RPS D5500CU en Installation Guide
RPS Table of Contents | en 3 Table of Contents 1 Legal 5 1.1 Trademarks 5 1.2 Software License Agreement 5 2 Introduction 8 2.1 Release Notes 8 2.2 Minimum System Requirements 8 2.2.1 RPS Minimum System Requirements 8 2.2.2 Minimum System Requirements for SQL Express Only 9 2.2.3 RPS and SQL Express on the Same PC Minimum Requirements 10 2.2.4 Minimum System Requirements for RPS and SQL Express on a PC with Vista 10 3 Installing RPS 11 3.1 Hardware Installation 11 3.1.
en | Table of Contents 6 RPS RPS Setup and Maintenance 79 6.1 Modifying RPS 79 6.2 Repairing RPS 80 6.3 Removing RPS 80 7 Logging Into RPS 81 7.1 First Time Log-In 81 7.2 Changing the Password 82 8 Recovering Old Database Files 83 9 RPS Operation and Control Panel Account Notes 84 9.1 RPS Notes 84 9.1.1 Installation and Administration 84 9.1.2 General Operation 84 9.1.3 Modems 84 9.2 Control Panel Account Notes 85 9.2.1 2000 Series 85 9.2.
RPS Legal | en 1 Legal 1.1 Trademarks – 5 Microsoft®, Windows® 2000, XP, VistaTM UltimateTM and SQL ServerTM are either registered trademarks or trademarks of Microsoft Corporation in the United States and/ or other countries. – InstallShield® is a registered trademark and service mark of Acresso Software in the – Intel® is a registered trademark of Intel Corporation in the United States and other United States and other countries. countries.
en | Legal RPS 3. OWNERSHIP AND PROPRIETY RIGHTS: Although the diskette/media containing the Software is yours, the Software is owned and copyrighted by Bosch and/or its suppliers.
RPS Legal | en 7. 7 EXPORT LAWS, APPLICABLE LAW: If you, the licensee under this License, are not a U.S. citizen or you will take delivery of the Software outside the United States, Bosch will secure the necessary U.S. Government authorizations for exportation of the Software to your country of destination. You agree to not reexport the Software from that destination to another foreign country without complying with all applicable U.S. Government restrictions and requirements.
en | Introduction 2 RPS Introduction RPS (Remote Programming Software) is a Windows®-based account management and control panel programming utility designed to remotely set up and program specific control panels. 2.1 Release Notes The Release Notes provide additional information about RPS that became available after the printing of this manual. Review these notes before using RPS. The Release Notes also list control panels that are compatible with RPS. 2.2 Minimum System Requirements i 2.2.
RPS 2.2.
en | Introduction 2.2.
RPS Installing RPS | en 3 Installing RPS 3.1 Hardware Installation 3.1.1 11 Installing a Modem When using an internal modem, consult the documentation accompanying your modem for physical installation. 3.1.2 Protecting AC Power and Phone Lines Protect your hardware and data from costly damage by protecting the AC power source and the phone line for the modem. Several manufacturers offer devices that provide combined AC and telephone line protection.
en | Installing RPS RPS 3. When the startup window opens, select a language from the list provided. Refer to Figure 3.1 on page 11. An instruction window opens in the selected language. Figure 3.2 English Instruction Page From the instruction window, you can open the RPS documentation and install RPS. 4. Follow the steps listed on the instruction window for installing each component required for RPS. i 3.3 For new installations of RPS 5.x, you must install Microsoft .NETTM Framework 2.0.
RPS Installing RPS | en 3.3.2 13 Windows Installer 3.1 i NOTICE! Windows Installer 3.1 is only needed on Windows® 2000 and Windows® XP SP2 operating systems. 1. Select the Windows Installer 3.1 from the RPS installation CD-ROM, or select Install Windows Installer 3.1 from the RPS instruction dialog. 2. The Windows Installer 3.1 welcome dialog opens. Click Next. Figure 3.3 Windows Installer 3.1 Welcome Dialog 3. The License Agreement dialog opens. Click I Agree, then click Next. Figure 3.
en | Installing RPS RPS Figure 3.5 License Agreement Dialog 5. When the installation completes, click Finish to restart the PC. Figure 3.6 Windows Installer 3.1 Completing Dialog 4998141259 | 09 | 2008.10 Installation Guide Bosch Security Systems, Inc.
