Blueprint Lab is an Australian company

specialising in the development of robotics for

the subsea environment. Our Reach System

robotic manipulators are a capability multiplier

for inspection class subsea vehicles and enable

operations in complex and conﬁned spaces.

MULTI-FUNCTION

MANIPULATORS

SINGLE AND DUAL

FUNCTION ACTUATORS

Applications include:

Dexterous probe articulation for crack and

corrosion measurement

Sample collection and selective sterilisation

Sonar and camera scanning

UIED counter-measures

A NEW

GENERATION

OF SUBSEA

ROBOTICS

Blueprint Lab

is an Australian company

Applications include:

A NEW

GENERATION

OF SUBSEA

ROBOTICS

DEXTEROUS

INTELLIGENT

TOUGH

Seven Functions

Built-in Kinematics

Summary of content (4 pages)

PAGE 1
A NEW GENERATION OF SUBSEA ROBOTICS Blueprint Lab is an Australian company specialising in the development of robotics for the subsea environment. Our Reach System robotic manipulators are a capability multiplier for inspection class subsea vehicles and enable operations in complex and confined spaces.
PAGE 2
REACH 5 MINI The Reach 5 Mini is a leap in miniature subsea manipulation technology. It builds on patented modular designs to create a highly durable and light weight 5-Function manipulator, capable of performing dexterous subsea tasks. Available in multiple configurations, it is easily tailored to meet application specific requirements. Independent axes allow for quick end-effector change-out. Feedback of position and force provides active self-protection.
PAGE 3
REACH SYSTEM 1 REACH SYSTEM 1 Our Reach System 1 actuators are small (40mm OD), light-weight, and proven on numerous subsea platforms operating in the field. Capable of operating at a depth of 300m, Reach System 1 modules are tough, reliable, and allow for advanced inspection and intervention in complex environments. Active joint compliance provides self-protection against impact. RS1-1100 INLINE ROTATE RS1-1100 is a miniature, inline rotational actuator.
PAGE 4
REACH SYSTEM 2 (Scheduled Q3/4 2019) REACH 7 DEXTEROUS Seven Functions INTELLIGENT Built-in Kinematics Z The Reach 7 is a highly capable multi-function manipulator for the subsea environment. Six degrees of freedom coupled with an in-built kinematics engine provide dexterous movement with unmatched precision. Designed to operate in environments too dangerous for humans, the Reach 7 has a 6000m depth rating and a variety of intuitive HMI options.
