8.2 Picture Settings
Contrast (0...255)
Adjust the contrast with the slider from 0 to 255.
Saturation (0...255)
Adjust the color saturation with the slider from 0 to 255.
Brightness (0...255)
Adjust the brightness with the slider from 0 to 255.
8.2.1 White balance
– Indoor: Allows the camera to continually adjust for optimal
color reproduction in an indoor environment.
– Outdoor: Allows the camera to continually adjust for
optimal color reproduction in an outdoor environment.
–In Manual mode the Red, Green, and Blue gain can be
manually set to a desired position.
Apply white balance
Click Hold to put ATW on hold and save the color settings.
R-gain
In Manual white balance mode, adjust the red gain from -50 to
+50 to offset the factory white point alignment (reducing red
introduces more cyan).
G-gain
In Manual white balance mode, adjust the green gain from -50
to +50 to offset the factory white point alignment.
B-gain
In Manual white balance mode, adjust the blue gain from -50 to
+50 to offset the factory white point alignment (reducing blue
introduces more yellow).
It is only necessary to change the white point offset for special
scene conditions.
Default
Click Default to set all video values to their factory setting.