RPS Installing RPS | en 3.3.3 15 Installing .NET Framework 2.0 i NOTICE! .NET Framework 2.0 is not required for Windows® Vista operating systems. 1. Select Install .NET Framework 2.0 from the RPS installation CD-ROM, or select Install .NET Framework 2.0 from the RPS instruction dialog. 2. The Microsoft .NET Framework 2.0 Setup welcome dialog opens. Click Next. Figure 3.7 .NET Setup Welcome Dialog 3. The End-User License Agreement dialog opens.
en | Installing RPS RPS 4. The Installing Components dialog show the installation progress. Figure 3.9 .NET Installing components Dialog 5. When the Setup Complete dialog opens, click Finish. Figure 3.10 .NET Setup Complete Dialog 4998141259 | 09 | 2008.10 Installation Guide Bosch Security Systems, Inc.
RPS Installing RPS | en 3.3.4 17 Installing MDAC i NOTICE! MDAC is required only for Windows 2000 installations. 1. Select the MDAC installer from the RPS CD-ROM, or select Install Microsoft Data Access Components from the RPS instruction dialog. 2. The End User License Agreement dialog opens. Select I accept all of the terms of the preceding license agreement, then click Next. Figure 3.11 MDAC End User License Agreement Dialog 3. The Installing the Software dialog opens. Click Finish.
en | Installing RPS RPS Figure 3.13 3.3.5 MDAC Setup is Complete Dialog Installing SQL Express 1. Select the SQL Express installer from the RPS installation CD-ROM, or select Install Microsoft SQL Server 2005 Express SP2 from the RPS instruction dialog. The Extracting Files dialog shows briefly. Figure 3.14 2. SQL Express Extracting Files Dialog The End User License Agreement dialog opens. Select I accept the licensing terms and conditions, then click Next. Figure 3.
RPS Installing RPS | en 3. 19 The Installing Prerequisites dialog opens, Click Install. The dialog shows the progress of the installation. Figure 3.16 SQL Express Installing Prerequisites Dialog 4. The Microsoft SQL Server Installation Wizard welcome screen opens. Click Next. Figure 3.17 Microsoft SQL Server Installation Wizard Welcome Dialog 5. Bosch Security Systems, Inc. When the System Configuration Check dialog finishes, click Next. Installation Guide 4998141259 | 09 | 2008.
en | Installing RPS RPS Figure 3.18 6. SQL System Configuration Check Dialog The Microsoft SQL Server Installation dialog shows the status of the installation. When the installation finishes, click Next. Figure 3.19 4998141259 | 09 | 2008.10 Microsoft SQL Server Installation Dialog Installation Guide Bosch Security Systems, Inc.
RPS Installing RPS | en 7. 21 The Registration Information dialog opens. Click Next. Figure 3.20 SQL Registration Information Dialog 8. The Feature Selection dialog opens: a. Click the X next to Connectivity Components. b. Select Entire feature will be installed on local hard drive. c. Click Next. Figure 3.21 SQL Feature Selection Dialog Bosch Security Systems, Inc. Installation Guide 4998141259 | 09 | 2008.
en | Installing RPS RPS 9. The Authentication Mode dialog opens: a. Select Mixed Mode. b. Type a SQL Server password in both password fields. c. Click Next. Figure 3.22 i SQL Authentication Mode Dialog NOTICE! You will need the SQL Server password later when logging into RPS. The password is case sensitive. 10. The Configuration Options dialog opens. Select Enable User Instances, then click Next. Figure 3.23 4998141259 | 09 | 2008.
RPS Installing RPS | en 23 11. The Error and Usage Report Settings dialog opens. Click Next. Figure 3.24 SQL Error and Usage Report Settings Dialog 12. The Ready to Install dialog opens. Click Install. Figure 3.25 SQL Ready to Install Dialog Bosch Security Systems, Inc. Installation Guide 4998141259 | 09 | 2008.
en | Installing RPS RPS 13. The Setup Progress dialog opens. When the installation is finished, click Next. Figure 3.26 SQL Setup Progress Dialog 14. The Completing Microsoft SQL Server 2005 Setup dialog opens. Click Finish. Figure 3.27 4998141259 | 09 | 2008.10 Completing Microsoft SQL Server 2005 Setup Dialog Installation Guide Bosch Security Systems, Inc.
