4

Subject to technical modiﬁcations

without notice. © 2010

5

Small overlay top door hinge planning CLIP top hinges

6

Large overlay top door hinge planning COMPACT hinges

B

Overlay

12.7

Overlay

B

1/2"

Part no.

CLIP top hinge

70T5580

Mounting plate

175H6000

Part no.

COMPACT hinge

32.4630

Mounting plate

130.1130.02

Overlay table

13

*

14 15 16 17

3 3 4 5 6

B Bore distance

* Bore at 3 then adjust 1

Assembly

Overlay table

1-1/4”

3

Bore distance
