Specification Sheet

4722-1015
Napkin Disposal
© 2014 Bradley
P.O. Box 309, Menomonee Falls, WI 53052-0309
800 BRADLEY (800 272 3539) [phone]
bradleycorp.com
Page 1 of 2 5/2/2012
This information is subject to change without notice.
Bradley_WasteReceptacle_4722-1015
 Model 4722-1015 — Semi-Recessed
Standard Series — Satin Finish
Single End Compartment
Product Materials
FLANGE: 22 gauge stainless steel with exposed surfaces in architectural
satin finish. One-piece seamless construction, 1" wide with ¼" return.
CABINET: 22 gauge stainless steel. All welded construction.
PUSH FLAP DOOR: 22 gauge stainless steel with exposed surfaces in
architectural satin finish. Heavy-duty stainless steel piano hinge. Self-
closing flap door.
WASTE CONTAINER: 22 gauge stainless steel with tumbler locks keyed
like other Bradley units
Capacity
1.5 gal (0.2 cu. ft.)
Operation
Waste container removable from one side with finger grip. Furnished with
waxed paper liner. Box of 500 waxed paper liners are available by ordering
part number P11-022.
Installation
Verify all rough-in dimensions prior to installation. Requires partition
opening 11"W x 15
3
⁄8"H x 2½"D. Secure unit to framing with mounting
screws (included) at holes provided. Shim at screw points as required.
Guide Specification
Semi-recessed napkin disposal shall be fabricated of 22 gauge stainless
steel with exposed surfaces in satin finish. Self-closing push flap door and
removable stainless steel receptacle with tumbler lock.
Overall dimensions: 12¾"W x 17
1
⁄8"H x 4"D.
ADA Compliant
Consult local and national accessibility codes for
proper installation guidelines.
Conformity and compliance to local and national
codes is the responsibility of the installer.