RPS 3.3.6 Installing RPS | en 25 Installing SQL Server Management Studio Express 1. Select the SQL Server Management Studio Express installer from the RPS installation CD-ROM, or select Install SQL Server Management Studio Express from the RPS instruction dialog. 2. The SQL Server Management Studio Express Setup dialog opens. Click Next. Figure 3.28 SQL Server Management Studio Express Setup Dialog 3. The License Agreement dialog opens.
en | Installing RPS RPS 4. The Registration Information dialog opens. Click Next. Figure 3.30 5. SQL Studio Registration Information Dialog The Feature Selection dialog opens. Click Next. Figure 3.31 4998141259 | 09 | 2008.10 SQL Studio Feature Selection Dialog Installation Guide Bosch Security Systems, Inc.
RPS Installing RPS | en 6. 27 The Ready to Install the Program dialog opens. Click Install. Figure 3.32 SQL Studio Ready to Install Dialog 7. When the installation finishes, click Finish. Figure 3.33 SQL Studio Installation Complete Dialog Bosch Security Systems, Inc. Installation Guide 4998141259 | 09 | 2008.
en | Installing RPS RPS NOTICE! Networking protocols are disabled by default in SQL Server Express. If someone simply installs SQL Server Express and chooses all the defaults, SQL Server Express can only have connections originating on the local machine where SQL Server is installed. To enable SQL Server Express to accept remote connections, configure SQL Server Express to listen on TCP/IP: i 3.
RPS Installing RPS | en 29 Figure 3.35 RPS Preparing to Install 4. When the Welcome dialog opens, click Next. Figure 3.36 RPS InstallShield Welcome Bosch Security Systems, Inc. Installation Guide 4998141259 | 09 | 2008.
en | Installing RPS RPS 5. The Choose Destination Location dialog opens. If the default directory is acceptable, click Next. Otherwise, click Browse to select a different directory, then click Next. Figure 3.37 6. RPS Choose Destination Dialog The New Database Creation dialog opens. If the default directory for the database files is acceptable, click Next. Otherwise, click Browse to select a different directory, then click Next. Figure 3.38 4998141259 | 09 | 2008.
RPS Installing RPS | en 7. 31 The Select Features dialog opens. Select the desired features and control panel types for this RPS installation, then click Next. Figure 3.39 8. RPS Select Features The Select Program Folder dialog opens. Click Next. Figure 3.40 Bosch Security Systems, Inc. RPS Select Program Folder Installation Guide 4998141259 | 09 | 2008.
en | Installing RPS RPS 9. The Start Copying Files dialog opens, listing your selections from the previous steps and confirming that the PC's hard drive has enough unused space for the RPS installation. Click Next. Figure 3.41 RPS Start Copying Files The Setup Status dialog indicates the installer's progress. 10. When the InstallShield Wizard Complete dialog opens, click Finish. The PC restarts. Figure 3.42 RPS InstallShield Wizard Complete 11.
RPS Installing RPS | en 33 13. From the Connect to Server dialog, copy the text from the Server name field into the PC's clipboard. Figure 3.43 SQL Server Connect to Server 14. In the RPS System Configuration dialog: a. Paste the text copied in the previous step into the Select or Enter SQL Server name field. b. Type a database name into the Enter SQL Database Name field. c.
en | Installing RPS RPS 15. The Create Database dialog opens. Click OK. Figure 3.45 RPS Create Database 16. Close the SQL Server Management Studio dialog. 17. Click OK to close the RPS System Configuration dialog. 18. In the RPS Logon Information dialog, enter your RPS user name and password, then click OK. Figure 3.46 RPS Logon Information 19. The Panel Filter dialog opens. If you want to see a subset of all accounts, enter the filter criteria into the Panel Information fields, then click OK.
RPS 3.4.2 Installing RPS | en 35 Installation Using SQL Server 1. Open the RPS installer from the RPS CD-ROM. 2. Select your setup language preference, then click OK. Figure 3.48 RPS Choose Setup Language 3. At the RPS InstallShield Welcome dialog, click Next. Figure 3.49 RPS InstallShield Wizard Welcome 4. The Choose Destination Location dialog opens. If the default directory is acceptable, click Next. Otherwise, click Browse to select a different directory, then click Next. Figure 3.
en | Installing RPS RPS 5. The New Database Creation dialog opens. Click Browse to select a different directory on the network. Figure 3.51 6. RPS New Database Creation In the Choose Folder dialog, browse to the desired network directory, then click OK. NOTICE! i To determine which network directory should contain the RPS database, consult your network or database administrator. RPS does not support Universal Naming Convention (UNC). Select a mapped network drive. 4998141259 | 09 | 2008.
