General Purpose LCD Monitors UML-151-90 | UML-171-90 | UML-191-90 en User’s Manual
General Purpose LCD Monitors Table of Contents | en iii Table of Contents 1 Safety 1 1.1 Important Safety Instructions 1 1.2 Safety Precautions 3 1.3 Important Notices 3 1.4 Customer Support and Service 8 2 Unpacking 9 2.1 Parts List 9 3 Exploded View 10 4 Remote Control 12 4.1 Remote Control Battery Installation 12 5 Description 13 5.1 Features 13 5.2 Power 13 6 Installing the Monitor 13 6.1 Ventilation 13 6.2 Mounting the Monitor 14 6.2.
iv 8 en | Table of Contents General Purpose LCD Monitors Power Management 22 8.1 Power Consumption 22 8.2 LED Indicator 22 9 Trouble Shooting Guide 23 10 Maintenance 24 11 Technical Specifications 25 F.01U.127.338 | 2.0 | 2009.05 User’s Manual Bosch Security Systems, Inc.
General Purpose LCD Monitors Safety | en 1 Safety 1.1 Important Safety Instructions 1 Read, follow, and retain for future reference all of the following safety instructions. Heed all warnings on the unit and in the operating instructions before operating the unit. 1. Cleaning - Unplug the unit from the outlet before cleaning. Follow any instructions provided with the unit. Generally, using a dry cloth for cleaning is sufficient, but a moist fluff-free cloth or leather shammy may also be used.
2 en | Safety General Purpose LCD Monitors 11. Power sources - Operate the unit only from the type of power source indicated on the label. Before proceeding, be sure to disconnect the power from the cable to be installed into the unit. – For battery powered units, refer to the operating instructions. – For external power supplied units, use only the recommended or approved power supplies. – For limited power source units, this power source must comply with EN60950.
General Purpose LCD Monitors 1.2 Safety | en 3 Safety Precautions DANGER! High risk: This symbol indicates an imminently hazardous situation such as “Dangerous Voltage” inside the product. If not avoided, this will result in an electrical shock, serious bodily injury, or death. ! ! ! i 1.3 WARNING! Medium risk: Indicates a potentially hazardous situation. If not avoided, this could result in serious bodily injury or death. CAUTION! Medium Risk Indicates a potentially hazardous situation.
4 en | Safety General Purpose LCD Monitors Coax grounding: – – Ground the cable system if connecting an outside cable system to the unit. Connect outdoor equipment to the unit's inputs only after this unit has had its grounding plug connected to a grounded outlet or its ground terminal is properly connected to a ground source. – Disconnect the unit's input connectors from outdoor equipment before disconnecting the grounding plug or grounding terminal.
General Purpose LCD Monitors Safety | en 5 PoE - Never supply power via the Ethernet connection (PoE) when power is already supplied via the power connector. Power disconnect - Units have power supplied whenever the power cord is inserted into the power source. The power cord is the main power disconnect for all units. Power lines - Do not locate the camera near overhead power lines, power circuits, or electrical lights, nor where it may contact such power lines, circuits, or lights.
6 en | Safety General Purpose LCD Monitors INFORMATIONS FCC ET ICES (modèles utilisés aux États-Unis et au Canada uniquement) Ce produit est conforme aux normes FCC partie 15. la mise en service est soumises aux deux conditions suivantes: – cet appareil ne peut pas provoquer d'interférence nuisible et – cet appareil doit pouvoir tolérer toutes les interférences auxquelles il est soumit, y compris les interférences qui pourraient influer sur son bon fonctionnement.
General Purpose LCD Monitors Safety | en 7 Copyright This user guide is the intellectual property of Bosch Security Systems, Inc. and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly. NOTICE! This user guide has been compiled with great care and the information it contains has been i thoroughly verified. The text was complete and correct at the time of printing.
8 1.4 en | Safety General Purpose LCD Monitors Customer Support and Service If this unit needs service, contact the nearest Bosch Security Systems Service Center for authorization to return and shipping instructions. Service Centers USA Telephone: 800-366-2283 or 585-340-4162 Fax: 800-366-1329 Email: cctv.repair@us.bosch.com Customer Service Telephone: 888-289-0096 Fax: 585-223-9180 Email: security.sales@us.bosch.
