• Industry-leading extended distance support, which enables native Fibre Channel extension greater
than 590 km.
• Expanded security for up to 16,000 hardware zones. Hardware zoning is accomplished at the port
level of the switch or by World Wide Name (WWN). Hardware zoning permits or denies delivery of
frames to any destination port address.
• Unicast, multicast (255 groups), and broadcast data traffic type, are support.
• Brocade Small Form-Factor Pluggable (SFP) or SFP+ optical transceivers support any combination
of Short Wavelength (SWL), Long Wavelength (LWL) or Extended Long Wavelength (ELWL) optical
media among the switch ports.
• Brocade Fabric Operating System (Fabric OS), which delivers distributed intelligence throughout
the network and enables a wide range of value-added applications including Brocade Advanced
Web Tools and Brocade Zoning. Optional Fabric Services include: Adaptive Networking with QoS,
Brocade Extended Fabrics, Brocade Enhanced Group Management, Brocade Fabric Watch, ISL
Trunking, Integrated Routing, and End-to-End Performance Monitoring (APM).
• Port-to-port latency minimized to 700 nanoseconds through the use of cut-through frame routing at
8 Gbps.
• Extensive diagnostics and system monitoring capabilities, which enhance high Reliability,
Availability, and Serviceability (RAS).
• The Brocade EZSwitchSetup wizard, which makes SAN configuration a three-step point-and click
task.
Facility requirements
The following table provides the facilities requirements that must be met for the Brocade 5100.
Facility RequirementsTABLE 1
Type Requirements
Electrical • Primary AC input 100-240 VAC, 2.0A, 47-63 Hz; switch autosenses input voltage
• Adequate supply circuit, line fusing, and wire size, as specified by the electrical rating on the
switch nameplate
• Circuit protected by a circuit breaker and grounded in accordance with local electrical codes
Refer to GUID-2965C97E-D67D-4F0A-8461-4C96C8CB0654#GUID-2965C97E-
D67D-4F0A-8461-4C96C8CB0654 for complete power supply specifications.
Thermal • A minimum air flow of 79.8 cubic meters/hour (47 cubic ft/min.) available in the immediate
vicinity of the switch
• Ambient air temperature not exceeding 40 ° C (104 ° F) while the switch is operating
Rack (when
rack-
mounted)
• One rack unit (1U) in a 48.3 cm (19-inch) rack
• All equipment in rack grounded through a reliable branch circuit connection
• Additional weight of switch not to exceed the rack’s weight limits
• Rack secured to ensure stability in case of unexpected movement