RPS Installing RPS | en 7. 37 The New Database Creation dialog returns and shows the new directory path. Click Next. Figure 3.52 RPS New Database Creation 8. The Select Features dialog opens. Select the desired features and control panel types for this RPS installation, then click Next. Figure 3.53 RPS Select Features Bosch Security Systems, Inc. Installation Guide 4998141259 | 09 | 2008.
en | Installing RPS RPS 9. The Select Program Folder dialog opens. Click Next. Figure 3.54 RPS Select Program Folder 10. The Start Copying Files dialog opens, listing your selections from the previous steps and confirming that the PC's hard drive has enough unused space for the RPS installation. Click Next. Figure 3.55 4998141259 | 09 | 2008.10 RPS Start Copying Files Dialog Installation Guide Bosch Security Systems, Inc.
RPS Installing RPS | en 39 11. When the InstallShield Wizard Complete dialog opens, click Finish. The PC restarts. Figure 3.56 RPS InstallShield Wizard Complete 12. After logging onto the PC, start RPS either by selecting Start>Bosch>RPS 5.x, or by double-clicking the RPS 5.x shortcut on the PC's desktop. 13. In the RPS System Configuration dialog: a. Select or enter the SQL server name into the Select or Enter SQL Server name field. b. Type a database name into the Enter SQL Database Name field.
en | Installing RPS RPS 14. When the Create Database dialog opens, click OK. Figure 3.58 RPS Create Database 15. Click OK to close the RPS System Configuration dialog. 16. In the RPS Logon Information dialog, enter your RPS user name and password, then click OK. Figure 3.59 RPS Logon Information The Panel Filter dialog opens. If you want to see a subset of all accounts, enter the filter criteria into the Panel Information fields, then click OK. If you want to see all accounts, click OK.
RPS 3.4.3 Installing RPS | en 41 Installation Using SQL Express on a Network 1. If necessary, install SQL Express from the RPS CD-ROM onto a network server. 2. Open the RPS installer from the RPS CD-ROM. 3. Select your setup language preference, then click OK. Figure 3.61 RPS Choose Setup Language 4. At the RPS InstallShield® Welcome dialog, click Next. Figure 3.62 RPS InstallShield Wizard Welcome 5. The Choose Destination Location dialog opens.
en | Installing RPS RPS 6. The New Database Creation dialog opens. Click Browse to select a different directory on the network. Figure 3.64 RPS New Database Creation NOTICE! i To determine which network directory should contain the RPS database, consult your network or database administrator. RPS does not support Universal Naming Convention (UNC). Select a mapped network drive. 7. In the Choose Folder dialog, browse to the desired network directory, then click OK. Figure 3.
RPS Installing RPS | en 8. 43 The New Database Creation dialog returns and shows the new directory path. Click Next. Figure 3.66 RPS New Database Creation 9. The Select Features dialog opens. Select the desired features and control panel types for this RPS installation, then click Next. i NOTICE! All networked workstations should have the same control panel types selected. Figure 3.67 RPS Select Features Bosch Security Systems, Inc. Installation Guide 4998141259 | 09 | 2008.
en | Installing RPS RPS 10. When the Select Program Folder dialog opens, click Next. Figure 3.68 RPS Select Program Folder 11. The Start Copying Files dialog opens, listing your selections from the previous steps and confirming that the PC's hard drive has enough unused space for the RPS installation. Click Next. Figure 3.69 4998141259 | 09 | 2008.10 RPS Start Copying Files Installation Guide Bosch Security Systems, Inc.
RPS Installing RPS | en 45 12. When the InstallShield Wizard Complete dialog opens, click Finish. The PC restarts. Figure 3.70 RPS InstallShield Wizard Complete 13. After logging onto the PC, start RPS either by selecting Start>Bosch>RPS 5.x, or by double-clicking the RPS 5.x shortcut on the PC's desktop. 14. In the RPS System Configuration dialog: a. Select or enter the SQL server name into the Select or Enter SQL Server name field. b. Type a database name into the Enter SQL Database Name field.
en | Installing RPS RPS 15. The Create Database dialog opens. Click OK. Figure 3.72 RPS Create Database 16. Click OK to close the RPS System Configuration dialog. 17. In the RPS Logon Information dialog, enter your RPS user name and password, then click OK. Figure 3.73 RPS Logon Information The Panel Filter dialog opens. If you want to see a subset of all accounts, enter the filter criteria into the Panel Information fields, then click OK. If you want to see all accounts, click OK.
