Recommendations for cable management
The minimum bend radius for a 50 micron cable is 2 inches under full tensile load and 1.2 inches with
no tensile load.
Cables can be organized and managed in a variety of ways, for example, using cable channels on the
sides of the rack or patch panels to minimize cable management. Following is a list of
recommendations:
NOTE
You should not use tie wraps with optical cables because they are easy to over tighten.
CAUTION
Before plugging a cable into to any port, be sure to discharge the voltage stored on the cable
by touching the electrical contacts to ground surface.
• Plan for rack space required for cable management before installing the switch.
• Leave at least 1 m (3.28 ft) of slack for each port cable. This provides room to remove and replace
the switch, allows for inadvertent movement of the rack, and helps prevent the cables from being
bent to less than the minimum bend radius.
• If you are using Brocade ISL Trunking, consider grouping cables by trunking groups. The cables
used in trunking groups must meet specific requirements, as described in the Fabric OS
Administrator’s Guide .
• For easier maintenance, label the fiber optic cables and record the devices to which they are
connected.
• Keep LEDs visible by routing port cables and other cables away from the LEDs.
• Use hook and loop style straps to secure and organize fiber optic cables.
Items required for installation
The following items are required for installing, configuring, and connecting the Brocade 5100 for use in
a network and fabric:
• Workstation with an installed terminal emulator, such as HyperTerminal
• Unused IP address and corresponding subnet mask and gateway address
• Serial cable (provided)
• Ethernet cable
• SFPs and compatible cables, as required
• Access to an FTP server for backing up the switch configuration (optional)
Items included with the Brocade 5100
The following items are included with the standard shipment of the Brocade 5100. When you open the
Brocade 5100 packaging, verify that these items are included in the package and that no damage has
occurred during shipping:
• The Brocade 5100 switch, containing two power supply/fan assembly units
• One accessory kit containing:
‐ Serial Cable with an RJ-45 connector
‐ 6 ft. Power Cord
Recommendations for cable management