General Purpose LCD Monitors 2 Unpacking | en 9 Unpacking This equipment should be unpacked and handled with care. If an item appears to have been damaged in shipment, notify the shipper immediately. Verify that all the parts listed in the Parts List below are included. If any items are missing, notify your Bosch Security Systems Sales or Customer Service Representative. The original packing carton is the safest container in which to transport the unit and must be used if returning the unit for service.
10 3 en | Exploded View General Purpose LCD Monitors Exploded View Figure 3.1 Front Panel Reference # Button Description 1 Input Button Selects the signal to be displayed. 2 Menu Button Selects the on-screen display (OSD). 3 Adjusts the value when in Scrolls up in the OSD. the OSD. 4 Adjusts the value when in Scrolls down in the OSD. the OSD or auto adjusts when in PC mode. 5 Decreases the value when in Scrolls left in the OSD. the OSD. Decreases volume.
General Purpose LCD Monitors Figure 3.2 Exploded View | en 11 Bottom Panel Reference # Connector Description 1 DC 12 V IN UML-151-50: 3.3 A UML-171-50: 4.1 A UML-191-90: 4.
12 en | Remote Control 4 General Purpose LCD Monitors Remote Control This section details the functions and the usage of the Bosch remote control. Button POWER SOURCE APC (Auto Function Turns the power ON and OFF. Selects the PC or Video source. Selects the Picture mode. Continuously press this button Picture Control) to change the selection. ACC (Auto Color Selects the Color mode. Continuously press this button Control) AV1 AV2 S-VIDEO to change the selection. Selects the AV1 mode.
General Purpose LCD Monitors 5 Description | en 13 Description The Bosch General Purpose Family of LCD monitors display PAL or NTSC standard color pictures in CCTV systems. Two (2) looping Composite Video BNC connector inputs and one (1) looping Y/C (S-Video) input using a 4-pin mini-DIN are included with each model. In addition, each works with a VGA signal. Monitor control functions are accessed via the front panel push buttons and the multilanguage On-screen Display (OSD). See Figure 3.
14 en | Installing the Monitor 6.2 General Purpose LCD Monitors Mounting the Monitor The UML-151-90, UML-171-90, and the UML-191-90 are designed for use on a desktop or mounted to a wall or rack. 6.2.1 Desktop Installation The Bosch General Purpose monitors are delivered with a 3-pole US-style power cord and a 3pole Euro-style power cord. Use the US-style power cord where 120 VAC, 60 Hz power is available; use the Euro-style power cord where 230 VAC, 50 Hz power is available.
General Purpose LCD Monitors 2. Installing the Monitor | en 15 Mount the unit to the mounting device (not provided) using the four (4) mounting holes on the rear panel. The square mounting hole patterns are standard on 100 mm (3.9 in.) centers. Four (4) M4 x 10 mm screws are required and are provided with the Bosch mounting kit. Figure 6.2 Mounting the Device 6.
16 6.4 en | Installing the Monitor General Purpose LCD Monitors Connecting the Y/C (S-Video) Signal to the Monitor There is one (1) mini-DIN type connector for the S-Video (Y/C) input (see Figure 6.3). NOTE: Both Y and C inputs are terminated with 75 ohm. Figure 6.3 6.
General Purpose LCD Monitors Figure 6.6 Navigating the Monitor | en 17 Multiple Monitor Configuration Reference # Description 1 Video Camera 2 VIDEO 1 (AV1) IN 3 VIDEO 1 (AV1) OUT 7 Navigating the Monitor 7.1 Navigating the Front Panel Use the front panel to make any necessary OSD adjustments to the UML-151-90, UML-171-90, or the UML-191-90. See the figure below for an explanation of the front panel. Figure 7.
18 7.2 en | Navigating the Monitor General Purpose LCD Monitors Navigating the Monitor On-screen Display (OSD) The UML-151-90, UML-171-90, and the UML-191-90 have two (2) modes: Video and VGA. The LCD is programmed through the on-screen display (OSD) menus and submenus where an operator can select operating parameters. To access the OSD menus, press the Menu button. Use the front panel of the monitor to make any necessary adjustments to the OSD. To navigate the set up menus, follow the steps below: 1.