RPS Installing RPS | en 47 NOTICE! Networking protocols are disabled by default in SQL Server Express. If someone simply installs SQL Server Express and chooses all the defaults, SQL Server Express can only have connections originating on the local machine where SQL Server is installed. To enable SQL Server Express to accept remote connections, configure SQL Server Express to listen on TCP/IP: i 3.4.4 – Launch the SQL Server Configuration Manager from the Microsoft SQL Server 2005 program menu.
en | Upgrading Existing RPS Installations RPS 4 Upgrading Existing RPS Installations 4.1 Upgrading RPS Client and Access Database to SQL 1. If necessary, install SQL Express from the RPS CD-ROM. 2. Open the RPS installer from the RPS CD-ROM. 3. Select your setup language preference, then click OK. Figure 4.1 RPS Choose Setup Language 4. When the Welcome dialog opens, click Next. Figure 4.2 RPS InstallShield Welcome Dialog 5. The Select Features dialog opens.
RPS Upgrading Existing RPS Installations | en 6. 49 When the Select Program Folder dialog opens, click Next. Figure 4.4 RPS Select Program Folder Dialog 7. The Start Copying Files dialog opens, listing your selections from the previous steps and confirming that the PC's hard drive has enough unused space for the RPS installation. Click Next. The Setup Status dialog indicates the installer's progress. Figure 4.5 RPS Start Copying Files Bosch Security Systems, Inc.
en | Upgrading Existing RPS Installations 8. RPS When the InstallShield® Wizard Complete dialog opens, click Finish. The PC restarts. Figure 4.6 RPS InstallShield Wizard Complete Dialog 9. After logging onto the PC, start RPS either by selecting Start>Bosch>RPS 5.x, or by double-clicking the RPS 5.x shortcut on the PC's desktop. 10. If necessary and if you do not know the SQL Server name, select Start>Microsoft SQL Server 2005>SQL Server Management Studio Express.
RPS Upgrading Existing RPS Installations | en 51 12. In the RPS System Configuration dialog: a. Paste the text copied in the previous step into the Select or Enter SQL Server name field. b. Type a database name into the Enter SQL Database Name field. c. In the Enter User Name and Enter Password fields, type the same name (sa for SQL Express) and password used when the SQL database was installed. d. Click Create Database, which creates a database in SQL Express with the name you provided.
en | Upgrading Existing RPS Installations RPS 14. In the Database Merge Utility dialog, select the Destination Database Details tab, then confirm that the SQL Database fields are configured correctly. If the Dat File Location field is not pointing to the correct directory, click ... and navigate to the correct directory, then click Merge Database. Figure 4.10 RPS Destination Database Details Dialog 15. In the confirmation dialog, click OK. Figure 4.11 Database Merge Success 16.
RPS Upgrading Existing RPS Installations | en 53 The Panel Filter dialog opens. If you want to see a subset of all accounts, enter the filter criteria into the Panel Information fields, then click OK. If you want to see all accounts, click OK. Refer to the RPS General Help in RPS for more information about the panel filter. Figure 4.13 RPS Panel Filter Dialog 19. Create and configure the control panel account. Bosch Security Systems, Inc. Installation Guide 4998141259 | 09 | 2008.
4.2 en | Upgrading Existing RPS Installations RPS Upgrading the SQL Server Database From the Server 1. Open the SQL Server Management Studio. Figure 4.14 2. Log into the database. Figure 4.15 3. 4998141259 | 09 | 2008.10 SQL Server 2005 Connect to Server In SQL Server, select File>Open>File. Figure 4.16 4. Path to SQL Server Management Studio SQL Server File > Open > File Path Locate the SQL upgrade script file on the RPS CD-ROM, then click Open.
RPS Upgrading Existing RPS Installations | en 5. 55 Log in again, then click Connect. Figure 4.17 SQL Server 2005 Connect to Database Engine 6. In the drop-down menu, select the RPS database that you are upgrading. Figure 4.18 SQL Server 2005 Upgrade RPS Database 7. Select Query>Execute. When you see Query executed successfully on the bottom of the window, the database is upgraded. Figure 4.19 SQL Server 2005 Query > Execute 8. 9. Close Microsoft SQL Server Studio.
4.3 en | Upgrading Existing RPS Installations RPS Upgrading the SQL Express Database From the Server 1. Open the SQL Server Management Studio. 2. Log into the database. Figure 4.20 3. Path to SQL Server Management Studio In SQL Server, select File>Open>File. Figure 4.21 SQL Server File > Open > File 4. Locate the SQL upgrade script file on the RPS CD-ROM, then click Open. 5. Log into the database again, then click Connect. Figure 4.22 4998141259 | 09 | 2008.
