Brocade Mobility RFS4000 Controller Installation Guide 7
53-1001933-02
Chapter
3
LED Codes
In this chapter
•System status LEDs 7
•RJ-45 Gigabit Ethernet LEDs 10
•SFP Gigabit Ethernet LEDs 11
The Brocade Mobility RFS4000 Controller has four vertically-stacked LEDs on its
front panel. Each of the six Gigabit Ethernet Ports have two status LEDs. These
LEDs display two colors (green & amber), and three lit states (solid, blinking, and
off). The following tables decode the combinations of LED colors and states for the
System Status LEDs and the Gigabit Ethernet LEDs.
System status LEDs
SYS
1
2
System Status 1
System Status 2
Fan status
Temperature status
