Data Sheet

Advanced Technologies:
Patented all-digital amplifier operating at 350 kHz provides high
power levels with extremely low distortion. State-of-the-art digital
processing circuits render pristine sound quality. Advanced limiter
algorithms provide precise system control without harming sound
quality at even the most aggressive levels. Universal AC voltage
compatibility.
Power Amplifiers and Processor:
Dual amplifiers, one per driver, with 2400W total music power
Driver Complement:
Dual Apogee 15"(381mm) permanent magnet cone-type drivers are
treated with a waterproofing compound, providing resistance to
moisture, and enabling long-term stability of cone resonance and
cone mass parameters; also treated with Ferrofluid
®
for greater
power handling capability, lower distortion, and control of short-
term impedance rise
Handles:
Four handles designed as an integral part of the enclosure
(no moving parts)
Grille:
Powder-coated, diamond-punched steel with acoustic foam covering
Trim:
Optional protective steel pieces on top and bottom edges; powder-
coated for durability
Rigging Hardware:
Four 12 gauge steel nutplates, mounted two on top and two on
bottom, recessed so as to be nominally flush; accepts 3/8"-16
thread, nutplates are backed with 12 gauge steel internal brackets
(10mm nutplate or Aeroquip™ Pan fittings optional)
Enclosure Type:
20° trapezoidal, optimally-vented bass
Cabinet Construction:
Multi-ply birch with stainless steel fasteners
Warranty:
Three (3) years, limited
Self-Powered Concert
Subwoofer System
Electronics Specifications:
Engineering Data:
Description:
Format:
Self-contained dual power amplifiers with
integrated processing electronics
Dispersion:
Omni-directional
Frequency Response (1m on axis):
34 Hz to 100 Hz ± 3 dB
Max. SPL (@1m):
131 dB cont./137 dB peak
Dimensions:
32"(813mm) W x 22.5"(572mm) H x
24"(610mm) D
Weight:
145 lb. (65.8 kg)
Input:
XLR connectors, active balanced 35k ohms
Loop-through Output:
Daisy-chain audio signal, XLR type connector
Amplifier Power:
2400W total music power, dual amplifiers
RMS Limiter:
100 ms long duration protection
Peak Limiter:
3 to 5 ms fast-acting transient protection
Cooling:
Passive using external heat sinks
Voltage:
115V AC or 230V AC selection switch, Neutrik
Powercon™ AC inlet with loop-through; power
cable included
The APL-10 self-powered subwoofer
incorporates internal amplifiers and
intelligent, front-end signal processing into a
robust enclosure designed for concert
touring, AV presentations, and fixed
installations. The dual cone drivers provide
powerful, deep bass with rapid transients for
a crisp, clean, and accurate sonic image.
APL-10