RPS Upgrading Existing RPS Installations | en 6. 57 In the drop-down menu, select the RPS database that you are upgrading. Figure 4.23 SQL Server 2005 Upgrade RPS Database 7. Select Query>Execute. When you see Query executed successfully on the bottom of the dialog, the database is upgraded. Figure 4.24 SQL Server 2005 Query > Execute 8. Close Microsoft SQL Server Studio. 9. If you have not already done so, upgrade the RPS .dat files. Refer to Section 4.6 Upgrading RPS .
en | Upgrading Existing RPS Installations 4.4 RPS Upgrading SQL Server Database from the RPS Client NOTICE! i If you have already upgraded the database for SQL Server or SQL Express from the server, you can skip this section and proceed to Section 4.5 Upgrading the RPS Client Only (if using a network database), page 63. 1. Instruct all users to log out of RPS. 2. Open the RPS installer from the RPS CD-ROM. 3. Select your setup language preference, then click OK. Figure 4.25 4.
RPS Upgrading Existing RPS Installations | en 5. 59 The Select Features dialog opens. Select the desired features and control panel types for this RPS installation, then click Next. Figure 4.27 RPS Select Features Dialog 6. When the Select Program Folder dialog opens, click Next. Figure 4.28 RPS Select Program Folder Dialog Bosch Security Systems, Inc. Installation Guide 4998141259 | 09 | 2008.
en | Upgrading Existing RPS Installations 7. RPS The Start Copying Files dialog opens, listing your selections from the previous steps and confirming that the PC's hard drive has enough unused space for the RPS installation. Click Next. The Setup Status dialog indicates the installer's progress. Figure 4.29 8. RPS Start Copying Files When the InstallShield Wizard Complete dialog opens, click Finish. The PC restarts. Figure 4.30 9.
RPS Upgrading Existing RPS Installations | en 61 10. An error dialog opens. Click OK. Figure 4.31 RPS Incompatible Database Message Dialog 11. In the RPS System Configuration dialog, click Upgrade Database. Figure 4.32 RPS System Configuration Dialog 12. A confirmation dialog opens. Click OK. Figure 4.33 RPS Upgrade Database Dialog Bosch Security Systems, Inc. Installation Guide 4998141259 | 09 | 2008.
en | Upgrading Existing RPS Installations RPS 13. In the RPS Logon Information dialog, type the RPS user name and password, then click OK. Figure 4.34 RPS Logon Information Dialog The Panel Filter dialog opens. If you want to see a subset of all accounts, enter the filter criteria into the Panel Information fields, then click OK. If you want to see all accounts, click OK. Refer to the RPS General Help in RPS for more information on the panel filter. Figure 4.35 RPS Panel Filter Dialog 14.
RPS 4.5 Upgrading Existing RPS Installations | en 63 Upgrading the RPS Client Only (if using a network database) 1. Open the RPS installer from the RPS CD-ROM. 2. Select your setup language preference, then click OK. Figure 4.36 RPS Choose Setup Language Dialog 3. When the Welcome dialog opens, click Next. Figure 4.37 RPS InstallShield Wizard Welcome Dialog 4. The Select Features dialog opens. Select the desired features and control panel types for this RPS installation, then click Next.
en | Upgrading Existing RPS Installations 5. When the Select Program Folder dialog opens, click Next. Figure 4.39 6. RPS RPS Select Program Folder Dialog The Start Copying Files dialog opens, listing your selections from the previous steps and confirming that the PC's hard drive has enough unused space for the RPS installation. Click Next. The Setup Status dialog indicates the installer's progress. Figure 4.40 4998141259 | 09 | 2008.
RPS Upgrading Existing RPS Installations | en 7. 65 When the InstallShield Wizard Complete dialog opens, click Finish. The PC restarts. Figure 4.41 RPS InstallShield Wizard Complete 8. After logging onto the PC, start RPS either by selecting Start>Bosch>RPS 5.x, or by 9. Log into RPS. double-clicking the RPS 5.x shortcut on the PC's desktop. 10. In the RPS System Configuration dialog, click Modify and change the location so that it points to the network database again.
en | Upgrading Existing RPS Installations RPS 12. In the RPS Logon Information dialog, type the RPS user name and password, then click OK. Figure 4.43 RPS Logon Information Dialog 13. Create and configure the control panel account. 4.6 Upgrading RPS .dat Files on the Server 1. 2. Use Windows Explorer to open the SQL Dat File Upgrade.zip file from the RPS CD-ROM. Extract the contents of the .zip file into the existing RPS Database directory, and replace all existing files. Figure 4.44 3.
