Camera Browser Interface Alarm | en 67
Bosch Security Systems Software manual AM18-Q0635 | v5.8 | 2013.05
3. Enter the password in the Destination password field.
4. Set the user password of all the remote stations to be
accessed using this password.
Setting destination 10 to the IP-address 0.0.0.0 overrides its
function as the tenth address to try.
11.1.5 Video transmission
If the device is operated behind a firewall, select TCP (HTTP
port) as the transfer protocol. For use in a local network, select
UDP.
To enable multicast operation, select the UDP option for the
Video transmission parameter here and on the Network page.
Note:
In the event of an alarm, a larger network bandwidth is
sometimes required for additional video streams (if multicast
operation is not possible).
11.1.6 Stream
Select a stream to be transmitted.
11.1.7 Remote port
Select an appropriate browser port depending on the network
configuration. The ports for HTTPS connections are only
available if the On option in SSL encryption is selected.
11.1.8 Video output
If a decoder device is used, select the analog video output to
which the signal should be switched. If the destination device is
unknown, select the First available option. This places the
image on the first video output with no signal.
The connected monitor only displays images when an alarm is
triggered.
11.1.9 Decoder
If a split image is set for the selected video output, select a
decoder to display the alarm image. The decoder selected
determines the position of the image.
