OPERATING INSTRUCTIONS
SvenskaItalianoFrançaisEspañolDeutschDanskEnglish Nederlands
Singer/Songwriter scene channel settings
Global settings
Microphone
CH 1
Guitar
CH 2
Keyboard
CH 3
MP3 Player
CH 4/5
ToneMatch
Active
Vocal Mics
Handheld Mics
Active
Acoustic Guitars
Steel String w/piezo
Active
Keyboards
General Keys
Active
DJ/Playback
Flat, zEQ Controls
zEQ
Active
Low Mid High
0dB 0dB 0dB
Active
Low Mid High
0dB 0dB 0dB
Active
Low Mid High
0dB 0dB 0dB
Active
Low Mid High
0dB 0dB 0dB
Para EQ Bypass Bypass Bypass Bypass
Comp/Gate
Bypass
Gate
Bypass
Comp2
Bypass
Comp2
Bypass
Limit
Mod
Bypass
Chorus1
Active
Chorus1
Bypass
Chorus3
Bypass
Chorus1
Delay
Bypass
Digital
Bypass
Digital
Bypass
Digital
Bypass
Digital
Reverb
Active
Medium (Global)
Active
Medium (Global)
Bypass
Medium (Global)
Bypass
Medium (Global)
Aux
Mute
Pre: With EQ & Fx
Mute
Pre: With EQ & Fx
Mute
Pre: With EQ & Fx
Mute
Pre: With EQ & Fx
Preferences Reverb Type
Active screen Status
USB to PC Left/Right:Master
USB from PC Left/Right:Master
Master Out Post Master Volume
Type Medium
Time 1.75ms
Bal 50%
