Operation Manual

19
OPERATING INSTRUCTIONS
SvenskaItalianoFrançaisEspañolDeutschDanskEnglish Nederlands
Using the T1 rotary selector
The T1 rotary selector provides access to the functions that shape the sound of the ToneMatch
TM
audio engine out-
put. Figure 2 provides a summary of the three global functions and the nine channel-related functions. The follow-
ing pages describe how to adjust each function.
Figure 2
Rotary selector
Scenes
Allows you to save and load
performance scenes (a snapshot
of the complete state of the unit).
Prefs
Allows access to several
system utilities.
Reverb Type
Applies a selected type
of reverb to all channels.
Aux
Sends a selected channel
to the Aux output.
Tuner
Provides tuning information
for an instrument playing
into the selected channel.
ToneMatch
TM
engine
Provides access to proprietary ToneMatch
presets designed for specific instruments
and microphones.
zEQ
As part of the selected ToneMatch preset,
provides controls to adjust low/mid/high
frequencies that are within the range of
your instrument or microphone.
Para EQ
Provides Level, Frequency, and
Width parametric EQ controls for
a single band.
Comp/Gate
Provides gate, compression, lim-
iter, de-esser, and kick drum pre-
sets with adjustable parameters.
Mod
Provides several modulation
effects such as chorus,
flanger, phaser, and tremolo.
Delay
Provides three types of
delays.
Reverb
Applies reverb to a selected
channel.
Global
