SYSTEM SETUP
14
EnglishDeutschEspañolFrançaisItalianoNederlandsSvenska Dansk
Connecting the T1 ToneMatch
TM
audio engine power supply (optional)
The T1 power supply provides power for the T1 audio engine when connecting it to an L1
TM
model I system or
your computer.
1. Plug the power supply cable into the T1 ToneMatch
TM
port.
2. Plug one end of the AC power cord into the power supply.
3. Plug the other end of the power cord into a live AC (mains) outlet.
4. Switch the T1 power switch to the ON position.
Figure 9
T1 power
supply
connections
T1 power
supply
Power supply cable
AC power cord
T1 ToneMatch
TM
audio engine
1
2
3
4
ToneMatch port
