e) Inspect the Completed Sub-Assembly
After completing the sub-assembly, inspect it to ensure that everything is correctly placed.
Check that:
•
Check that the power amp assembly is mounted in the correct orientation.
•
Check that the all PCB standoff holes have been secured (12 screws total).
•
Check that the power switch is snapped flush into the chassis in the correct
orientation.
•
Check that all screws and nuts securing the output jack have been installed
and are secure (4 screws, 8 plastic nuts).
•
Check that the RJ45 jack protrudes through the square hole in the chassis and
is flush with the back face of the chassis.
If the assembly passes the above tests, move on to the next step. Correct any problems
immediately. If you have any quality questions, consult your supervisor.
