Waste/recycle sets Waste/recycle sets Premium TANDEM and TANDEMBOX solutions for waste/recycle cabinets blum.
SERVO-DRIVE inside BLUMOTION inside 2
Waste/recycle solutions for every kitchen Blum’s new TANDEM and TANDEMBOX waste/recycle sets are the premium solutions for waste/recycle cabinets in the kitchen. They feature BLUMOTION soft closing and TANDEM smooth running action. With the SERVO-DRIVE touch-to-open feature, drawers open automatically with just a touch of the drawer front or a light pull of the handle. Customers will be amazed by the quality and ease of use.
TANDEMBOX waste/recycle set with SERVO-DRIVE Description Application Basic components ■ Pre-assembled bottom mount solution ■ TANDEMBOX heavy duty full extension drawer system ■ For 12", 15" and 18" minimum opening widths ■ For face frame and panel applications ■ Three-dimensional drawer front adjustment ■ Maximum 6 (1/4") cabinet bottom recess ■ TANDEM smooth running action ■ 175 lb static, 150 lb dynamic load rating ■ SERVO-DRIVE touch-to-open feature NOTE: Bins not included Components TANDEMBOX waste
SERVO-DRIVE inside Specifications BLUMOTION inside Drawer and cabinet specifications Front view Important 6 (1/4") minimum top clearance opening width Bin width and height must be considered when designing your cabinet (see the diagram on the left).
TANDEM waste/recycle set with SERVO-DRIVE Description Application Basic components ■ Pre-assembled bottom mount set ■ TANDEM plus BLUMOTION heavy duty full extension concealed drawer runners ■ For 12", 15" and 18" minimum opening widths ■ For 16 (5/8") max.
SERVO-DRIVE inside Specifications BLUMOTION inside Drawer and cabinet specifications Front view Important 6 (1/4") minimum top clearance opening width Bin width and height must be considered when designing your cabinet and drawer (see the diagram on the left).
TANDEM plus BLUMOTION 568R heavy duty bottom mount drawer runners Description Application Basic components ■ Full extension bottom mount concealed drawer runners with BLUMOTION ■ For 16 (5/8") max. drawer side thickness ■ For face frame and panel applications ■ Tool-free height and tilt adjustment ■ Concealed roller carriages with permanently lubricated synthetic rollers create a smooth running action ■ Locking devices enable easy drawer insertion and removal ■ Force-guided right side and ±1.
BLUMOTION inside Specifications Drawer and cabinet specifications Drawer back preparation Front view 6 (1/4") minimum top clearance opening width 7 (9/32") Ø6 x 10 bor e f or hook outside drawer width 11 (7/ 16") 13 (1/2") opening height 21 (13/16") drawer height maximum = opening minus 20 (13/16") drawer side thickness maximum 16 (5/8") 35 (1-3/8") minimum rear notch Runner comparison 13 (1/2") 568R – No vertical profile #6 wood screws 14 (9/16") bottom clearance 568H – Vertical profile Calcu
TANDEMBOX adjustments Bin configurations 15" wide cabinet — one bin 18" wide cabinet — two bins 21" wide cabinet — two bins Accommodates a wide range of standard bin sizes. Drawer adjustment Height adjustment Side adjustment Tilt adjustment Use a Phillips screwdriver to adjust drawer front up or down as shown (+/- 2 mm). Use a Phillips screwdriver to adjust drawer front left or right (+/- 2 mm). Adjust Slide gallery cover towards drawer back.
a Cross rail adjustment 1 Slide to desired position 2 Lock cross rail into place Cross rail removal 1 Unlock cross rail 2 Lift cross rail to remove Dimensions in millimeters (inch equivalents as noted) © 2011 Blum, Inc.
TANDEM adjustments Bin configurations 15" wide cabinet — one bin 18" wide cabinet — two bins 21" wide cabinet — two bins Accommodates a wide range of standard bin sizes. Detailed drawings of recommended drawer box specifications are available at blum.com. Drawer insertion and removal Insertion Removal Place drawer on runners and close. Locking devices will automatically connect to runners.
Why choose Blum Blum, Inc. is a leading manufacturer of functional hardware for the kitchen cabinet and commercial casework industries specializing in lift systems, concealed hinges and drawer runner systems. Virtually all of the hardware needed to assemble and make cabinets functional is available within the wide range of quality Blum products. Blum supports the U.S.
Blum, Inc. 7733 Old Plank Rd. Stanley, NC 28164 800-438-6788 fax 704-827-0799 blum.com Please visit blum.com for information on other Blum products. Technical specifications subject to change without notice. LIT.WRS1000.08.11 © 2011 Blum, inc.
