LEDs
System component Description
Switch status and
management
One system status LED (above) on the left side
One power status LED (below) on the left side
40 port status LEDs, one for each Fibre Channel port, located above the ports
One power supply status LED on each power supply FRU, to the left of the ON/OFF
rocker switch on the non-port side of the switch
Other
System component Description
Serial Cable RJ-45 connector cable
RJ-45 to DB9 adaptor RJ-45 to DB9 for console cable
RJ-45 connector 10/100 Ethernet management port; in-band over Fibre Channel; serial port (RJ-45)
Weight and physical dimensions
Model Height Width Depth Weight
Brocade 5100 4.3 cm
1.7 inches
42.9 cm
16.9 inches
61 cm
24 inches
9.3 kg
20.6 inches
Environmental requirements
Condition Operational Non-operational
Ambient temperature 0°C to 40°C (32°F to 104°F) -25°C to 70°C (-13°F to 158°F)
Relative humidity
(non-condensing)
10% to 85% at 40°C (104°F) 10% to 95 % at 70°C (158°F)
Altitude (above sea
level)
0 to 3000 m (10,000 feet) 0 to 12000 m (40,000 feet)
Shock 20 G, 6 ms, half-sine wave 33 G, 11 ms, half-sine wave, 3/eg Axis
Vibration 0.5 G sine, 0.4 gms random, 5-500 Hz 2.0 G sine, 1.1 gms random, 5-500 Hz
Brocade 5100 Technical Specifications
