Installation

P.O. Box 309

Menomonee Falls, WI 53052 USA

800 BRADLEY (800 272 3539)

+1 262 251 6000

bradleycorp.com

IMPORTANT

Read this entire installation manual to ensure proper installation. When finished with the installation, file

this manual with the owner or maintenance department. Compliance and conformity to local codes and

ordinances is the responsibility of the installer.

Pressurized plumbing fixtures shall be installed in accordance with manufacturer´s recommendations. The

supply piping to these devices shall be securely anchored to the building structure to prevent installed

device from unnecessary movement when operated by the user. Care shall be exercised when installing the

device to prevent marring the exposed significant surface.

Separate parts from packaging and make sure all parts are accounted for before discarding packaging

material. If any parts are missing, do not begin installation until you obtain the missing parts.

Make sure that all water supply lines have been flushed and then completely turned off before beginning

installation. Do not use pipe dope. Debris in supply lines can cause valves to malfunction.

Do not modify or convert this Faucet; any modifications will void warranties.

Product warranties may be found under “Products” on our web site at www.bradleycorp.com.

Aerada 1000 Series Faucet

S53-326 AC Gooseneck

S53-327 DC Gooseneck

Aerada 1100 Series Faucet

S53-328 AC High Arc Infrared

S53-329 DC High Arc Infrared

Table of Contents

Supplies Required.................. 2

Installation ..................... 4

Manual Settings ................... 6

Adjustments....................................9

Troubleshooting ................................10

Care and Maintenance ..........................12

Multi-Faucet Transformer Wiring ...................14

Aerada 1000

Aerada 1100

215-1628 Rev. C; ECN 16-02-002

Page 1 of 13 9/1/2016

Summary of content (13 pages)

