Camera Browser Interface Network | en 95
Bosch Security Systems Software manual AM18-Q0635 | v5.8 | 2013.05
13.5 Accounts
Four separate accounts can be defined for posting and
recording export.
Type
Select either FTP or Dropbox for the account type.
Account name
Enter an account name to be shown as the target name.
IP address
For an FTP server, enter the IP address.
Login
Enter your login name for the account server.
Password
Enter the password that gives access to the account server.
Click Check to confirm that it is correct.
Path
Enter an exact path to post the images on the account server.
Click Browse... to browse to the required path.
Maximum bit rate
Enter the maximum bit rate in kbps that will be allowed when
communicating with the account.