RPS Post-Installation/Upgrade Tasks | en 5 Post-Installation/Upgrade Tasks 5.1 Switching From a Client to Network Installation 67 It can be advantageous to place your RPS database files on a network drive so that many workstations can access a single database. 1. Locate the RPS\Database directory on the local drive. 2. Using Windows Explorer, right-click on the Database directory, then select Sharing and Security.... Figure 5.1 Windows Explorer > Sharing and Security 3.
en | Post-Installation/Upgrade Tasks 4. RPS In the Permissions dialog, select Allow for the Change and Read permissions, then click OK to close the Permissions and Properties dialogs. Figure 5.3 Windows Explorer > Permissions for Database 5. Copy the Database directory to the new location on the network drive. 6. Start RPS, and log on when the RPS Logon Information dialog opens. Figure 5.4 RPS Logon Information 7. Select Config > System. The System Configuration dialog opens.
RPS Post-Installation/Upgrade Tasks | en 8. 69 Select the File Locations tab, then click Modify and navigate to the directory location you created on the network drive in Step 5. Figure 5.
en | Post-Installation/Upgrade Tasks RPS When the database files are stored on a network drive, two or more operators can access a single account. When an operator attempts to access an account that is already open by another operator (for example, one that has a different user name), a Panel Already Open dialog appears, indicating that the account is already opened for editing by another operator (the operator's log-in name displays in the message box).
RPS Post-Installation/Upgrade Tasks | en 5.2 Reverting to Previous RPS Installation After SQL Upgrade 5.2.1 Reverting to a Microsoft Access Database 71 NOTICE! i The following procedure assumes that the Microsoft Access database from the previous installation was backed up, and that this Access database is already copied to the desired directory. 1. Select Control Panel > Add or Remove Programs, then uninstall the existing RPS 2. Restart the PC. 3.
en | Post-Installation/Upgrade Tasks 5.2.2 RPS Reverting to a Previous SQL Database NOTICE! i The following procedure assumes that you used SQL Management Studio to back up the previous SQL database (creating a .bak file), and that the Database directory containing the .dat files was also backed up. 1. Select Control Panel > Add or Remove Programs, then uninstall the existing RPS installation. 2. Restart the PC. 3.
RPS Post-Installation/Upgrade Tasks | en 7. 73 When the Specify Backup dialog opens, click Add. Figure 5.12 SQL Server Specify Backup 8. In the directory containing the SQL installation, select the .bak file, then click OK. Figure 5.13 SQL Server Locate Backup File Bosch Security Systems, Inc. Installation Guide 4998141259 | 09 | 2008.
en | Post-Installation/Upgrade Tasks 9. RPS When the Specify Backup dialog identifies the Backup location, click OK. Figure 5.14 SQL Server Specify Backup 10. Under Select the backup sets to restore, click the checkbox under Restore, then click OK. Figure 5.15 SQL Server Restore Database 11. The database restores successfully. Click OK. Figure 5.16 4998141259 | 09 | 2008.10 SQL Server Successful Database Restore Installation Guide Bosch Security Systems, Inc.
RPS Post-Installation/Upgrade Tasks | en 75 12. Install the earlier version of RPS. During the installation process, when you reach the Select Database Configuration dialog, click Use Existing Database, then click Next. Figure 5.17 RPS Select Database Configuration 13. When the Use Existing Database dialog opens, click Browse and specify the location of the Access database. Figure 5.18 RPS Use Existing Database 14. Finish the installation by following the instructions on the screen.
en | Post-Installation/Upgrade Tasks 5.3 RPS Setting Security Levels by Panel Type for Networked Users If your company is using a database on a networked drive and you want to allow users to be able to set security levels for control panels, you must copy the control panel definition files to each workstation on the network. This preserves the security settings you have set for each control panel type on the individual workstations on the network.
