Specification Sheet

5224
Toilet Tissue Dispenser
© 2014 Bradley
P.O. Box 309, Menomonee Falls, WI 53052-0309
800 BRADLEY (800 272 3539) [phone]
bradleycorp.com
Orders composed of products indicated as Bradex
®
will be available to ship in three days after receipt of
order at the factory. There is no pricing penalty for
this service from Bradley.
Page 1 of 1 4/1/2010
This information is subject to change without notice.
Bradley_TPDispenser_5224
2¾"
(70mm)
9⁷⁄₈"
(232mm)
12³⁄₈"
(314mm)
4⁵⁄₁₆"
(110mm)
Model 5224 — Bradex
®
Controlled Delivery
Dual Roll (For Single Roll see Model 5054)
Product Materials
UNIT: heavy-duty chrome-plated steel.
Capacity
Two standard core toilet tissue rolls through 6" in diameter.
Operation
Remove tissue roll core to access special locking mechanism for ser vic ing.
Tension spring controls paper delivery.
Installation
Verify all rough-in dimensions prior to installation. Secure to wall with
mounting screws (included) at holes provided.
Guide Specification
Surface-mounted toilet tissue dispenser shall be heavy-duty chrome-plated
steel and hold two standard core toilet tissue rolls. Tension spring controls
paper delivery.
Overall dimensions: 12
3
⁄8"W x 2¾"H x 4
5
⁄16"D.
