CARE & MAINTENANCE
SvenskaItalianoFrançaisEspañolDeutschDanskEnglish Nederlands
Not hearing any effects. • Check that you pressed the correct CH Edit button.
• Make sure the FX Mute button is not pressed for the channel in question.
T1 not responding to
control knobs.
• Turn off the audio engine. Wait 30 seconds and turn unit on again.
Master volume control has
no effect.
• Verify that the Master output is configured for Post Master Volume operation in the Prefs menu under Master
Out.
With nothing plugged into
the T1 input connectors, a
slight hum or buzz is heard
from the L1 system.
• Plug the T1 and the L1
TM
power stand into the same AC (mains) outlet.
• Using an AC outlet tester, test the AC outlet that the T1 and/or the L1 power stand is plugged into for reversed
or open (hot, neutral, and/or ground) contacts.
• If using an extension cord, make sure that the cord is also tested as above.
Too much (or not enough)
bass, mid-range, or high
frequencies.
• Make sure there is no unwanted zEQ or Para EQ equalization applied.
• Verify that you have selected an appropriate ToneMatch
TM
engine preset for your microphone/instrument. If you
do not want to use a ToneMatch engine preset, make sure ToneMatch is set to Flat in the Utility category.
Poor-sounding playback of
a stereo recording using a
CD player, MP3 player, or
other such device.
• Connect the left channel of the device to T1 input channel 4 and the right channel to T1 input channel 5.
Channels 4/5 are designed for line-level inputs.
• Disable any extended bass or EQ features when using CD or MP3 players.
• If you are using recording software on a computer, check the software requirements. You may need to configure
the software settings for 48kHz/24-bit operation.
If using the T1 with an L1 model I system:
•Do not use a female
1
/8" stereo-to-male ¼" stereo adapter when connecting a portable device to an input
channel on the L1 model I power stand. The L1 model I input channels use a monaural (TS) connection. Use a
stereo-to-monaural adapter.
Problem What to do
