Pre-position
To move the camera to a pre-position, click one of the buttons
numbered one to six.
To store the current position of the camera in a pre-position:
1. Position the camera.
2. Enter a pre-position number.
3. Click Set.
3.1.4 View Control ROI
(not for SD cameras)
When the stream 2 encoder stream is set for Region of Interest
(ROI), a specific type of View Control panel is activated.
Refer to Section 9.2.1 H.264 settings, page 52 for more
information on setting up stream 2. (If dual ROI is available,
open the camera in a second browser window to set up the
second ROI on stream 2.)
Zoom
To zoom in on a region of the stream 2 image:
 Click and hold to zoom in; click and hold to
zoom out.
 Click to see the full image.
Select an area
To select a particular region of the image:
1. Click and hold the arrows to move up and down, and from
side to side through the image.
2. Click and hold the center area to move in all directions.
