Specification Sheet

9533, 9534, 9535, 9537
Shower Curtain
© 2017 Bradley
P.O. Box 309, Menomonee Falls, WI 53052-0309
800 BRADLEY (800 272 3539) [phone]
bradleycorp.com
Orders composed of products indicated as Bradex
®
will be available to ship in three days after receipt of
order at the factory. There is no pricing penalty for
this service from Bradley.
Page 1 of 1 4/6/2017
This information is subject to change without notice.
Bradley_ShowerCurtain_9533_34_35_37
Model 9533 Antimicrobial Vinyl Shower
Curtain
Guide Specification
Shower curtain 6 gauge vinyl material with hemmed top edges and aluminum grommets
on 6” centers. White only.
Vinyl Shower Curtain Model 9533 is available in widths of 36", 42", 48", 60",
or 72" and heights of either 72" or 78". See charts below for dimensional
information.
Model 9534 Duck Shower Curtain
Guide Specification
Shower curtain is 8-oz. 100% cotton duck material with hemmed top edges and chrome-
plated nickel grommets on 6" centers. White only.
Duck Shower Curtain shall be Bradley Model 9534 is available in widths of
36", 42", 48", 60", or 72" and heights of either 72" or 78". See charts below
for dimensional information.
Model 9533 and Model 9534 Shower Curtains have a tolerance of +/- 2"
length and +/- 2" width, top edge hemmed.
Model 9533 – Antimicrobial Vinyl Shower Curtain (White) Bradex
®
Model 9534 – Duck Shower Curtain (White)
Model 9535 – Antimicrobial Shower Curtain (Green)
Model 9537 – Antimicrobial Shower Curtain (White) Bradex
®
9535 and 9537 Width Tolerances
Width Tolerance
36" (914mm) +/- 2"
42" (1067 mm) +/-2"
48" (1219 mm) +/-2"
60" (1524 mm) +/-2"
72" (1829 mm) +/-2"
Length tolerance is +/-2"
Model 9535 & 9537 Antimicrobial Shower
Curtain
Guide Specification
Shower curtain is 9-oz. nylon-reinforced antimicrobial PVC vinyl fabric (flameproof, stain
resistant, self-deodorizing) and furnished with aluminum grommets on 6" centers. Shower
curtain is .014" thick with top edge hemmed. Ideal for hospital applications. Model 9535
is Green. Model 9537 is White.
Antimicrobial Shower Curtain Model 9535 and 9537 is available in widths of
36", 42", 48", 60", or 72" and heights of either 72" or 78". See charts below
for dimensional information.
9533 Models Bradex
®
Width Height Overall
Dimensions
(Inches)
Overall
Dimensions
(Millimeters)
# of 9536 Shower
Hooks Required
(Order Separately)
36" (914 mm) 72" (1829 mm) 36 x 72 914 x 1829 6
42" (1067 mm) 72" (1829 mm) 42 x 72 1067 x 1829 7
48" (1219 mm) 72" (1829 mm) 48 x 72 1219 x 1829 8
60" (1524 mm) 72" (1829 mm) 60 x 72 1524 x 1829 10
72" (1829 mm) 72" (1829 mm) 72 x 72 1829 x 1829 12
9534 Models
Width Height Overall
Dimensions
(Inches)
Overall
Dimensions
(Millimeters)
# of 9536 Shower
Hooks Required
(Order Separately)
36" (914 mm) 72" (1829 mm) 36 x 72 914 x 1829 6
42" (1067 mm) 72" (1829 mm) 42 x 72 1067 x 1829 7
48" (1219 mm) 72" (1829 mm) 48 x 72 1219 x 1829 8
60" (1524 mm) 72" (1829 mm) 60 x 72 1524 x 1829 10
72" (1829 mm) 72" (1829 mm) 72 x 72 1829 x 1829 12
9535 Models
Width Height Overall
Dimensions
(Inches)
Overall
Dimensions
(Millimeters)
# of 9536 Shower
Hooks Required
(Order Separately)
36" (914 mm) 72" (1829 mm) 36 x 72 914 x 1829 6
42" (1067 mm) 72" (1829 mm) 42 x 72 1067 x 1829 7
48" (1219 mm) 72" (1829 mm) 48 x 72 1219 x 1829 8
60" (1524 mm) 72" (1829 mm) 60 x 72 1524 x 1829 10
72" (1829 mm) 72" (1829 mm) 72 x 72 1829 x 1829 12
9537 Models Bradex
®
Width Height Overall
Dimensions
(Inches)
Overall
Dimensions
(Millimeters)
# of 9536 Shower
Hooks Required
(Order Separately)
36" (914 mm) 72" (1829 mm) 36 x 72 914 x 1829 6
42" (1067 mm) 72" (1829 mm) 42 x 72 1067 x 1829 7
48" (1219 mm) 72" (1829 mm) 48 x 72 1219 x 1829 8
60" (1524 mm) 72" (1829 mm) 60 x 72 1524 x 1829 10
72" (1829 mm) 72" (1829 mm) 72 x 72 1829 x 1829 12
