The Cylindrical Radiator
®
top section needs to be removed for this installation.
1. Slide the carriage into the channel on the rear of the Cylindrical Radiator
®
bottom section and turn the locking
knob clockwise to lock it in place (Figure 4).
2. Insert the mounting bar into the slot in the carriage and push it downward.
3. Place the T1 on the mounting bar.
Figure 4
T1 mounted on
a Cylindrical
Radiator
®
loudspeaker
Carriage
Mounting
bar
Cylindrical
Radiator
®
bottom section
T1 ToneMatch
TM
audio engine
1
2
3
Locking knob
The T1 can be mounted to the left or right.
