Specification Guide

2/21
24" Compact Washer
800 Series Washer with Home Connect® – WAW285H2UC
Technical Details Continued
Power Cord (included)
[Type]
(Yes)
[240V; NEMA 6-15,
3-prong]
Power cord length 63" (Full Length)
Drain hose length 57" (Full Length)
Inlet hose length 59" (Full Length)
Door hinge Left Side
(Not Reversible)
Dimensions & Weight
Overall appliance
dimensions (HxWxD)
33 1/4" x 23 1/2"
x 25"
Net weight 160 lbs
Minimum stack height 67 3/4"
†ADA compliance
– Meets ADA height and access requirements
when installed on pedestal.
– Meets ADA operable parts requirements for
controls and detergent dispenser.
Accessories
Short Stainless Steel
Hose (If needed for
plumbing box clearance
with AQS hose)
P/N 645787
General Properties
Tub material Stainless Steel
Maximum spin speed 1,400 rpm
Interior light Yes (LED)
Leak protection systems AquaStop® Plus
(AquaStop® Base +
Aquashield® Hose)
Internal water heater Yes
Stackable Yes with Stacking
Kit Accessory
Silence level – washing 50 dBA
Silence level – spinning 71 dBA
Programs (No.),
[Special]
(14), [Super
Quick 15, Whitest
Whites]
Options (No.), [Special] (10) [Remote
Start, EcoPerfect™,
Stains]
Home Connect™
(Wi-Fi enabled)
Yes
Energy consumption 84 kWh/yr
Water consumption 2,379 gal/yr
ENERGY STAR® certified Yes
Capacity
Capacity 2.2 cu. ft.
Design Elements
Door ring Chrome
Control type Premium LED
touch
Dial Illuminated jog dial
Bosch logo on door glass Yes
Technical Details
Watts 2,520 W
Circuit breaker 15 A**
Volts 208/220-240 V
Current 10.5 A
Frequency 60 Hz
*As compared to Perm Press Heavy Soil cycle without SpeedPerfect®
** Stated circuit breaker size is if the appliance is plugged into an individual 240/208V, 15A minimum branch circuit.
Accessories: To purchase Bosch accessories, cleaners & parts please visit www.bosch-home.com/us/store or call 1-800-944-2904 (Mon to Fri 5 am to 6 pm PST, Sat 6 am to 3 pm PST).
Notes: All height, width and depth dimensions are shown in inches. BSH reserves the absolute and unrestricted right to change product materials and specifications, at any time, without
notice. Consult the product’s installation instructions for final dimensional data and other details prior to making cutout.
Warranties: Please see Use & Care manual or Bosch website for statement of limited warranty.
For more information on our entire line of products, go to www.bosch-home.com/us or call 1-800-944-2904
© BSH Home Appliances Corporation. All rights reserved. Bosch is a registered trademark of Robert Bosch GmbH.
WAW285H2UC
White
The 800 Series Laundry
pair is ENERGY STAR®
certified and offers
matching quality, water
protection, design and fast
wash and dry cycles.
Features & Benefits
The Bosch 800 Series
washer with Home
Connect® can be operated
from anywhere.
AquaStop®Plus provides
extra protection against
water damage.
Customized stain options
treat organic oils, blood,
red wine and grass.
SpeedPerfect® provides
up to 40% faster washing
time.*
At 2.2 cu. ft. Bosch
washers are compact in
size without sacrificing
capacity so you can fit a
variety of loads.
†
WTZ11400UC
Stacking Kit with Shelf
WTZ20410UC
Stacking Kit without Shelf
WTZPA20UC
Power Adapter
(Included with Dryer)
Matching Bosch Dryer is
supplied with a Power Adapter
to fit into a standard 4-Prong,
30A, Dryer receptacle (NEMA
14-30R) and power both
Bosch Washer and Dryer.
Note: Use of two individual
NEMA 6-15R or 6-20R
receptacles/circuits may be
used as an alternative to
power Washer and Dryer.
WMZPW20W
Pedestal
