Operation Manual
Table Of Contents
- Introduction
- Welcome
- Product overview
- Controls and indicators
- Connection panel
- System Setup
- Unpacking
- Removing/attaching the cover
- Mounting options
- Connecting the T1 to an L1TM model II power stand
- Connecting the T1 to an L1 model I power stand
- Connecting the T1 ToneMatchTM audio engine power supply (optional)
- Connecting the T1 to your computer
- Operating Instructions
- Optimizing input gain and output volume
- Using the Master volume control
- Muting a channel
- Muting channel effects
- Reading the T1 display
- Using the T1 rotary selector
- Editing the sound of a channel
- Selecting a ToneMatch™ preset
- Adjusting zEQ
- Adjusting Para EQ
- Using compressor/gate functions
- Using the KickGate
- Using modulation effects
- Adding delays
- Adding reverb
- Routing input signals to the Aux output
- Using the tuner
- Using global functions
- Selecting a type of reverb
- Using the Prefs utilities
- Loading and saving scenes
- Sharing a scene
- Bose scenes
- Factory Settings
- Singer/Songwriter
- DJ/Playback
- Drums and Bass
- The Works scene
- Factory Settings
- Care & Maintenance
- Cleaning
- Limited Warranty and Registration
- Accessories
- Troubleshooting
- Technical information
37
OPERATING INSTRUCTIONS
SvenskaItalianoFrançaisEspañolDeutschDanskEnglish Nederlands
Bose scenes
The five Bose scenes are provided as examples for you to use as a starting point. After loading a Bose scene, you
can modify the settings and then save the settings as a My Scene or Shared Scene.
Factory Settings
This scene restores the T1 audio engine to the settings it had when it left the factory. Loading this scene erases any
changes you previously made to the currently loaded scene.
Note: For a list of the factory settings for all effects, see “Factory Settings” on page 46.
CH 1-4/5
ToneMatch
Active
Utility
Flat
Global settings
Preferences
Active screen
USB to PC
USB from PC
Master Out
Reverb Type
Type
Time
Bal
Status
Left/Right:Master
Left/Right:Master
Post Master Volume
Medium
1.75ms
50%
zEQ
Bypass
Low Mid High
0dB 0dB 0dB
Para EQ Bypass
Comp/Gate
Bypass
Comp1
Mod
Bypass
Chorus1
Delay
Bypass
Digital
Reverb
Bypass
Medium (Global)
Aux
Mute
Pre: With EQ & Fx