RPS 5.4 Post-Installation/Upgrade Tasks | en 77 Backing Up the SQL or SQL Express Database 1. From the PC's Start > Programs menu, select Microsoft SQL Management Studio or Microsoft SQL Management Studio Express. 2. When the Connect to Server dialog opens, click Connect. Figure 5.19 SQL Server 2005 Connect to Server 3. Right-click the RPS database, then select Tasks > Back Up.... Figure 5.20 SQL Server 2005 Tasks > Back Up Bosch Security Systems, Inc.
en | Post-Installation/Upgrade Tasks 4. When the Back Up Database dialog opens, click OK. Figure 5.21 5. SQL Server 2005 Back Up Database When the Backup Completed Successfully dialog opens, click OK. Figure 5.22 4998141259 | 09 | 2008.10 RPS Backup Completed Successfully Installation Guide Bosch Security Systems, Inc.
RPS RPS Setup and Maintenance | en 6 RPS Setup and Maintenance 6.1 Modifying RPS 79 NOTICE! i To modify the current RPS installation, you must use the original installation files. – If RPS was installed from the CD-ROM, you must use the CD-ROM. – If RPS was installed from a folder containing the installation files, you must use the same folder in the location it resided at when RPS was installed.
en | RPS Setup and Maintenance 4. RPS Click Modify, and then click Next. The Select Features dialog opens. Figure 6.3 Select Features Window 5. Select the checkboxes for the features you want to install, or clear the checkboxes for the features you want to remove. 6. Click Next. The selected features are either installed or uninstalled as selected. 7. When the Install Complete dialog opens, click Finish to end the RPS Setup Maintenance process. 6.
RPS Logging Into RPS | en 7 81 Logging Into RPS NOTICE! i 7.1 Limit access to RPS to authorized individuals as it contains provisions for setting security passwords. Establish appropriate security levels and set passwords before allowing operating personnel access to RPS. First Time Log-In i NOTICE! Do not log into RPS as the same operator from two different PCs when using a networked database. To log into RPS: 1.
7.2 en | Logging Into RPS RPS Changing the Password To change the default password: 1. From RPS, select Config Password. Figure 7.2 Accessing the Change Password Window 2. When the Change Password dialog opens: a. Enter the old password. b. Enter the new password. c. Enter the new password again. d. Click OK. The new password takes effect the next time you log in. Figure 7.3 Logon Information Window 4998141259 | 09 | 2008.10 Installation Guide Bosch Security Systems, Inc.
RPS Recovering Old Database Files | en 8 83 Recovering Old Database Files i NOTICE! You cannot point RPS to a database created in an older version of RPS. Doing so either produces errors, or it corrupts the database. To recover control panel accounts that were not exported before installing the new version of RPS: 1. Uninstall the new version of RPS. Refer to Section 6.3 Removing RPS on page80. 2. Reinstall the old version of RPS 3.
en | RPS Operation and Control Panel Account Notes RPS 9 RPS Operation and Control Panel Account Notes 9.1 RPS Notes 9.1.1 Installation and Administration When using the RAM II Exporter, use the Exporter R2X_V004.exe file. Do not use any other Ram2expt files 9.1.2 General Operation If your PC runs Windows XP Service Pack 2 or higher and you use Windows Firewall, you must grant permission to RPS so it can conduct network communication with control panels: 1. Select Start > Control Panel.
RPS RPS Operation and Control Panel Account Notes | en 9.2 Control Panel Account Notes 9.2.1 2000 Series 85 RAM II Exporter version 004 does not import account notes and zone notes. The cells for these notes are empty in RPS. 9.2.2 D6412/D4412 and DS7240/DS7220 – Changing an RF ID: RPS allows you to change the RF ID for a location without resetting the learned characteristics for the transmitter. For example, the control panel supervises an RF3401 (RF3401E) Point Transmitter.
en | RPS Operation and Control Panel Account Notes – RPS Tamper conditions not bypassable (DS7240-UK only): Bypassing a zone from RPS only bypasses the alarm condition. Tamper conditions cannot be bypassed. – Remote Programming Lockout (DS7240-UK and DS7200V2-UK only): After three invalid attempts to connect to the control panel from RPS, the control panel locks out any remote programming sessions for 4 h. Remote programming through the direct connect method is still available.
RPS 9.2.6 RPS Operation and Control Panel Account Notes | en 87 DS7400XiV4-EXP – Phone Number Fields Also Apply to IP Addresses: The phone number fields in Phone Control and Partitions > Account Code also support IP addresses if you are communicating over an Ethernet network. – Resetting the Control Panel from RPS Clears Date and Time Settings: If you click the Reset Panel checkbox on the End Session dialog, RPS clears the control panel's date and time settings.
en | RPS Operation and Control Panel Account Notes 4998141259 | 09 | 2008.10 RPS Installation Guide Bosch Security Systems, Inc.
