7.2 LIVEPAGE Functions
You can adapt the Livepage functions to meet your
requirements. Choose from a variety of different options for
displaying information and controls.
1. Mark the checkboxes for the functions to be shown on the
Livepage. The selected elements are checked.
2. Look at the Livepage to see if the desired items are shown.
Note:
Only those checkboxes that are relevant for your type of camera
are shown.
7.2.1 Transmit audio
(only for cameras with audio)
When selected, the audio from the camera (if on) is sent to the
computer. This setting applies only to the computer on which it
is made.
7.2.2 Lease time [s]
The lease time in seconds determines the time beyond which a
different user is authorized to control the camera after no
further control signals are received from the current user. After
this time interval, the camera is automatically enabled.
7.2.3 Show event log
The event messages are displayed with the date and time in a
field next to the video image.
7.2.4 Show system log
The system messages are displayed with the date and time in a
field next to the video image and provide information about the
establishment and termination of connections, etc.
7.2.5 Allow snapshots
Specify whether the icon for saving individual images should be
displayed below the live image. Individual images can only be
saved if this icon is visible.
