Set positions
To store the current view:
1. Select a region of interest.
2. Click Set.
3. Click a number.
To display a pre-set region of interest, click one of the buttons
numbered one to six.
Intelligent Tracking
For cameras with the ability to track movement, options for
tracking objects within the region of interest are displayed in
the Intelligent Tracking panel.
When on, the tracking icon is displayed on the image
together with the lines that track moving objects.
Select Off, Auto or Click. If Click is selected, use the mouse to
click on an object to track it.
3.1.5 Cameras with alarm and relay I/O
(only for cameras with I/O connections)
The alarm input and the relay output are displayed in the Digital
I/O panel next to the camera image.
The alarm symbol is for information and indicates the input
status of the alarm input:
– Active 1 = Symbol lights
– Active 0 = Symbol not lit.
The camera relay allows the operation of an external device (for
example, a light or a door opener).
 To operate, click the relay symbol.
– The symbol is red when the relay is activated.
