Specification Sheet

ManualsBrandsBradley ManualsSanitary NapkinBradley Bradex Recessed Sanitary Napkin Disposal

4A00

Sanitary Product Disposal Unit

P.O. Box 309, Menomonee Falls, WI 53052-0309

800 BRADLEY (800 272 3539) +1 262 251 6000

bradleycorp.com

Page 1 of 2 11/30/2015

This information is subject to change without notice.

Bradley_SanitaryProductDisposal_4A00

 Model 4A00 — Recessed Bradex

(recesses 3

⁄4"; projects 2")

 Model 4A00-10— Semi-Recessed

(recesses 2"; projects 3

⁄4")

Diplomat Series

Product Materials

FLANGE: 0.030-inch/22ga.-(0.76 mm) stainless steel with exposed surfaces in

architectural satin finish. One-piece seamless construction, ⁵⁄₈" wide with ¹⁄₄" return.

CABINET: 0.030-inch/22ga.-(0.76 mm) stainless steel with exposed surfaces

in architectural satin finish. All welded construction matching curvature to other

Bradley Diplomat washroom accessories.

PUSH FLAP DOOR: Fabricated of heavy gauge stainless steel with exposed

surfaces in architectural satin finish. Heavy-duty stainless steel piano hinge and

tumbler locks keyed like other Bradley units. Self-closing flap door.

Capacity

1.5 gal (0.2 cu. ft.)

Operation

Waste container removable from one side with finger grip.

Installation

Verify all rough-in dimensions prior to installation. Requires opening

⁄4"W x 13

⁄4"H x 4"D (Semi-recessed unit only 2"D). Secure unit to framing

with mounting screws (not included) at holes provided. Shim at screw points

as required.

Guide Specification

Wall-mounted, single-sided [recessed] [semi-recessed] napkin/tampon disposal

unit with self-trimming flange, with face formed with contemporary contours, radii,

and finish matching related accessories in manufacturer's designer series. Capacity

1.5 gal (0.2 cu. ft.). Equipped with push flap door with concealed hinges, hinged

drop-down service door with keyed tumbler lock, and removable waste container.

Universal keying. Formed from stainless steel sheet with satin finish on exposed

surfaces, fully welded, with seamless corners and burr-free edges: cabinet, flange,

and waste container 0.030-inch / 22-ga. thick; door 0.036-inch / 20-ga. thick.

Overall dimensions: 12⁵⁄₁₆"W x 14¹³⁄₁₆"H x 5³⁄₄"D.

ADA Compliant

Consult local and national accessibility codes for

proper installation guidelines.

Conformity and compliance to local and national

codes is the responsibility of the installer.

Recessed

Semi-Recessed

For information on Warranties, Maintenance and BAA/ARRA

Compliance, visit our web site at:

bradleycorp.com/products/accessories/.

MasterFormat Title: Commercial Toilet Accessories

MasterFormat Number: 10 28 13.13

OmniClass Title: Toilet and Bath Specialties

OmniClass Code: 23.31.25.00

Summary of content (2 pages)

PAGE 1
4A00 Sanitary Product Disposal Unit M odel 4A00 — Recessed Bradex® (recesses 33⁄4"; projects 2") M odel 4A00-10— Semi-Recessed (recesses 2"; projects 33⁄4") Diplomat Series Product Materials FLANGE: 0.030-inch/22ga.-(0.76 mm) stainless steel with exposed surfaces in architectural satin finish. One-piece seamless construction, ⁵⁄₈" wide with ¹⁄₄" return. CABINET: 0.030-inch/22ga.-(0.76 mm) stainless steel with exposed surfaces in architectural satin finish.
PAGE 2
4A00 Sanitary Product Disposal Unit Dimensions Recessed Semi-Recessed 4"Max. (102 mm) 2" (51 mm) 33⁄4" (95 mm) 11" (279 mm) 11" (279 mm) 12⁹⁄₁₆" (319 mm) 12 ⁄ " (313 mm) 5 16 131⁄2" (343 mm) 131⁄2" (343 mm) 15¹⁄₁₆" (382 mm) 143⁄16" (376 mm) 81⁄16" (205 mm) 8³⁄₁₆" (208 mm) Dim. "A" to finished floor Dim. "A" Key Surface: Top of Door (4" Door Opening) to finished floor Page 2 of 2 11/30/2015 This information is subject to change without notice. Bradley_SanitaryProductDisposal_4A00 For Dim.
