58 en | Recording Camera Browser Interface
AM18-Q0635 | v5.8 | 2013.05 Software manual Bosch Security Systems
10.1.3 Activating and configuring storage media
Available media or iSCSI drives must be transferred to the
Managed storage media list, activated, and configured for
storage.
Note:
A iSCSI target storage device can only be associated with one
user. If a target is being used by another user, ensure that the
current user no longer needs the target before decoupling that
user.
1. In the Storage overview section, double-click the required
storage medium, an iSCSI LUN or one of the other
available drives.
– The medium is added as a target in the Managed
storage media list.
– Newly added media is shown as Not active in the
Status column.
2. Click Set to activate all media in the Managed storage
media list.
– The Status column shows all media as Online.
3. Check the box in the Rec. 1 or Rec. 2 column to specify the
recording tracks to be recorded on the target selected.
10.1.4 Formatting storage media
All recordings on a storage medium can be deleted at any time.
Check the recordings before deleting and back-up important
sequences on the computer's hard drive.
1. Click a storage medium in the Managed storage media list
to select it.
2. Click Edit below the list.
3. Click Format in the new window to delete all recordings in
the storage medium.
4. Click OK to close the window.
10.1.5 Deactivating storage media
A storage medium in the Managed storage media list can be
deactivated. It is then no longer used for recordings.
