MINIPRESS P - SPECIALISED
MINIPRESS P
• MINIPRESS P is a specialised machine to carry out precise routine drilling and
insertion of Blum fittings to maximise user efficiency.
• With additional standard inclusions such as, Hold Clamps, Quick Connect
Chucks, Calibrated Display, 16mm ruler adjustment, tool holder, MINISTICKS
and MINISTICK drilling charts the MINIPRESS P is now even safer and more
accurate.
Drilling of Various Patterns
With the multi-swivel drilling head, various drilling
patterns for furniture fixings can be set quickly, tool-
free and precisely.
Quick Connect Chuck
For quick and comfortable drill bit changeovers.
The quick connect chucks can be retrofitted
individually.
Insertion of Blum Components
MINIPRESS P is equally efficient when it comes to
inserting Blum fittings. The operation is both simple
and precise.
9 Spindle Drilling Head
For efficient drilling of hole groups within the 32 mm
system.
Practical and Precise Ruler System
The drilling distance is set easily from the front using
a calibrated spindle.
Now standard on all MINIPRESS P machines in
Australia.
8 Spindle Drilling Head
For the assembly of BOX front fixings and cabinet
profiles (runners).
Contact your local Lincoln Sentry Territory Manager for more detail
on the benefits a MINIPRESS P can bring to your business.
Description Blum No. Code
MINIPRESS P Kit
M53.1050 1-343-165
