Setting Menu allows you to edit device, control Siren and Power Switches, or request PIR camera to take a picture (SH3000 only). The Edit Device option allows you to edit a device name, and set attribute for Door Contact, PIR Sensor and PIR Camera (SH3000 only).
Siren Control (Optional Bellbox Required) Outdoor The Siren Control option allows you to edit Siren settings if you have included BX-S1 Outdoor Bellbox in your alarm system. “Device Type” information will only be updated after you successfully synced with the Control Panel Select the function you want to edit and choose to enable or disable the function. Press “Save” to send the SMS command to panel.
When set to Disabled, the Bellbox will not PSS Control (Optional Power Switch required) make any sound when system mode is changed. You can control Power Switches in your alarm system remotely with PSS Control function. This function is only available via Connect2Home app for SA2700 and not available from panel LCD menu.
Capture Image (SH3000 only) Home Automation Setting (Optional SH3000 panel can be controlled remotely via SMS command to take a picture with its PIR Camera. The picture will be uploaded according to the Control Panel setting. Power Switch required) The Home Automation Setting enables you to program Power Switches to turn on/off for set duration according to different conditions The follow conditions are available for setting: Arm – Home – When the system is Away Armed. When the system is Home Armed.
For High/Low Temperature condition, set the temperature threshold for the Power Switch to be activated/deactivated. For Time condition, set the time when the Power Switch deactivated. should be activated/ For Alarm Event condition, set the events for the Power Switch to be activated/deactivated, you can set more than one events Press “Save”. The phone will send a SMS command to panel to program the Home Automation setting.
Blaupunkt Competence Center Security & Care Azure Security & Care Corporation www.blaupunkt.com 6F., No.1, Lane 250, Sinhu 2nd Rd.
