Specifications

108
A1: 6" DR -13.98 "
A2: 4" DR -11.98 "
C: 7.4 0 "
E:8.50 "
B1: 6" DR -12.20 "
B2: 4" DR -10.20 "
D: 5.91"
DR = Downrod
SPECSFEATURES
Heavy-Duty, 3-Speed Reversible Motor
Dual Mount
4" & 6" Downrods (Included)
Limited Lifetime Warranty
Blades Sold Separately
Integrated LED Light Source (Dimmable)
ICS Remote and Wall Controls (Included)
Suitable for Damp Locations
CEILING DROP DIMENSIONS
Blade Sweep. ............... 60"
Number of Blades
........... 3
Blade Pitch .................. Variable
Motor Size (MM) ............. 188 x 22
AMPS (HI Speed) . . . . . . . . . . . . <1
Shipping Wt. (lbs.)........... 16.27
CU. FT. in Carton ............ 1.63
Energy Guide Airflow
(Cubic Feet Per Minute)
.....4,374
Energy Guide Wattage
...... 51 Watts
Energy Guide Efficiency
(CFM Per Watt)
.............95
Energy Guide
Estimated Yearly Cost*
.....$11
LED Specs:
Color Temp 3000K
Lumens 1,350 lm
CRI 90
Watts 17
LED Module is Guaranteed for 5 Years
*Based on 12 cents per kWh and 6.4 hours use per day.
