Data Sheet

RS1-1100 is a miniature, inline rotational actuator. Capable of
continuous rotation, it can be used for a variety of tasks including
sonar/video scanning or vectoring thrustors. A cable pass through
option allows for powering and controlling a variety of payloads.
RS1-1100 INLINE ROTATE
RS1-1300 is a high strength linear actuator. With multiple
end-eectors available, this device turns into a highly capable
grabber, cutter or sampler. Accurate position and force control
allows for the manipulation of delicate objects. With the addition
of a quick-release mounting kit, the jaws can be quickly orientated
to the required position.
RS1-1300 GRABBER
The dual function grabber combines high strength linear and
rotatory actuators. Internal feedback allows precise control of
position, velocity and grip force. Lighter, smaller, and more
capable than anything else in its class, RS1-2130 extends the
capability of small unmanned vehicles to manipulate and recover
objects in cluttered and complex environments.
RS1-2130 ROTATING GRABBER
RS1-1200 is a 90 degree rotary actuator. It can be used for a
variety of tasks including rotating winches, panning camer-
as and probes, or operating valves.
RS1-1400 is a higher-torque variant of the RS1-1200 with an
output of above 10Nm.
RS1-1200/RS1-1400 90° ROTATE
The RS1-2120 is a highly capable and ultra-compact pan-tilt
actuator. Configured with sonar or camera, the RS1-2120
provides operators with the ability to control sensor output
orientations manually or program autonomous angular sweeps,
making it a useful tool for search and survey operations.
RS1-2140 is a higher-torque variant of the RS1-2120 with a tilt
performance of above 10Nm.
RS1-2120/RS1-2140 PAN-TILT
Our Reach System 1 actuators are small (40mm OD), light-weight, and proven on numerous subsea platforms
operating in the field. Capable of operating at a depth of 300m, Reach System 1 modules are tough, reliable, and allow
for advanced inspection and intervention in complex environments. Active joint compliance provides self-protection
against impact.
REACH SYSTEM 1
