SPECIFICATION SHEET
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
MODELS RMDD3004EX,
RMDD3604EX, RMDD4804EX
REMOTE DOWNDRAFT
20F 99043190A
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
NuTone, Inc., 4820 Red Bank Road, Cincinnati, OH 45227 (1-800-543-8687)
Broan-NuTone Canada, Inc., 1140 Tristar Drive, Mississauga, Ontario, L5T 1H9 (1-888-882-7626)
Exhaust your cooktop without the use of an ovehead
hood. Control a powerful exterior blower (600-1500
CFM) from the cooktop location. Compact design is
installed directly behind cooktop.
FEATURES
HOUSING:
•
Rugged steel construction
•
Finished with silver paint
•
Space-saving - can be used with most cooktops on the
market
•
30", 36", or 48" widths - Fits standard-size cabinets
CHIMNEY ASSEMBLY:
•
Brushed stainless steel cover - just press button to turn
unit "ON"
•
Chimney rises 9½" when activated - ideal for large pots
and pans
•
Stylish, stainless steel filters with aluminum mesh - easy
to remove and dishwasher-safe
•
Stainless steel chimney front and back - makes cleanup
quick and easy
•
Flush-mounted, infinite rotary speed blower control
•
Heat Sentry adjusts speed of blower to HIGH in case of
excess heat
•
Conveniently located button - press to lower air vent and
turn unit "OFF"
•
OPTIONAL Remote Control (Model RMDDRBK) acti-
vates downdraft from alternate location
DUCT CONNECTOR HOUSING:
•
Rugged steel construction with galvanized finish
•
3¼" x 14" rectangular duct connector (8" round duct using
Model 459 transition)
•
3-position discharge - movable to adjust to floor joists
TYPICAL SPECIFICATION
Downdraft blower system shall be Rangemaster
®
Model
RMDD3004EX (RMDD3604EX) (RMDD4804EX).
Unit to have steel housing with silver paint finish. Air vent to
rise at least 9½" and have a stainless steel front and back for
ease of cleaning.
Filters to be stainless steel with aluminum mesh, easy to
remove and dishwasher-safe.
3¼" x 14" duct connector shall be adjustable to accomodate
ductwork from left, right, or below and have 7½" side to side
adjustment.
Unit must accept an optional remote control activation but-
ton.
Unit to include Heat Sentry, to adjust blower speed to HIGH
in case of excess heat.
Downdraft system shall operate on 120 VAC and be able to
be plugged into a standard grounded outlet. It will have an
infinite speed blower control.
SPECIFICATIONS
VOLTS HZ AMPS DUCT
120 60 6 3¼" x 14"
