Network Router User Manual
Table Of Contents
- About This Document
- Introduction
- Common Commands
- In this chapter
- Common commands
- show
- autoinstall
- banner
- commands
- crypto
- environment
- history
- interfaces
- ip
- ldap
- licenses
- logging
- mac
- mac-address-table
- management
- mobility
- ntp
- port-channel
- power
- privilege
- radius
- redundancy dynamic-ap-load-balance
- redundancy group
- redundancy history
- redundancy members
- rtls
- smtp-notification
- snmp
- snmp-server
- spanning-tree
- static-channel-group
- terminal
- timezone
- traffic-shape
- users
- version
- wireless
- (config-wireless) Executable Mode
- wlan-acl
- access-list
- aclstats
- alarm-log
- boot
- clock
- debugging
- dhcp
- file
- ftp
- password-encryption
- running-config
- securitymgr
- sessions
- startup-config
- upgrade-status
- mac-name
- firewall
- role
- virtual-IP
- wwan
- aap-wlan-acl
- aap-wlan-acl-stats
- protocol-list
- service-list
- User Exec Commands
- Privileged Exec Commands
- Global Configuration Commands
- In this chapter
- Global Configuration commands
- aaa
- access-list
- autoinstall
- banner
- boot
- bridge
- country-code
- crypto
- do
- end
- errdisable
- ftp
- hostname
- interface
- ip
- license
- line
- local
- logging
- mac
- mac-address-table
- mac-name
- management
- ntp
- prompt
- radius-server
- ratelimit
- redundancy
- role
- rtls
- service
- smtp-notification
- snmp-server
- spanning-tree
- timezone
- traffic-shape
- username
- vpn
- wireless
- wlan-acl
- network-element-id
- firewall
- virtual-ip
- wwan
- aap-wlan-acl
- arp
- power
- aap-ipfilter-list
- whitelist
- Crypto-isakmp Instance
- Crypto-group Instance
- Crypto-peer Instance
- Crypto-ipsec Instance
- Crypto-map Instance
- Crypto-trustpoint Instance
- Interface Instance
- Spanning tree-mst Instance
- Extended ACL Instance
- Standard ACL Instance
- Extended MAC ACL Instance
- DHCP Server Instance
- DHCP Class Instance
- Radius Server Instance
- Wireless Instance
- In this chapter
- Wireless configuration commands
- aap
- admission-control
- adopt-unconf-radio
- adoption-pref-id
- ap
- ap-containment
- ap-detection
- ap-image
- ap-ip
- ap-standby-attempts-threshold
- ap-timeout
- ap-udp-port
- auto-select-channels
- broadcast-tx-speed
- client
- clrscr
- cluster-master-support
- convert-ap
- country-code
- debug
- dhcp-one-portal-forward
- dhcp-sniff-state
- dot11-shared-key-auth
- end
- exit
- fix-broadcast-dhcp-rsp
- help
- hotspot
- load-balance
- mac-auth-local
- manual-wlan-mapping
- wireless-client
- mobility
- multicast-packet-limit
- multicast-throttle-watermark
- nas-id
- nas-port-id
- no
- proxy-arp
- qos-mapping
- radio
- rate-limit
- secure-wispe-default-secret
- self-heal
- sensor
- service
- show
- smart-rf
- smart-scan-channels
- wlan
- wlan-bw-allocation
- dot11k
- wips
- non-preferred-ap-attempts-threshold
- test
- RTLS Instance
- ESPI Instance
- RFID Instance
- SOLE Instance
- Smart RF Instance
- Role Instance
- AAP IP Filtering
Brocade Mobility RFS4000, RFS6000 and RFS7000 CLI Reference Guide 187
53-1001931-01
Priv Exec command
4
Example
RFController#debug ?
all Enable all debugging
cc Controller (wireless) debugging messages
ccstats Controller (wireless) debugging messages
certmgr Certificate Manager Debugging Messages
dhcpsvr DHCP Conf Server Debugging Messages
imi Integrated Management Interface
ip Internet Protocol (IP)
logging Modify message logging facilities
mgmt Mgmt daemon
mobility L3 Mobility
mstp Multiple Spanning Tree Protocol (MSTP)
nsm Network Service Module (NSM)
pktdrvr Pktdrvr (kernel wireless) debugging messages
radius RADIUS server debugging messages
redundancy Redundancy Protocol debugging messages
securitymgr Security Manager Debugging Messages
sole Location engine debugging messages
RFController#debug
securitymgr
[acldebug|aclerror|all|
debug|dosdebug|
doserror|error|ikedebug|
natdebug|naterror|
packet-forwarding|
pmdebug|pmerror|
rulesdebug|ruleserror|
user]
Security manager debugging messages
• acldebug – Trace debug messages from ACL module
• aclerror – Trace error messages from ACL module
• all – Trace all messages from Security Manager
• debug – Trace general debug messages from Security
Manager
• dosdebug – Trace debug messages from DOS module
• doserror – Trace error messages from DOS module
• error – Trace general error messages from Security Manager
• ikedebug – Trace debug messages from Ike
• natdebug – Trace debug messages from NAT module
• naterror – Trace error messages from NAT module
• packet-forwarding <WORD> – Enable debug messages
related to packet forwarding
• <WORD> – Module based debug string
• pmdebug – Trace debug messages from Policy Manager API
calls
• pmerror – Trace error messages from Policy Manager API
calls
• rulesdebug – Trace debug messages from rules module
• ruleserror – Trace error messages from debug module
• user <WORD> – Enable debug messages from Policy
manager library
• <WORD> – Module based debug string
sole [adapters|aeroscout|
algo|all|cclib|ekahau|error
s|info|init]
Location engine debugging messages
• adapters – SOLE Adapter manager logs
• aeroscout – Aeroscout logs
• algo – Location algorithm logs
• all – All module logs
• cclib – cc library logs
• errors – Error and higher severity logs
• info – SOLE info logs
• init – Initialization logs
• ekahau – Ekahau logs
