29
OPERATING INSTRUCTIONS
SvenskaItalianoFrançaisEspañolDeutschDanskEnglish Nederlands
• Input Level – Displays input level meters with peak signal indicators for all input channels. Press the Reset
button to reset all peak signal indicators. This display is helpful in setting the channel input trim level (see
“Optimizing input gain and output volume” on page 16).
• Output Level – Displays output level meters for all outputs – Master, Aux, USB L (left), and USB R (right).
• Versions – Displays revision levels of DSP Firmware, Bose Presets, and Bose Scenes (viewable only).
Input Level Preferences
CH1 . . . . . . . . . . . . .
CH2 . . . . . . . . . . . . .
CH3 . . . . . . . . . . . . .
CH 4/5 . . . . . . . . . . . . .
Menu Reset
Peak level
indicator
Input level
indicator
Output Level Preferences
Master . . . . . . . . . . . . .
Aux . . . . . . . . . . . . .
USB L . . . . . . . . . . . . .
USB R . . . . . . . . . . . . .
Menu
Versions Preferences
DSP Firmware: 1.0
Bose Presets: 1.0
Bose Scenes: 1.0
Menu
