Camera Browser Interface Camera | en 45
Bosch Security Systems Software manual AM18-Q0635 | v5.8 | 2013.05
8.4 Encoder Settings
The Encoder Profile, Encoder Streams, and Encoder Regions
settings allow you to adapt the video data transmission
characteristics for your operating environment (network
structure, bandwidth, data structures). The camera
simultaneously generates two H.264 video streams and an
M-JPEG stream for transmission. An I-frame only stream is used
for recording.
Select the compression settings of these streams individually,
for example, one setting for transmissions to the Internet and
one for LAN connections.
Refer to Section 9.1 Encoder Profile, page 48 for more
information on setting up the encoder profile.
Refer to Section 9.3 Encoder Regions, page 54 for more
information on setting up the encoder streams.
