Bradley_ShowerAccessories_1CWallArm
Standard Institutional Showerhead (S15)
Features
• Chrome plated brass arm with stainless steel wall flange
• Adjustable spray pattern
• 1.5 GPM (4.7 LPM) flow control
Standards
• Showerhead meets ANSI A112.18.1M flow requirements
Options
Volume Control - Allen Key (AKV)
Key operated volume control is adjustable by supervisory personnel only. Does not
compensate for pressure fluctuations but restricts maximum discharge to desired level.
Volume Control - Lever Handle (LHV)
Lever Handle operated volume control is adjustable by user. Does not compensate for
pressure fluctuations but restricts maximum discharge to desired level.
Lockable Universal Ball Joint (LBJ)
Allows showerhead to be locked at desired angle. Ideal for keeping spray away from dry
areas.
Deluxe Showerhead with
Ball Joint and Wall Arm (SF)
Features
• Chrome plated brass arm with stainless steel wall flange
• Self cleaning spray disc
• Ball joint
• 1.5GPM (4.7 LPM) flow control
Standards
• Showerhead meets ANSI A112.18.1M flow requirements
Cone
Heavy chrome-plated ABS construction. All internal components are anti-liming.
Dimensions
(mm)
3" (76.2)
1-1/2"
(38.1)
2-3/8" (60.3)
1/2" (12.7)
Centerline
of pipe
1C
Showerheads – Institutional Wall Arm