PAGE 1
Installation Aerada 1000 Series Faucet S53-326 AC Gooseneck S53-327 DC Gooseneck Aerada 1100 Series Faucet S53-328 AC High Arc Infrared S53-329 DC High Arc Infrared Aerada 1000 Aerada 1100 Table of Contents Supplies Required . . . . . . . . . . . . . . . . . . 2 Installation . . . . . . . . . . . . . . . . . . . . . . 4 Manual Settings . . . . . . . . . . . . . . . . . . . 6 Adjustments . . . . . . . . . . . . . . . . . . . . .
PAGE 2
Aerada 1000/1100 Series Installation Faucet Accessories Part No. Description 150-221 4" Cover Plate 232-008 Plugin Transformer 232-009 Hardwired Transformer (1-8 faucets) 269-2479 .5 GPM Non-Aerating Flow for Gooseneck 269-2478 .5 GPM Non-Aerating Flow for High Arc 269-1923 2.2 GPM Laminar Flow for Goodneck* 269-1922 2.2 GPM Laminar Flow for High Arc* 261-010 6V Lithium Battery CR-P2 *2.2 GPM flow control does not meet California Energy Commission 20 CCR T.20, Div. 2, 1601-1609.
PAGE 3
Aerada 1000/1100 Series Installation Installation This faucet comes with all the components needed for installation,however, some tools and supplies are not included. • • • • • • 3 Mount bracket from underneath. Place hoses through large opening and mounting rod through small opening. Make sure flange sits securely against surface.
PAGE 4
Aerada 1000/1100 Series Installation Start-Up Operation Test Function Before startup operation, be sure: • • • • 1 1 Hold hand in front of sensor. Water should start to flow. Fully open supply valves. CAUTION Hot water may burn skin. Hold hand carefully under water and remove quickly. For faucets with external mixer, turn mixer handle from cold to warm. Water temperature should increase. 2 Remove all items from sink. 3 Remove protective covering from sensor.
PAGE 5
Aerada 1000/1100 Series Installation Enabling "Manual Setting Mode" A battery model is shown in the following example. These instructions apply to all models. After 30 minutes, the "Manual Setting" mode will be disabled automatically and all settings will be saved. 5 a - Re-insert battery b - LED lights up c - Remove battery immediately after LED switches off. Before enabling mode, be sure: • Water supply valve is open. • Battery is full (LED does not blink) for DC faucets.
PAGE 6
Aerada 1000/1100 Series 9 Installation Mount mixer handle (only for faucets with external mixer). Setting Normal Mode Setting the normal mode will allow the faucet to activate only when it senses a hand presence. 1 Enable "Manual Setting" Mode (see "Manual Setting Mode" on page 5). 2 Fully cover sensor with hand. Water flow stops after 5 seconds. Continue to hold on for one (1) additional water pulse. 3 Remove hand. Normal Mode is now activated.
PAGE 7
Aerada 1000/1100 Series Installation Setting Scrub Mode (60 seconds) Sensor Range Adjustment Setting scrub mode for 60 seconds will allow the faucet to activate for 60 seconds from the last hand presence. The detection distance of the sensor can be adjusted between approximately 4 - 11 inches from the infrared window. 1 Enable "Manual Setting" Mode (see "Manual Setting Mode" on page 5). 2 Fully cover sensor with hand. Water flow stops after 5 seconds.
PAGE 8
Aerada 1000/1100 Series Installation Faucet Adjustments Operating modes and sensor ranges can be adjusted with a manual operation through the infrared sensor. Faucet adjustment operations apply to all models. Operating Modes Operating Modes Description Cleaning Mode The faucet is inactive for 90 seconds. Normal Mode The faucet is activated if it senses a hand presence. This is the default operating mode of the faucet.
PAGE 9
Aerada 1000/1100 Series Installation Troubleshooting Problem No water flow Possible Cause Solution Supply valves are closed Open supply valves Aerator is blocked or dirty Clean or replace aerator (See "Care and Maintenance") Inlet water line filter is dirty or blocked Clean or replace filter (See "Care and Maintenance") Braided hose is kinked Eliminate braided hose kink No external water pressure Check water pressure/Provide water pressure Battery is drained (DC faucets only) Replace battery
PAGE 10
Aerada 1000/1100 Series Problem Installation Possible Cause Water runs continuously and stops when object present Connector between electronics module and solenoid valve plug is reversed Plug connector properly Water runs continuously Interfering object is in monitoring range Remove object from monitoring area Remove and re-install shut-off screw.
PAGE 11
Aerada 1000/1100 Series Installation Care and Maintenance The following are described in this section: • • • • Activating Cleaning Mode Replacing Battery Cleaning or Replacing Inlet Filter Adjusting Water Temperature (Internal Mixer) • Adjusting Hot Water Limiter (External mixer) • Cleaning or Replacing Aerator 3 Remove housing vertically. 4 Remove used battery from battery holder and recycle. 5 Insert new battery. The LED lights up for 1 second. 6 Mount housing vertically.
PAGE 12
Aerada 1000/1100 Series 7 Installation Adjusting Hot Water Limiter (External Mixer) Install shut-off screw. The proportion of hot water can be switched from approximately 85% to 95% (or reverse) depending upon inlet water pressures and temperatures. The default setting is 85%. CAUTION Hot water may burn skin. Hold hand carefully under water and remove quickly. 8 1 Remove mixer handle. 2 Carefully pull out hot water limiter from handle (using pliers) and reverse by 180°.
PAGE 13
Aerada 1000/1100 Series Installation Cleaning or Replacing Aerator 1 Remove shut-off screw. 2 Remove aerator with vandal resistant wrench supplied with the faucet. Clean or replace aerator, then reinstall. 3 Install shut-off screw. Multi-Faucet Transformer AC Connector from Faucet Bank Installation Adapter Wire Bank Installation Adapter Wire (Incl. w/ AC Faucet) 232-009 (1–8 faucets) Additional Wiring, if needed, To be Supplied by Customer (22 GA min; 50 ft. max.