General Purpose LCD Monitors 7.3 Navigating the Monitor | en 19 On-screen Display Menus There are three (3) on-screen menus that allow you to customize your settings. Press the Menu button to access the OSD menu. Icon Menu Function Custom Adjusts the Brightness, Contrast, Color, Tint, and the Sharpness level for video performance of the OSD. (The menu options differ between the Video and PC modes.
20 en | Navigating the Monitor General Purpose LCD Monitors Submenu Definition Brightness Adjusts the brightness level for video performance (range 0-100). Contrast Adjusts the contrast level for video performance Color Adjusts the overall intensity of the screen (range 0-100). Tint Adjusts the tint of the picture (range 0-100). NTSC only. Sharpness Adjusts the sharpness level for video performance (range 0-100). (range 0-100). 7.
General Purpose LCD Monitors Navigating the Monitor | en Submenu 21 Definition Picture Mode Selects the automatic picture control mode. Choices are: (Video Mode) Custom: User selected values of the Custom menu are applied. Dynamic: Automatically adjusts the Brightness, Contrast, and Sharpness, maximizing the video quality in the picture. Standard: Applies factory default values. Picture Mode (PC Selects the automatic picture control mode.
22 en | Power Management General Purpose LCD Monitors Submenu Definition Reset Restores default settings. Language Adjusts the language of the OSD. Choices are: English, French, OSD Tones Selects the type of background for the OSD menu. Choices are: Blue Screen Enables or disables video loss indication. Choices are: German, Italian, Dutch, Spanish, and Portuguese. Transparency and Blue. On: displays a blue background when video loss is detected.
General Purpose LCD Monitors 9 Trouble Shooting Guide | en 23 Trouble Shooting Guide Problem Solution No image is displayed on screen – Check that the power cord of the monitor is securely connected into the wall outlet or grounded extension cable or strip. – Power switch should be in the ON position and the LED lit. – Check that the Brightness and/or Contrast adjustments of the display have not been turned down to minimum levels.
24 en | Maintenance 10 General Purpose LCD Monitors Maintenance To clean the LCD panel, wipe off water droplets or oil immediately with absorbent cotton or a soft lint-free cloth. Staining and discoloration may occur if left on the panel for long periods. If the surface (polarizer) of the LCD panel is dirty or stained, use absorbent cotton or a soft lint-free cloth to remove the residue as follows: 1. 2. Turn off the computer or display. Do not spray any liquid directly on the screen.
General Purpose LCD Monitors 11 Technical Specifications | en 25 Technical Specifications UML-151-90 UML-171-90 UML-191-90 Electrical Rated Voltage 120/230 VAC, 50/60 Hz 120/230 VAC, 50/60 Hz 120/230 VAC, 50/60 Hz Voltage Range 100-240 VAC 100-240 VAC 100-240 VAC Power at Rated Voltage 25 W operation, 5 W 40 W operation, 5 W 45 W operation, 5 W standby standby standby Sync Format PAL/NTSC PAL/NTSC PAL/NTSC LCD Panel TFT LCD TFT LCD TFT LCD Screen Size (H x V) 304.1 x 228.
26 en | Technical Specifications General Purpose LCD Monitors PC Input Analog RGB 0.7 Vp-p (0.
General Purpose LCD Monitors Technical Specifications | en 27 Dimensions (W x H x D) 352 x 355 x 200 mm 382.4 x 390.5 x 200.0 mm 430 x 428 x 200 mm (13.86 x 14.0 x 7.9 in.) (15.1 x 15.4 x 7.9 in.) (16.9 x 16.9 x 7.9 in.) 352 x 292 x 58 mm 382.4 x 330.0 x 58.7 mm 420 x 374 x 60 mm (13.9 x 11.5 x 2.2 in.) (15.1 x 13.0 x 2.3 in.) (16.9 x 14.7 x 2.4 in.) Monitor with Base 3.7 kg (8.1 lb) 5.2 kg (11.4 lb) 5.2 kg (11.4 lb) Monitor Only 2.5 kg (5.6 lb) 3.8 kg (8.4 lb) 4.1 kg (9.
28 en | Technical Specifications F.01U.127.338 | 2.0 | 2009.05 General Purpose LCD Monitors User’s Manual Bosch Security Systems, Inc.
