5050

OWNERS MANUAL

Premier Series

7-Day Programmable

Single Stage Heat / Cool

Digital Thermostat

Compatible with low voltage single stage gas,

oil or electric heating or cooling systems,

including single stage heat pumps. This

thermostat can also be used on 250mv to

750mv millivolt heating only systems.

Do not use this thermostat on applications

with voltages above 30 Volts AC.

READ ALL INSTRUCTIONS BEFORE PROCEEDING

Store this

booklet for

future reference

Braeburn Systems LLC, as an Energy Star partner

has determined that this product meets the Energy

Star Guidelines developed by the U.S. Environmental

Protection Agency & the U.S. Department of Energy

for maximum energy efficiency.

WARRANTY

YEAR

LIMITED

CONTENTS

WARNING!

Quick Reference Contents Guide

Important Safety Information

FEATURES

SPECIFICATIONS

INSTALLATION

Replacing Existing Thermostat

Installing Your New Thermostat

TESTING YOUR NEW THERMOSTAT

PROGRAMMING

Default Thermostat Settings

Setting Current Time of Day and Day o f Week

Setting Temperature Differential a nd Residual

Cooling Fan Feature

Setting Temperature Differential

Setting Residual Cooling Fan Feature

Setting Your Energy Saving Programs

Tips Before Starting

Using Quick Program Groups

or Individual Day Programming

Entering Your Program

ADDITIONAL OPERATION FEATURES

Review Set Temperature

Temporary Program Override

Permanent Hold (Vacation) Mode

High Temperature Safety Switch

Low Temperature "Freeze" Protection

Compressor Protection

Changing Fahrenheit (˚F) to Celsius (˚C)

Low Battery Detection and Replacement

Replacing the Batteries

Resetting T hermostat

TROUBLESHOOTING

WIRING DIAGRAMS

5.1

3.1

3.2

5.2

5.3

5.4

6.1

6.2

6.3

6.4

6.5

6.6

6.7

6.8

6.9

5.3.1

5.3.2

5.4.1

5.4.2

5.4.3

6.8.1

• Always turn off power to the air conditioning or heating system prior to installing,

removing, cleaning or ser vicing thermostat.

• Read this manual thoroughly prior to installing, programming or operating this

thermostat.

• This thermostat is designed for use with a 24 Volt AC low voltage single stage gas

oil or electric heating or cooling system. This thermostat can also be used on

250mv to 750mv millivolt heating only systems.

• Do not use this thermostat on applications with voltages higher than 30 Volts AC.

• This thermostat requires two (2) properly installed "AA" alkaline batteries to

provide power for the thermostat to properly control the system operation.

• The system must have 24 Volt AC power present for proper system operation and

control.

• Wiring must conform to all building codes and ordinances as required by local

and national code authorities having jurisdiction.

• Do not short (or jumper) across terminals on the gas valve or at the hea ting or

cooling system control board to test the thermostat installation. This could

damage the thermostat and void the warranty.

• Do not select COOL mode of operation if the outside temperature is below 50˚ F

(10˚ C). This could possibly damage the controlled cooling system and may cause

personal injury.

• This thermostat should only be used as described in this

manual. Any other use is not recommended and will void the warranty.

Summary of content (9 pages)

PAGE 1
Quick Reference Contents Guide CONTENTS 1 FEATURES 2 SPECIFICATIONS 3 INSTALLATION 5050 Premier Series 7-Day Programmable Single Stage Heat / Cool Digital Thermostat 4 5 OWNERS MANUAL Compatible with low voltage single stage gas, oil or electric heating or cooling systems, including single stage heat pumps. This thermostat can also be used on 250mv to 750mv millivolt heating only systems. Do not use this thermostat on applications with voltages above 30 Volts AC.
PAGE 2
1 3 FEATURES • Contemporary Styling with Large LCD Display • 7 Day Programming Flexibility • Battery Powered (2 "AA" Alkaline batteries included) • Relay Outputs for Maximum Compatibility • LCD Display Backlight • Easy Access Front Battery Door • Pre-Programmed for Quick Installation • Meets Title 24 and Energy Star® Energy Saving Guidelines • Vacation "HOLD" Mode • Compressor Short Cycle Protection • Adjustable Temperature Differential • Residual Cooling Fan Delay • Low battery Indication • Quick Wiring
PAGE 3
INSTALLATION 3.2 Installing Your New Thermostat cont. 9. cont. Place the thermostat rear body (mounting plate) against the wall in the desired location making sure the mounting holes are aligned as appropriate and the thermostat wires are properly inserting through opening in middle of rear body. 10. Fasten the rear body (mounting plate) to wall using supplied screws. 4 TESTING YOUR NEW THERMOSTAT cont. 1. Place the system switch in the HEAT position. 2.
PAGE 4
5 cont. 5 5.2 Setting Current Time of Day and Day of Week cont. 5.3 PROGRAMMING NOTE: The thermostat will return to normal operating mode automatically after 15 seconds if no key is pressed. It will also return to normal operating mode immediately if the RESUME button is pressed. 5.3 Setting Temperature Differential and Residual Cooling Fan Feature The default settings for the temperature differential and residual cooling fan delay settings are compatible with most systems and applications.
PAGE 5
PROGRAMMING cont. 5.4 Setting Your Energy Saving Programs cont.. 5.4.2 Using Quick Program Groups or Individual Day Programming cont.. Weekend – allows you to program the weekend days (SA, SU will show in the display) at the same time. Again, individual day programming can be used to change specific setpoint times or temperatures. Individual Days – allows you to program each day of the week individually to give you the greatest schedule flexibility.
PAGE 6
ADDITIONAL OPERATION FEATURES cont. 6.4 High Temperature Safety Switch 6.7 Changing Fahrenheit (°F) to Celsius (°C) cont. While the thermostat is in the HEAT mode of operation (selector switch in the HEAT position), the thermostat will mechanically turn-off if the room temperature raises higher than 99˚F (37˚ C). There is also a software feature that will automatically turn-off the thermostat in HEAT mode if the temperature raises higher than 93˚ F (34˚ C). 4.
PAGE 7
TROUBLESHOOTING SYMPTOM Thermostat does not turn on heating or cooling system. POTENTIAL SOLUTION Check to see if OFF is shown in display. This indicates that the system is turned off at the thermostat. Move the system selector switch to the HEAT or COOL position. After the compressor short cycle protection 5-minute period expires the system should start within a minutes time. Compressor protection features may be in effect due to compressor short cycle conditions, power outages or rolling blackouts.
PAGE 8
7 TROUBLESHOOTING cont. SYMPTOM POTENTIAL SOLUTION Thermostat will not allow me to program a setpoint temperature higher than 90˚ F (32˚ C). This is above the normal thermostat temperature setting range of 45˚ to 90˚ F (7˚ to 32˚ C). Thermostat will not allow me to program a setpoint temperature lower than 45˚ F (7˚ C). This is below the normal thermostat temperature setting range of 45˚ to 90˚ F (7˚ to 32˚ C). Fan continues to run all the time whether the system is on or off.
PAGE 9
8 WIRING DIAGRAMS cont.
