Operation Manual
Table Of Contents
- Introduction
- Welcome
- Product overview
- Controls and indicators
- Connection panel
- System Setup
- Unpacking
- Removing/attaching the cover
- Mounting options
- Connecting the T1 to an L1TM model II power stand
- Connecting the T1 to an L1 model I power stand
- Connecting the T1 ToneMatchTM audio engine power supply (optional)
- Connecting the T1 to your computer
- Operating Instructions
- Optimizing input gain and output volume
- Using the Master volume control
- Muting a channel
- Muting channel effects
- Reading the T1 display
- Using the T1 rotary selector
- Editing the sound of a channel
- Selecting a ToneMatch™ preset
- Adjusting zEQ
- Adjusting Para EQ
- Using compressor/gate functions
- Using the KickGate
- Using modulation effects
- Adding delays
- Adding reverb
- Routing input signals to the Aux output
- Using the tuner
- Using global functions
- Selecting a type of reverb
- Using the Prefs utilities
- Loading and saving scenes
- Sharing a scene
- Bose scenes
- Factory Settings
- Singer/Songwriter
- DJ/Playback
- Drums and Bass
- The Works scene
- Factory Settings
- Care & Maintenance
- Cleaning
- Limited Warranty and Registration
- Accessories
- Troubleshooting
- Technical information
INTRODUCTION
2
EnglishDeutschEspañolFrançaisItalianoNederlandsSvenska Dansk
Product overview
The T1 ToneMatch
TM
audio engine can be used with a Bose
®
L1
TM
model II or model I system. For convenient
access, you can mount the T1 on a Cylindrical Radiator
®
loudspeaker or on a microphone stand using the optional
microphone stand bracket. When used with the L1
TM
model II system, the T1 operates on DC power received from
the power stand. The optional T1 ToneMatch
TM
audio engine power supply is used to power the T1 when it is con-
nected to an L1
TM
model I system or a USB port on your computer.
Figure 1
T1
ToneMatch
TM
audio engine
and
accessories
To order accessories, call (800) 905-0886 or visit www.Bose.com/musicians.
T1 ToneMatch
TM
audio engine
and the L1 model II system
Optional accessories
T1 ToneMatch
TM
audio engine
power supply
Ton eMatc h
TM
audio engine
microphone stand bracket
T1 ToneMatch
TM
audio engine
L1
TM
model II
