Installation Sheet

9
Subject to technical modifications
without notice. © 2010
14
Attach covers
Attach the left and right cover plates to each lift mechanism then attach the symmetrical cover caps
Adjust and lock telescopic arms
13
1. Close and flush doors to cabinet. While pressing on
the top door, pull the bottom door open one inch.
1
2
2. Slightly open door and lock the telescopic arms
into position using the levers as shown.
Open door
enough to
lock levers
