1. BUTTONS LOCATION AND FUNCTIONS 1 12 8 6 11 10 13 5 4 15 17 16 2 14 7 3 9 18 1. Panel Release Button 2. Mute Button 3. CD Eject Button 4. Audio Button 5. Display Button / ID3 Information Button 6. Local / Distant Button 7. Preset Memory Buttons 8. Mono / Stereo Button 9. Scan Button 10. Volume Knob 11. MP3 Menu Button & Automatically Store / Preset Scan Button 12. Power Button 13. Band/Loudness Button / MP3 Enter Button 14. Tuning Up/Down & Track Up / Down Buttons 15. Source Button 16.
2. HANDLING COMPACT DISCS MOISTURE CONDENSATION On a rainy day or in a very damp area, moisture may condense on the lenses inside the unit. Should this occur, the unit will not operate properly. In such a case, remove the disc and wait for about an hour until the moisture has evaporated. NOTES ON CDs NOTES ON DISCS 1. A dirty or defective disc may cause sound dropouts while playing. To enjoy optimum sound, handle the disc as follows. Handle the disc by its edge.
3. INSTALLATION Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and system work properly. Use only the parts included with the unit to ensure proper installation. The use of unauthorized parts can cause malfunctions. Consult with your nearest dealer if installation requires the drilling of holes or other modifications of the vehicle.
Removing the unit a a. Frame b. Insert fingers into the groove in the front of frame and pull out to remove the frame. (When re-attaching the frame, point the side with a groove down wards and attach it.) c. Insert the levers supplied with the unit into the grooves at both sides of the unit as shown in figure until they click. Pulling the levers makes it possible to remove the unit from the dashboard. b c Trim Plate Installation: Push the trim plate against the chassis until it is fitted.
4. DETACHABLE CONTROL PANEL (D.C.P.) Removing The Detachable Control Panel (D.C.P.). 1. Turn the power off 2. Press the D.C.P. release button 3. Remove the D.C.P. PANEL RELEASE BUTTON Attaching the DCP 2 A B 1. Attach the panel at the right side first, with point B on the main unit touching point A on the D.C.P. (As shown on the digram). 2. Then press the left side of D.C.P. onto the main unit until a “click” sound is heard. CAUTION DO NOT insert the D.C.P from the left side. Doing so may damage it.
5. WIRING DIAGRAM (BUILT IN ISO PLUG ) L REAR R ANTENNA INPUT / / HC-L AMP HC-R REAR LINE OUT/RÜCKANSCHLUSS/SORTIE ARRIERE/SAIDA TRASEIRA /SALIDA DE LINEA TRASERA/LINE OUT POSTERIORE L-CH / / FRONT LINE OUT/VORDERER AUSGANG/SAÍDA FRONTAL /SALIDA DE LINEA TRASERA/LINE OUT POSTERIORE RCA-TO-RCA CABLES (not supplied) RCA-TO-RCA-KABEL (nicht geliefert) CABLES RCA-TO-RCA (non fournis.
6. BASIC OPERATIONS 1) PANEL RELEASE BUTTON (REL) Press this button to remove the control panel. 12) POWER ON/OFF BUTTON Press this button to turn on or off the power. 5) DISPLAY BUTTON (DISP) Press this button briefly, the LCD will display the clock for about 2 seconds, then return to previous display mode. Clock Adjustment Under clock display mode, press DISP button until the LCD flashes, press Tuning Up Button to adjust hour and Tuning Down Button to adjust minute.
7. AUDIO OPERATIONS 10) VOLUME KNOB Turn this knob to adjust desired volume level. 4) AUDIO BUTTON Press this button to select desired audio function. ORDER OF FUNCTION: VOLUME(VOL) -> BASS(BAS) -> TREBLE(TRE) ->BALANCE(BAL) ->FADER(FAD) While the selected function is displayed, turn Volume Knob to adjust the level within 5 seconds, otherwise the unit will return to volume adjustment mode. 2) MUTE BUTTON (MUTE) Press this button to mute the sound. Press it again to resume listening.
8. RADIO OPERATIONS 11) AUTO MEMORY STORE/PRESET SCAN BUTTON (AS/PS) 1. PRESET SCAN: Press AS/PS button briefly to enter Preset Scan mode, it will scan all the preset stations in the memories, you can hear that it will stay on each station for about 5 seconds. 2. AUTO MEMORY STORE: Press AS/PS button for couple of seconds to enter Auto Store mode, this feature will automatically scan the current band and enter up to 6 strongest stations into the 6 preset memories.
9. CD OPERATIONS M1) PAUSE BUTTON (PAUSE) Press this button to pause CD play, press again to release pause. M2) SCAN BUTTON (SCAN) Press this button, the first 10 seconds of each track will be played sequentially until this button is pressed again, then normal play will resume at the current track. M3) REPEAT BUTTON (REPEAT) Press this button, the current track will be played repeatedly until this button is pressed again. M4) SHUFFLE BUTTON (SHUFFLE) Press this button to play all tracks on CD in random.
10.MP3 OPERATIONS Notes : - An MP3 directory is shown in this manual as “Directory”, and an MP3 file is shown as “Track”. - Maximum length of file name : 28 characters. - Maximum length of directory : 16 characters. - Maximum number of tracks per disc : 254. - Maximum number of directories per disc : 128. - Sampling Frequencies support : 32KHz, 44 KHz, 48KHz. - Bit Rates support : 64 - 320KHz including VBR. - Supports Multi-Session recording. - Supports CD, CDR and CDRW.
(2) SEARCH DIRECTORY / TRACK NAME BY USING VOLUME KNOB Under MP3 Play Mode, press MP3 MENU BUTTON twice, the display shows “ * “. Rotate the VOLUME KNOB for selecting the character. In this Encoder Search mode, SELECT button use as move cursor. Press BAND/LOUDNESS button use as MP3 CONFIRM BUTTON. The unit searches files and directories which have the same character which is inputted by the user. The unit shows these sorted files and directories by VOLUME KNOB ( ROTATE ANTI-CLOCKWISE First ).
10. REMOTE CONTROL 1 8 9 2 3 10 4 5 11 6 12 7 13 14 OPERATIONS: Key Radio Mode CD Player Mode 1. Power ( ) Power On/Off Power On/Off Power On/Off 2. Volume Up/Down Adjust Vol,Bas, Tre,Fad,Bal Adjust Vol,Bas, Tre,Fad,Bal Adjust Vol,Bas, Tre,Fad,Bal 3. ID3/DISP Display Clock Display Clock ID3 tag information Display Clock, Numeric key 0* 4.Stereo/Mono Stereo/FM Mono No Functio n No Functio n MP3 Mode 5.
12. SPECIFICATIONS CD PLAYER System Usable disc Sampling frequency No of quantization bits Frequency Number of channels S/N Ratio RADIO SECTION FM Frequency Range Intermediate Frequency Usable Sensitivity Stereo Separation S/N Ratio AM/MW Frequency Range CD Player Sistema: Tipo de disco: Frequência de Amostragem: Conversor D/A: Resposta de frequencia Número de canais: Relação sinal/ruído: Compact disc audio system Compact disc 44.1KHz 1bit 5-20,000Hz 2 stereo 70dB Rádio FM Faixa de Frequencia: 87.
13.TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. Symptom No power Disc cannot be loaded or ejected Cause Solution The car ignition is not on. If the power supply is properly connected to the car accessory terminal, switch the ignition key to “ACC” The fuse is blown. Replace the fuse. Presence of CD disc inside the player.
