Specification Sheet

591
Combination Unit
© 2014 Bradley
P.O. Box 309, Menomonee Falls, WI 53052-0309
800 BRADLEY (800 272 3539) +1 262 251 6000
bradleycorp.com
Orders composed of products indicated as Bradex
®
will be available to ship in three days after receipt of
order at the factory. There is no pricing penalty for
this service from Bradley.
Page 1 of 2 8/13/2012
This information is subject to change without notice.
Bradley_CombiDispenser_591
ADA Compliant
Consult local and national accessibility codes for proper
installation guidelines.
Conformity and compliance to local and national codes is
the responsibility of the installer.
Model 591 — Partition-Mounted Bradex
®
Serves Two Compartments
Seat Cover Dispenser/Dual Roll Tissue Dispenser/Waste
Receptacle
Product Materials
CABINET: 22 gauge stainless steel with exposed surfaces in architectural satin
finish. Welded construction with burr-free edges.
FLANGE: 22 gauge stainless steel with exposed surfaces in architectural satin
finish. One-piece seamless construction, 1" wide with ¼" return.
DOOR: 18 gauge stainless steel with full-length piano hinge and tumbler lock
keyed like other Bradley units.
PUSH FLAP DOOR: 22 gauge stainless steel with exposed surfaces in
architectural satin finish. Self-closing, with heavy-duty stainless steel piano
hinge.
WASTE RECEPTACLE: leakproof molded plastic. 0.88 gal. capacity.
SPINDLE: polyethylene, non-removable by user.
Capacity
Toilet Seat Cover Dispensers — 1,000 standard single-fold or half-fold toilet
seat covers; Toilet Tissue Dispensers — four standard core toilet tissue rolls
through 5¼" in diameter. Box of 500 waxed paper napkin disposal liners are
available by ordering part number P11-022.
Operation
Hinged access door permits servicing of components from one side.
Installation
Verify all rough-in dimensions prior to installation. Requires partition opening
15
3
⁄8"W x 28
7
⁄8"H. (Location of hole and dimensions should be noted in partition
specifications.) Flanges adjustable for partitions from
3
⁄8" to 2¾" thick. Remove
one flange and install cabinet in partition opening flush against partition.
Position flanges on both sides of cabinet and secure with mounting screws
(included) at holes pro vid ed.
Guide Specification
Partition mounting combination unit shall include toilet seat cover dis pens er,
toilet tissue dispenser, and napkin disposal, and be fabricated of heavy gauge
stainless steel with seamless ex posed surfaces in satin finish. Door and back
panel shall be 18 gauge. Door shall have piano hinge and tumbler locks.
Overall dimensions: 17
1
⁄8"W x 30
5
⁄8"H x 4½"D.
5900 Series Combination Units are to be installed so that
doors open 90° to fill product and maintain waste container.
