BREW EXPRESS ™ INSTT ALLAT INS ALLAT ION GUI G UIDE DE 2 by model no.
CONT EN TS GET TING STARTED IMPORTANT: 1. Getting Started 1 2. Safety 2 3. Hardware/Tools 3 4. Specification and Requirements Read and follow instructions carefully before installing your BREW EXPRESS™ in-the-wall COFFEE SYSTEM. For best results its advised that you hire a qualified professional. Getting Started 1. Carefully unpack BREW EXPRESS™ from gift box. 4 2. Remove carafe from brewing unit and set aside. 5. Location (area of Installation) 5 3. 6.
SAFETY HARDWARE/TOOLS IMPORTANT: Read and follow instructions carefully before installing your BREW EXPRESS™ in-the-wall COFFEE SYSTEM. Wire the BREW EXPRESS™ to a GFCI ground protected source. This can be accomplished by: (A). Wiring the unit directly to a string of outlets that are protected by a GFCI outlet. OR (B). Wiring the unit with a dedicated line to electrical panel with a GFCI breaker. FOR BEST RESULTS ITS ADVISED THAT YOU HIRE A QUALIFIED PROFESSIONAL.
SPECIFICATIONS AND REQUIREMENTS IMPORTANT: Read and follow instructions carefully before installing your BREW EXPRESS™ in-the-wall COFFEE SYSTEM. For best results it is advised that you hire a qualified professional. 1. Overall Dimensions (Finished Unit with Rough-in-Box) approximately 12.5” x 12.5” (see below). 2. Dimensions for Rough-in-Box (Mounting Structure) approximately 11.5” x 11.5” x 4”. 3. Electrical Requirements 120VAC, 60HZ. (1400 watts). 4.
WATER INSTALLATION POWER INSTALLATION Always turn off water supply at source. It is strongly advised you consult a qualified professional plumber when attempting to install BREW EXPRESS™ in-the-wall COFFEE SYSTEM. Always turn off power supply at main electrical panel before attempting any electrical installation. Local electrical codes vary. All electrical installation must be done in accordance with local codes. Installation must be peformed by a Qualified Electrican only, or equivalent.
BREWER INSTALLATION IMPORTANT: If installing Unit PRIOR to cabinets, it is strongly advised to consult with cabinet maker and building contractor for exact height of counter top due to the various thicknesses of counter tops (tile laminate, granite, etc). For best results cut hole and install unit AFTER cabinets are installed. A. Installing BREW EXPRESS™ on Counter BREWER INSTALLATION Installation of Rough-In-Box 1. Locate wall studs within the desired location of wall.
BREWER INSTALLATION BREWER INSTALLATION 5. After sheet rock screws are in place, gently bend appropriate tabs (long or short depending on wall thickness such as tile or granite) as shown on all other areas to finish securing rough-in box to wall. Use pliers (if needed) to bend/crimp tabs firmly to wall. Gently slide excess water line back through grommet into wall cavity leaving top of connector a maximum of 3” above bottom of rough-in box. See Figure 5. and Figure 6.
TESTING TROUBLESHOOTING Testing A. Display is not illuminated Once BREW EXPRESS™ has been installed into the rough-in-box it must be tested to ensure proper operation. • Ensure the power to the rough-in box is turned on (check circuit breaker). 1. Turn on electrical power. Check to see if display panel is illuminated, The display panel is lit when electrical supply has been properly connected. If the display panel is not lit, refer to the troubleshooting section of this manual.
Printed in CHINA.
